Configuring the Router via the
D-Link Click'n Connect Utility
The Click'n Connect utility will guide you through the installation process step-
by-step. Follow the on-screen instructions, then proceed to the next step.
Step 3 – Connect the Device to the ADSL Line
Connect your ADSL telephone line from the wall socket to the DSL-504T ADSL
socket. Please note that if you are using an ADSL Splitter/Filter, you will need to
connect the telephone line from the DSL socket on the filter to the DSL-504T
ADSL socket.
Once you have completed this, wait for the ADSL LED to light up, and click on
Next to continue to Step 4.
6
Follow the on-
screen
instructions,
then Click
Next to
continue
