- Page 1 Installation Guide Quadrangle Bath Whirlpool Français, page “Français-1” Español, página “Español-1” 1022211-2-D...
-
Page 2: Important Information
Do not relocate the whirlpool pumps, or make other modifications to the whirlpool system, as this could adversely affect the performance and safe operation of the whirlpool. Kohler Co. shall not be liable under its warranty or otherwise for personal injury or damage caused by any such unauthorized modification. -
Page 3: Table Of Contents
Inspect the whirlpool for damage before you begin installation. You must install this whirlpool to an adequately supported, level subfloor. Model K-1360 features an integral fill system using dual fill ports at both sides of the Waterfall, and preinstalled valving. Kohler Co. 1022211-2-D... -
Page 4: Tools And Materials
Consult local and national codes. Tools and Materials Plus: • Conventional Woodworking Tools and Materials • Drop Cloth • Cement, Mortar, or Construction Adhesive • 2x4s Tin Snips Silicone Sealant 1022211-2-D Kohler Co. -
Page 5: Prepare The Site
NOTICE: Measure your actual product for site preparation. Note the model number located on the whirlpool pump, then visit the product page at kohler.com for additional information. Make sure the flooring offers adequate support for your whirlpool, and verify that the subfloor is flat and level. -
Page 6: Secure The Whirlpool To The Subfloor
With help, carefully lift the whirlpool into position. Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support blocks. Apply a continuous bead of 100% silicone sealant around the entire rim of the whirlpool. 1022211-2-D Kohler Co. -
Page 7: Secure The Whirlpool To The Stud Framing
Use #6 large-head galvanized nails to secure the nailing-in flange to the studs. For tile ledge installations, size and install a pressure-treated wood batten along the nailing-in flange. Pre-drill nail holes through the wood batten and nailing-in flange before securing with galvanized nails. Kohler Co. 1022211-2-D... -
Page 8: Cut The Pump Banding Straps
5. Cut the Pump Banding Straps IMPORTANT! This step is necessary to make your KOHLER whirlpool operate more quietly. Use tin snips to cut the two pump banding straps from each whirlpool pump. NOTE: Do not raise the pumps higher than they were before you cut the pump banding straps. If the pumps are raised too high, they will not prime properly. -
Page 9: Make Electrical Connections
Follow local electrical codes. Bond in accordance with national and local codes. A wiring harness has been pre-wired at the factory, allowing communication between the keypad, all features, and the control. No additional wiring is required, but ensure that all wires are securely fastened. Kohler Co. 1022211-2-D... - Page 10 Make Electrical Connections (cont.) NOTE: Your wiring harness includes an antenna for the optional remote control. Do not alter or damage this antenna during installation. *Outside of North America, this device may be known as a Residual Current Device (RCD). 1022211-2-D Kohler Co.
-
Page 11: Install The Whirlpool Trim Kit
It takes approximately 1 minute to cycle through all eight colors. Verify functions using the remote control. Refer to the ″Remote Control Operation″ section. NOTE: For additional information on whirlpool operation, see the ″Confirm Proper Operation″ section of this guide. Kohler Co. 1022211-2-D... -
Page 12: Complete The Finished Wall
Tape and mud the water-resistant wall material. Install the finished wall to the water-resistant wall material. Seal the joints between the whirlpool rim and the finished wall material with silicone sealant. Install the faucet trim according to the instructions packed with the trim. 1022211-2-D Kohler Co. -
Page 13: Complete The Finished Wall - Continued
Remove plaster by carefully scraping with a wood edge. Do not use metal scrapers, wire brushes, or other metal tools. Use a powder-type detergent on a damp cloth to provide mild abrasive action to any residual plaster. Kohler Co. 1022211-2-D... -
Page 14: Install The Removable Pillows
firmly with the heel of your hand. Check to make sure that the pillows are attached firmly to the whirlpool. Detach the pillows by lifting them off the whirlpool surface. 1022211-2-D Kohler Co. -
Page 15: Confirm Proper Operation
The Riverjets and Flexjets will not operate at the same time. NOTE: The water temperature in the whirlpool should not exceed 104°F (40°C). The heater will automatically turn off as the water temperature approaches 104°F (40°C) and will remain off until the water cools. Kohler Co. 1022211-2-D... -
Page 16: Operating Sequence
The Tidepool mode does not affect the Waterfall. NOTE: Some air may flow from one or more jets for a short time after the Tidepool feature has been activated. 1022211-2-D Kohler Co. -
Page 17: Chromatherapy Operation
flow volume. Troubleshooting Procedures NOTICE: This section is for general aid only. A Kohler Co. Authorized Service Representative or qualified electrician should correct any electrical problems. For warranty service, call 1-800-4KOHLER from within the USA and Canada, or 001-800-456-4537 from within Mexico. - Page 18 C. Replace control. 9. Flexjets operate, but A. Insufficient water in whirlpool A. Fill whirlpool so water covers Riverjets do not operate basin. water-level sensors. as described. B. User keypad does not work. B. Replace user keypad. 1022211-2-D Kohler Co.
- Page 19 B. Remove jet, replace and lubricate (squeal). O-ring, and reinstall jet. 19. Remote control (if A. Batteries improperly installed or A. Replace batteries. equipped) does not work. dead. B. Antenna on wiring harness is B. Replace wiring harness. damaged. Kohler Co. 1022211-2-D...
- Page 20 Troubleshooting the Chromatherapy Lights - H2 Models Only Symptoms Probable Causes Recommended Action 20. Chromatherapy lights do A. Loose, disconnected or damaged A. Check wiring for proper not work. wiring/connections. connections. Replace wiring if necessary. B. Control does not work. B. Replace control. 1022211-2-D Kohler Co.
