- Page 1 Document revision history Revision Date Comments Made by 1.11 3. May 2021 Intensity & Weight Update 1.10 11. Jan 2021 Graphic Update Ruby 1.00 25. Feb 2015 First Public 0.90 03. Dec 2014 First Draft Date 3.5.2021 Version 1.11 Product Manual 0 of 1 LM200M SABIK Oy ·...
-
Page 2: Product Manual
LO200M LED Range Light Signal Product Manual Version: 1.11 Date: May 3 , 2021 Date 3.5.2021 Version 1.11 Product Manual 1 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 3: Table Of Contents
PERIODIC MAINTENANCE ..........................28 11.1....................28 ECHANICAL INSPECTION AND MAINTENANCE 11.2....................28 UNCTIONAL INSPECTION AND MAINTENANCE REPLACING THE LIGHT UNIT ........................28 TROUBLESHOOTING (Q&A) .........................29 APPENDIX ..............................30 14.1. LO200M O ......................30 ABIK PTIONS AND ABEL 14.2............................31 IMENSIONS 14.3........................31 XPLODED IEW AND 14.4. -
Page 4: Introduction
The LO200M is a signal with integrated flasher and extremely low power consumption. It is also very easy to install and has a durable design. LO200M lantern can be equipped with GPS synchronization and Light Guard monitoring. The lanterns are available in many different versions; please refer to the Sabik product key (Appendix) for more information. -
Page 5: Technical Details
Technical Details 2.1. Main specification table Specification Value Lens Visual/Mechanical diameter 200mm (8”) Lens material UV stabilized Polycarbonate High power Light Emitting Diode Light source (LED) Lens horizontal divergence 6º @ 50% ( ±1º ) of peak intensity Supply Voltage 10 –... -
Page 6: Mechanical
OFF the light. The factory default setting is to switch on the light at 15 lux and off at 60 lux. Power Supplies The LO200M is provided with a ready-made power supply cable. In this section a number of application examples are provided to assist choosing the right configuration/connection. -
Page 7: Solar Battery With Photovoltaic
5.2. Solar Battery with Photovoltaic The maximum allowed solar panel current is 16A and must not be exceeded. It is recommended to install a 16 A fuse as close to the battery as possible. Long cables will result in an energy loss due to the voltage drop in the cable. Charger Setting Recommended settings, 12V systems Lead Acid... -
Page 8: Other Dc Power Supply
Sabik PDA Programmer! Event Log LO200M maintains a log for storing information. Please refer the programmer options for residing and storing the information. The lantern can be configured to also store main events which can be retrieved by service technician using the Sabik PDA programmers. -
Page 9: Mounting
Commissioning The installation procedure is simple, as the lantern is (usually) pre-installed/configured at the factory. If you must install additional hardware, or change settings, please follow the instructions below or contact Sabik Oy for instructions. 8.1. Mounting The lantern is fixed to the fundament using Four M12 bolts. The lantern can be mounted on a horizontal base or through a (vertical) wall. -
Page 10: Precise Aligning Of The Light Beam
8.2. Precise Aligning of the Light Beam Aligning is done using the spring loaded aligning nuts. Align the beam horizontally by adjusting the horizontal alignment nuts using two 19mm wrenches. You may attach and use a telescopic-sight (sold as a separate accessory) for precise adjusting. -
Page 11: Sabik Easyprogrammer
Programming Programming can be done with a wireless Sabik Easy Programmer, PDA Programmer or PC/USB interface. Below you will find short instructions on how to use the Sabik easyProgrammer. 9.1. Sabik easyProgrammer Sabik easyProgrammer is a stand-alone simple programmer for lanterns with an infrared-Interface. With the aid of easyProgrammer PC software, you can download/upload information to/from the handheld programmer to a Windows based personal computer. -
Page 12: Using The Programmer
9.1.1. Using the programmer Start/Shut Down To start the programmer, press and hold down the green (Enter) button. 1. Start programmer: Press green ENTER for at least 2sek. 2. Set/Check Date and time settings: Select ADVANCED -> DATE/TIME To check/change existing lantern settings 1. - Page 13 On the following pages you will find the Sabik easyProgrammer built-in flash character list where: Number: Flash character number used by Sabik. Flash Character: Flash character name. Duty Cycle: Light on time (seconds) in percent. Min flash duration: Shortest light on time in one cycle. FL1...FL9: EC...EC9: Date 3.5.2021 Version 1.11 ...
- Page 14 Date 3.5.2021 Version 1.11 Product Manual 13 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
- Page 15 Date 3.5.2021 Version 1.11 Product Manual 14 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
- Page 16 Date 3.5.2021 Version 1.11 Product Manual 15 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 17: Configuration Using Pc Usb-Interface And Sabik Programmer Lite
9.2. Configuration using PC USB-interface and SABIK Programmer Lite 9.2.1. Installation of application Refer to Sabik Programmer Lite manual for installation of drivers and application. Date 3.5.2021 Version 1.11 Product Manual 16 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 18: Launching The Application
9.2.2. Launching the application Sabik programmer software can be launched in two ways: Select Programmer Lite from your Start menu or If a shortcut is created on your desktop, double- click on it. When the application is launched, the Main window will appear: The Main window consists of the following areas: A. - Page 19 Dated Shutdown. When Yes selected, please specify Start and End dates for, when the lantern is in Idle state. Photocell override state: - None: The lantern senses light level and starts/stops flashing. - Day: The lantern does not flash, even if it is dark. - Night: The lantern flashes all the time.
