- Page 1 Document revision history Revision Date Comments Made by 20. Sep 2019 Minor adjustments 1.00 24. Apr. 2017 First release Date 20.11.2020 Version 2.0 Product Manual 0 of 1 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 2: Product Manual
SC 160 LED Marine Lantern Product Manual Version: 1.2 Date: January 11 , 2020 Date 20.11.2020 Version 2.0 Product Manual 1 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 3: Table Of Contents
Disclaimer: Every possible effort has been made to ensure the validity of this document. It represents the current view (as of the publishing date) on the functions and properties of the products mentioned in the document. SABIK OY is not responsible for possible typing errors. The pictures and drawings are for descriptive use only. The document may be updated or changed without notice. -
Page 4: Introduction
Introduction The SC 160 is a self-powered medium-range LED lantern for buoys and minor beacons with up to 8 NM range with best-in-class optical performance for fixed and floating structures. The lantern includes solar panels, battery and charge controller. This lantern is designed for harsh marine environments and for long uninterrupted operation. -
Page 5: Optical Performance
1.1. Optical performance Optical performance Maximum fixed intensity SC 160 I N 5° @ 50% peak intensity FWHM White Yellow Green 1850 cd 1150 cd 1200 cd 1000 cd Power Consumption Maximum fixed intensity SC 160 I W 10° @ 50% peak intensity FWHM... -
Page 6: Product Identification And Options
Product Identification and Options Every Sabik unit is supplied with a product label. (The picture is only an example) Option matrix for SC 160 1 Product label Product Options included Description SC 160 OPT 9L LightGuard GSM + GPS Integrated GSM/GPS based... - Page 7 Date 20.11.2020 Version 2.0 Product Manual 6 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 8: Mechanical
Mechanical The optical lens is made of UV-resistant Acrylic and lantern housing is made of epoxy painted marine grade corrosion resistant aluminium and rotomolded PE. There are no serviceable parts inside the optical unit. If the lantern is equipped with Sabik LightGuard, and you must install/change the SIM card or service parts inside the lantern –... -
Page 9: Mounting
3.1. Mounting The SC 160 unit is suitable for fixed and floating installations (buoys). The mounting flange supports installation on structures using 3 x M12 bolts on a 330mm diameter, a common mounting arrangement for marine lanterns. The mounting bolt holes should be covered with plastic insulators upon installation, to prevent galvanic contact with the mounting platform as well as protect the painting on the mounting flange during installation. -
Page 10: Aligning
3.2. Aligning No special aligning is needed. On fixed installations just ensure, that the base is levelled. Date 20.11.2020 Version 2.0 Product Manual 9 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 11: Electrical
Electrical The SC 160 lantern is operated using built in solar panels, charger and battery. Date 20.11.2020 Version 2.0 Product Manual 10 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 12: Solar Charger
4.1. Solar Charger A programmable solar panel regulator is integrated in the lantern, enabling the lantern to control solar panel charging directly without the need to install an external charger. Date 20.11.2020 Version 2.0 Product Manual 11 of 43 LED 160 SABIK Oy ·... -
Page 13: Programming
Programming Programming the lantern can be done using Sabik easyProgrammer, Bluetooth application for Android or iPhone or Programmer Lite (USB). IR port and photocell The combined infrared communication port and Photocell (ambient light sensor) is located in the base of the light unit. Programming is done by pointing the programmer at the IR port. -
Page 14: Sabik Easyprogrammer Quick Guide
5.1. Sabik easyProgrammer Quick Guide Sabik easyProgrammer is a stand-alone simple programmer for lanterns with an infrared-Interface. With the aid of easyProgrammer PC software, you can download/upload information to/from the handheld programmer to a Windows based personal computer. This is done using the SABIK Infrared USB interface (sold separately). - Page 15 To check/change existing lantern settings 1. Select SETTINGS and press green ENTER 2. Point at lantern’s IR diode to read lantern’s settings. The programmer beeps twice, when reading is completed. 3. To change existing settings, press DOWN/UP keys to select, and press ENTER to change setting.
