- Page 1 Lighting made better. User Manual Outdoor LED Emergency Light SKU:ODS_2H_BBT-WH-6500K AMERICAN support@sunco.com COMPANY (844) 334-9938...
- Page 2 Whats in the Box? Exit Sign Components Crescent trim plate Sqaure trim plate Wire Nuts M4X25 Screws...
- Page 3 What You Need Get Your Gear Drill Pliers Screwdriver Ladder IMPORTANT: Prior to fixture installation, install junction box in ceiling or wall. When re-lamping, use only lamps specified in the fixture. Using other lamp types may result in transformer damage or unsafe conditions. The battery in this unit may not be fully charged upon unboxing.
- Page 4 Before You Start Safety Information • Not compatible with timing devices. • Turn off circuit breaker before installing this fixture. • Suitable for use in damp environments at temperatures • All electrical connections must be in accordance with local and National Electric Code (N.E.C.) standards. ranging from 32°F to 104°F.
- Page 5 Installation Guide STEP 1 Using a Phillips screwdriver (not included) to unscrew the two screws on the side of the lamp cover. STEP 2 Insert a flathead screwdriver (not included) along a notch on the side of the lamp cover to prise open the lamp cover. Repeat on the opposite side to unlatch the lamp cover.
- Page 6 Installation Guide STEP 5 Connect wires through the -box, (1) When using 120V AC, connect the black wire to the building utility. (2) if using 277V AC, connect the red wire to the building utility. Connect neutral wires to the white lead. Unused wires must be capped using enclosed wire nuts.
-
Page 7: Product Details
Product Details Wiring Diagram Specifications Voltage 120V-277V Beam Angle Wattage 2.4W Lumens 400 LM Power Factor 0.48 IP Rating IP65 Battery 3.6V2000mAh Ni-Cad Weight 2.09 lbs Power Source Battery Housing Material ABS+PC Amps 120V/0.025A, 277V/0.01A Dimmable Warranty 1 Year... -
Page 8: Common Troubleshooting
Common Troubleshooting Feeling in the dark about an issue with your product? No problem. If you still need some assistance, please feel worries! Our troubleshooting section is here to shed some free to contact us with any questions. Our team of light and provide you with easy-to-follow solutions for any lighting experts are happy to help brighten your day. -
Page 9: Customer Support
It gets even better - scan the QR code for 2 extra years of protection! 30 Day Return Policy At Sunco, we value our customers and If you are not completely satisfied with your stand by the quality and performance of our purchase, we accept returns within 30 days products. - Page 10 Lighting made better. support@sunco.com AMERICAN (844) 334-9938 COMPANY REV1.0...
