- Page 1 Lighting made better. User Manual LED Wall Pack WP_DD_60SW-BR-3050K WP_DD_80W-BR WP_DD_120SW-BR-3050K WP_DD-BR WP_BR-3050K support@sunco.com AMERICAN (844) 334-9938 COMPANY...
-
Page 2: What's In The Box
Whats in the Box? LED Wall Pack Get Your Gear Light Fixture Drill Wire Strippers Ladder Leveler Screwdriver... -
Page 3: Before You Start
Before You Start Safety Information To reduce the risk of fire, electric shock, or physical injury: • Turn off the switch and circuit breaker before installing this • Equipment should be mounted in locations and at heights LED light fixture. where it will not be subject to tampering by unauthorized •... - Page 4 Installation Guide STEP 1 a. Turn off the circuit breaker for the location where the wall pack will be installed. Make sure the area is well lit by sunlight if the dawn to dusk sensor is going to be used. b.
- Page 5 Installation Guide (Cont.) STEP 4 Non Junction box Junction box a. Before mounting the wall pack, unscrew a cable port. There is one above the junction box and one on either side. STEP 5 a.Thread the cables through the cable ports. Connect the wall pack wires with black the wall power: black (live) to black, white (neutral) to white, and yellow/green white...
-
Page 6: Product Details
Product Details Recommended Dimmers Brand Model LUTRON NTSTV-DV LUTRON NFTV-IV LUTRON DVTV LEVITON IP710 LEVITON DS710-10Z LEGRAND RH4FBL3PW WP_DD_60SW-BR-3050K Specifications Voltage 120V-277V Average Lifetime 50000 hrs 3000K/4000K/ 5000K Lumens 8600 LM Frequency 50/60 Hz Moisture Rating IP65 Beam Angle 85° Weight Usage 3.7 lbs... - Page 7 Product Details WP_DD_80W-BR Specifications Voltage Average Lifetime 120V-277V 50000 hrs Country of Origin Moisture Rating Vietnam IP65 Frequency 50 Hz Weight 5.06 lbs Usage Outdoor Housing Material Aluminium Alloy Power Factor >90 Dimmable 0-10V Warranty 7 Years WP_DD_120SW-BR-3050K Specifications Voltage Average Lifetime 120V-277V 50000 hrs...
- Page 8 Product Details WP_BR-3050K Specifications Voltage 120V-277V Average Lifetime 50000 hrs 3000K/4000K/ 5000K Lumens Up to 8200LM Frequency 50/60 Hz Moisture Rating IP65 Beam Angle 100*87° Weight Usage 3.5 lbs Outdoor Housing Material Power Factor Aluminium Alloy >90 Dimmable 0-10V Warranty 7 Years *Not all options are applicable to all models.
-
Page 9: Common Troubleshooting
Common Troubleshooting Feeling in the dark about an issue with your product? No If you still need some assistance, please feel free to worries! Our troubleshooting section is here to shed some light contact us with any questions. Our team of lighting experts and provide you with easy-to-follow solutions for any problem. - Page 10 Light Distribution Angle I I N N T T E E N N S S I I T T Y Y D D I I S S T T R R I I B B U U T T I I O O N N D D I I A A G G R R A A M M I I N N C C P P L L A A N N S S -/+180...
-
Page 11: Customer Support
It gets even better - scan the QR code for 2 extra years of protection! 30 Day Return Policy At Sunco, we value our customers and stand by If you are not completely satisfied with your the quality and performance of our products. - Page 12 Lighting made better. support@sunco.com AMERICAN (844) 334-9938 COMPANY REV1.0...