- Page 16 Sabik EasyProgrammer Flowchart Date 20.11.2020 Version 2.0 Product Manual 15 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 17: Easyprogrammer Flash Character List
5.1.1. EasyProgrammer Flash Character List On the following pages you will find the Sabik easyProgrammer built-in flash character list where: Number: Flash character number used by Sabik. Flash Character: Flash character name. Duty Cycle: Light on time (seconds) in percent. Min flash duration: Shortest light on time in one cycle. - Page 18 001 Fixed light 100,0% 002 Fl(2) 10s 10,0% 2 Fl(2) 10s 10% 0,50 003 Fl(2) 10s 10,0% 3 Fl(2) 10s 10% 0,50 004 Fl(2) 10s 16,0% 4 Fl(2) 10s 16% 0,80 005 Fl(2) 10s 20,0% 5 Fl(2) 10s 20% 1,00 006 Fl(2) 10s 20,0% 6 Fl(2) 10s 20% 1,00...
- Page 19 081 ISO 6S 50,0% 81 ISO 6S 50% 3,00 082 ISO 8S 50,0% 82 ISO 8S 50% 4,00 083 ISO 3S 50,0% 83 ISO 3S 50% 1,50 084 LFL 10S 20,0% 84 LFL 10S 20% 2,00 085 LFL 10S 30,0% 85 LFL 10S 30% 3,00 086 LFL 10S 40,0% 86 LFL 10S 40%...
- Page 20 161 VQ(3) 5S 9,0% 161 VQ(3) 5S 9% 0,15 0,15 0,35 0,15 0,35 0,15 3,85 162 VQ(3) 5S 12,0% 162 VQ(3) 5S 12% 0,20 163 VQ(3) 5S 18,0% 163 VQ(3) 5S 18% 0,30 164 VQ(6)+LFL 10S 32,0% 164 VQ(6)+LFL 10S 32% 0,20 165 VQ(6)+LFL 10S 38,0% 165 VQ(6)+LFL 10S 38%...
-
Page 21: Sabik Bluetooth Application Guide
® 5.2. Sabik Bluetooth application guide Date 20.11.2020 Version 2.0 Product Manual 20 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 22: Introduction
5.2.1. Introduction The Product is designed for programming and controlling Sabik Bluetooth® enabled lanterns using a simple user friendly interface. The Android or iPhone app can be downloaded and installed to Bluetooth® 4.0 (Bluetooth® Smart) capable smart phone. The useable range between lantern and phone is usually more than 10m (the range is depending on type of lantern) and maximum up to 50m. -
Page 23: Installation
5.2.2. Installation Download The app can be downloaded from Apple (http://store.apple.com ) or Google ( https://play.google.com ) for free. Observe, that you may have to register yourself before downloading. The app is free of charge. Installation Follow the instructions on Google Play or Apple Store. Registration For the application to be able to work, you have to register your application using a valid user name and a password. -
Page 24: Launching The Application
5.2.3. Launching the application After the installation you should find an icon for the Bluetooth® app. You may relocate it if necessary. Switch Bluetooth on before starting the application. Date 20.11.2020 Version 2.0 Product Manual 23 of 43 LED 160 SABIK Oy ·... -
Page 25: Login And Selecting Lantern
5.2.4. Login and selecting lantern Fill in your user name and password and tap “Login”. -if you don’t have a user name and password, please contact your dealer to obtain these. This information is stored in your device so the next time you will be logged in just by tapping the “Login”... - Page 26 Date 20.11.2020 Version 2.0 Product Manual 25 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 27: User Interface
5.2.5. User Interface The interface labels are loaded from the lantern, so only the parameters relevant to this lantern are displayed. For instance, if there is no GPS function in the lantern, none are displayed in the application. The pages shows the standard settings. - Page 28 On the CONFIGURATION page you can change the lanterns configuration by tapping the small >-shaped symbol on the right side of the setting’s name. If needed, expand the block to see the advanced settings. When, for example, LED Intensity is selected, you will be able to adjust the intensity by writing the range (in NM) or adjusting the intensity in percent.
