- Page 1 WSD12T-DD User Manual...
-
Page 2: General Warnings
WSD12T-DD User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger. - Page 3 WSD12T-DD User Manual 3. Device pre-set and use mode. a. Wireless Mode: In this use mode, the datalogger records and transmits each measure sampled to the linked gateway. Typically, the monitoring system is refer to Picture 5 - Status table –...
-
Page 4: Device Enrolment
WSD12T-DD User Manual The following COMMAND table describes the available commands: WIRELESS DEVICES USER INTERFACE Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash refer to STATUS reported in the STATUS table. If the device is performing the TEST ( TEST command ) this command stops it. - Page 5 WSD12T-DD User Manual refer to “WineCap System - User Manual R31 After installing the gateway in appropriate place in charge, ( ”), be sure that the device is enrolled to the gateway and activated. Head for the installation point. On the way, to check the quality of the radio coverage, use the "Field Measurer" function.
- Page 6 WSD12T-DD User Manual 7. Stand-alone USB datalogger installation. Install the datalogger in appropriate place. WineCapKey If the sampling process has not yet been activated, you can start it through the TEST (refer to Picture 4 – Bring it closer to the sensitive point, wait for 2 flashes ( and remove.
-
Page 7: Channel Calibration
WSD12T-DD User Manual 10. Channel Calibration. If you need to add calibration values to a measurement channel, you can access the "Advanced sensor properties" screen and set the gain and offset values in the appropriate fields on the "Calibration" tab. - Page 8 WSD12T-DD User Manual 11. WSD12T-DD-PC - Load tests version. Test The datalogger version suitable for load tests executes the for 12 hours in a row. This feature allows the reception on the gateway a measurement flow with a period of 5 seconds necessary for rapid changing evaluations during load/unload phases.
-
Page 9: Technical Information
WSD12T-DD User Manual 13. Technical Information. Power supply 8.5Ah - 3.6V type “C” lithium internal battery (BAT2) Up to 10 years (samples every 10 minutes and radio signal quality at least Battery life (*) sufficient) • Linear deformation (3 input channels) Measures acquired •... -
Page 10: Mechanical Dimensions
Picture 9 - Mechanical dimensions 15. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l. -
Page 11: Reference Standards
WSD12T-DD User Manual 16. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