-
Page 20: Flash Code Editor
9.3. Flash code editor The Flash Code editor is a small simple database application for editing light characters. The values in this database can be selected in Programmer Lite Flash Code drop-down list. Launch Flash Code Editor Sabik programmer software can be launched in two ways: Select Programmer Lite from your Start menu or double click the Flash Code Editor icon on your desktop (If you created a shortcut in your desktop). -
Page 21: Optional Modules
Optional Modules Dated Shut-down The dated shut-down feature is a software dependent option, which can be enabled with the Sabik PDA Programmer. By setting a shut-down date and a start-up date in the controller, the lantern can be switched off to save power during times when channels/fairways are closed. - Page 22 Command Possible response The modem sends a message that displays the versions of the various components in the lantern: LG SMC MK II Version SMC Firmware: 02.27 GPS Hardware: 03.00 GPS Firmware: 01.09 GSM Software: 0.0.6 GSM Firmware: 421 The modem sends a message that displays the basic status of the SMC: SMC STATUS ACT.TIME: 1526 LIGHT: OFF...
- Page 23 Command Possible response RSSI The modem sends a message that displays the “receive GSM signal strength indicator” RSSI: 0: -113 dBm or less 1: -111 dBm 2 to 30: -109 to -53 dBm 31: -51 dBm or greater 99: not known or not detectable RSMS The modem resets the SMS counter The LightGuard unit and all antennas are fully integrated in the design of the lantern.
-
Page 24: Sim Card Insertion/Change (Lanterns With Gsm Module)
10.1. SIM Card Insertion/Change (lanterns with GSM Module) These instrutions are for authorized service personnel only. If the lantern is supplied with built-in GSM monitoring, it is recommended that the SIM card should have been supplied to Sabik or their authorised distributor for fitting and programming prior to delivery. -
Page 25: Gps Antenna Assembly Instructions
Slide the SIM holder lock to the "OPEN" position and lift the holder upwards. Push the SIM card into the holder and turn it down. Slide the SIM holder lock to "CLOSE" position. Complete the service: Carefully close the cover, without damaging the sealing ring.Tighten the 6mm screws. - Page 26 Thread the antenna cable (4.) thru the hole in the side of the nylon sleeve (2.) and connect it to the GPS antenna head (1.). Assemble the antenna and tighten the small Allen screw (using a 2,5mm key) to lock the sleeve to the foot. Disassemble the cable gland and thread the cable thru Assemble the cable gland.
-
Page 27: Gsm Antenna Connection
Tighten the cable gland using a 22mm wrench. Check, that the fitting between cable and cable gland is tight. Open the cover and connect the grounding strap following the instruction in chapter Inserting/changing optional SIM card Connect the cable to the GPS antenna connector on the circuit board. -
Page 28: Checking Mobile Phone Communication
10.4. Checking Mobile Phone Communication With the lantern in GSM coverage send text the message TEL to the mobile phone number recorded on the side of the box. The lantern will respond with its own text message giving the lantern configuration. By sending TEL1 the lantern will respond with the configuration that the factory has set including its character and intensity. -
Page 29: Sabik Programmer For Wm (Pda Programmer)
10.8. Sabik Programmer for WM (PDA Programmer) The following features are now available: Wireless communication (IR) Event log up to 3 years Lantern data stored in PDA memory Flexible GUI adjustments for administrators and users Data integrity protection The view of the Programmer may vary depending on platform. -
Page 30: Troubleshooting (Q&A)
Troubleshooting (Q&A) Q: I covered the photocell, but the lantern does not turn on. A1: Read controller values with a programmer and check status. The battery voltage is below the minimum programmed value. Replace the battery. A2: The dated shut-down feature may be enabled. Re-programme to disable shut-down feature A3: Read controller values with the programmer and check status. -
Page 31: Appendix
Appendix 14.1. Sabik LO200M Options and Label Every Sabik product has a label with full product information. The label is on the product and the box. Option Matrix LightGuard GSM Integrated GSM based monitoring with OPT 10 external GSM antenna... -
Page 32: Main Dimensions
14.2. Main Dimensions The dimensions are in mm. 14.3. Exploded View and Part List Date 3.5.2021 Version 1.11 Product Manual 31 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 33: Recycling And Disposal Of Products
14.4. Recycling and Disposal of products Date 3.5.2021 Version 1.11 Product Manual 32 of 33 LM200M SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... - Page 34 NOTICE! Incorrect handling or improper disposal can cause danger to the environment! There can be serious damage to the environment if substances hazardous to the environment are handled incorrectly and if they are disposed of incorrectly. Separate waste and dispose of it separately. ...