-
Page 29: Pages
5.2.6. Pages On the pages you will find information about the lantern, change settings and send commands. Observe that if your lantern does not have a specific module installed, then there is no information about that module. DEVICE STATUS Here you will find information about the Light, Power, Temperature, Position, Counters and Engineering values. You cannot make any changes to the lantern from this page. - Page 30 Date 20.11.2020 Version 2.0 Product Manual 29 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 31: Configuration
5.2.7. CONFIGURATION On this page you can review and change the values of the Flasher, Charger, GPS & Sync, Tilt and Impact, Dated Shutdown and Bluetooth® Settings. Tap Write button to send new values to the lantern. The advanced settings are shown in italics Flasher Flash Character:... - Page 32 Advanced Settings Shutdown Date: Set date to shut down lantern Startup Date: Set date to start up lantern Bluetooth Settings Bluetooth Device name: Set lantern’s Bluetooth name Advanced settings PIN Code Enabled: Enable or disable lantern PIN code (give PIN code to change setting) PIN Code: Set new PIN Code COMMANDS...
-
Page 33: About
5.2.8. About Device Product Code Serial number Advanced settings Advanced settings Bluetooth Firmware Lantern Software Version GPS Software Version GPS Hardware Version Date 20.11.2020 Version 2.0 Product Manual 32 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... -
Page 34: Create A Custom Flash Character Using Bluetooth App; Step By Step Instructions
5.2.9. Create a custom Flash Character using Bluetooth app; Step by Step Instructions Select CONFIGURATION page Tap on > symbol to the right of Flash Character Select an existing Character from the list as a starting point 4. tap “Edit Flash Signal” to customize the character. - Page 35 Date 20.11.2020 Version 2.0 Product Manual 34 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 36: Configuration Using Pc Usb-Interface And Sabik Programmer Lite
5.3. Configuration using PC USB-interface and SABIK Programmer Lite Installation of application Refer to Sabik Programmer Lite manual for installation of drivers and application. Date 20.11.2020 Version 2.0 Product Manual 35 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com... - Page 37 Launching the application Sabik programmer software can be launched in two ways: Select Programmer Lite from your Start menu If a shortcut is created on your desktop, double- click on it. When the application is launched, the Main window will appear: Date 20.11.2020 Version 2.0 ...
- Page 38 The Main window consists of the following areas: A. Settings Flash Code Drop-down list. This list can be edited with the Flash Code Editor *. Intensity Drop-down list. % of maximum value. Photocell Threshold defines when the flasher starts, selectable 5 – 200 lx Dated Shutdown.
- Page 39 Date 20.11.2020 Version 2.0 Product Manual 38 of 43 LED 160 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
-
Page 40: Periodic Maintenance
Periodic Maintenance The SC 160 is a robust lantern, which requires no maintenance, except for periodical lens cleaning. To maintain a good light output and achieve a long service life, it is advisable to visually inspect the lantern whenever visiting the site. -
Page 41: Replacing The Light Unit
Replacing the light unit There are no user serviceable parts inside the lantern. For servicing of the light source, SIM card or GPS/GSM unit – please contact Sabik or distributor near you. Date 20.11.2020 Version 2.0 Product Manual 40 of 43 LED 160 SABIK Oy ·... -
Page 42: Replacing The Battery And/Or Solar Panel
Replacing the battery and/or solar panel First unscrew the four hex bolts using an 8mm Allen (hex) key. Remove and disconnect the light unit. Turn over the lantern and unscrew the (6) M6 bolts, using a 4mm Allen key. Do not unscrew the four battery bracket bolts! Do NOT Remove! Date 20.11.2020 Version 2.0 ... - Page 43 Carefully pull out the inside contents. Use a 12mm wrench to disconnect the battery (+ and -) leads. To change the solar panel, open the junction box and disconnect the leads. Replace the panel(s) and re assemble the lantern. Unscrew the four bottom plate screws holding the battery bracket using a 3mm Allen key and a 12mm wrench.
-
Page 44: Troubleshooting (Q&A)
Troubleshooting (Q&A) Q: I covered the photocell, but the lantern does not turn on. A1: Read controller values with the programmer and check status. The battery voltage is below the minimum programmed value. Replace the battery. A2: The dated shut-down feature may be enabled. Re-programme to disable shut-down feature A3: Read controller values with the programmer and check status.
