D-Link DSL-504T Quick Installation Manual

D-Link DSL-504T Quick Installation Manual

Adsl modem router
Hide thumbs Also See for DSL-504T:

Advertisement

Quick Links

Download this manual
This product can be set up using
any current web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 6.2.3.
Before You Begin
1.
If you purchased this Router to share your high-speed Internet connection with other
computers, you must have an established Internet account from an Internet Service Provider
(ISP).
2.
It is best to use the same computer that is connected to your ISP for configuring the DSL-
504T ADSL Modem Router. The DSL-504T acts as a DHCP server and will assign all the
necessary IP address information on your network. See the Appendix for setting each
network adapter to automatically obtain an IP address.
Check Your Package Contents
If any of the above items are missing, please contact your reseller.
©2007 D-Link Australia Pty Ltd. All rights reserved. Trademarks or registered trademarks are the property of their
respective holders. Software and specifications subject to change without notice.
DSL-504T Generation II
4-Port Ethernet ADSL2+ Modem Router
CD-ROM with Click'n Connect Utility and
Product Documentation
Telephone Cable (RJ-11)
CAT 5 UTP Ethernet Cable (RJ-45)
12V 1.25A
Power Adapter
DSL-504T Generation II ADSL Modem Router.
DSL-504T
ADSL Modem Router
Using a power adapter with
a different voltage rating will
damage and void the
warranty for this product.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DSL-504T and is the answer not in the manual?

Questions and answers

Related Manuals for D-Link DSL-504T

Summary of Contents for D-Link DSL-504T

  • Page 1 It is best to use the same computer that is connected to your ISP for configuring the DSL- 504T ADSL Modem Router. The DSL-504T acts as a DHCP server and will assign all the necessary IP address information on your network. See the Appendix for setting each network adapter to automatically obtain an IP address.
  • Page 2 Connect the power adapter to the power input at the back panel of the DSL-504T and then plug the other end of the power adapter to a wall outlet or power strip. On the front of the device, the Power LED will turn ON to indicate proper operation.
  • Page 3 You can select one of five options: User Manual: This option will open up the DSL-504T user manual. You will need Adobe Acrobat Reader installed to view the manual. Quick Install Guide: This option will show you a software-based version...
  • Page 4 Step 1 - Power Up the Device Follow the on- screen instructions, then Click Next continue Connect the Power Adapter from the wall socket to the DSL-504T. Wait for the Status LED to blink before proceeding onto the next step.
  • Page 5 Click Next continue Connect the Ethernet cable from the computer to one of the DSL-504T LAN ports now. Wait for the LAN Link LED for the corresponding port to flash, then click on Next to continue to Step 3.
  • Page 6 Connect your ADSL telephone line from the wall socket to the DSL-504T ADSL socket. Please note that if you are using an ADSL Splitter/Filter, you will need to connect the telephone line from the DSL socket on the filter to the DSL-504T ADSL socket.
  • Page 7 Follow the on-screen instructions, then proceed to the next step. Step 4 – Checking Device Connectivity The Click’n Connect utility will now check the DSL-504T to make sure it has been connected correctly. Once it has successfully detected your modem, it will proceed to the next step automatically.
  • Page 8 Configuring the Router via the D-Link Click’n Connect Utility The Click’n Connect utility will guide you through the installation process step- by-step. Follow the on-screen instructions, then proceed to the next step. Step 5 – ISP Configuration Select your Select your...
  • Page 9 Configuring the Router via the D-Link Click’n Connect Utility The Click’n Connect utility will guide you through the installation process step- by-step. Follow the on-screen instructions, then proceed to the next step. Step 6 – Account Configuration Enter your ISP Username...
  • Page 10 Step 7 – Completing Setup The Click’n Connect Utility will now save the settings you have entered to the DSL-504T modem, and verify that you have entered your account details correctly to ensure an Internet connection can be established. If you receive an error message, please review all the information that you have...
  • Page 11 Configuring the Router via the D-Link Click’n Connect Utility The Click’n Connect utility will guide you through the installation process step- by-step. Follow the on-screen instructions, then proceed to the next step. Step 9 – Setup Complete – Ethernet and USB...
  • Page 12 Configuring the Router via the Web Interface Now it is time to configure the Router. Enter 10.1.1.1 into the URL address box. Open your Web browser and type http://10.1.1.1 into the URL address box. Press Enter Return. The login dialog appears: When you first log in, your Login Name is admin...
  • Page 13 Configuring the Router via the Web Interface Once you have logged in, the Home directory tab is prominent with the setup Wizard window displayed. Most users will be able to use the setup wizard to establish the ADSL connection to your ADSL Internet Service Provider (ISP). To begin using the setup wizard, click on the Run Wizard button in the middle of the web page.
  • Page 14 Configuring the Router via the Web Interface The first Setup Wizard window lists a summary of the steps required to complete the setup. Click the Next button to begin setup. Click the Next button.
  • Page 15 Configuring the Router via the Web Interface Configure the time zone used for the Router’s system clock. Select the appropriate time zone setting for your location. Click Next to continue. Select the time zone you are located in. Click the Next button.
  • Page 16 Configuring the Router via the Web Interface Configure the Internet connection type for the WAN interface. Your ISP has given this information to you. If you do not know what type of connection to use, exit the Setup Wizard and contact your ISP for the information. The Setup Wizard window that appears when you click the Next button depends on what connection type you select.
  • Page 17 Configuring the Router via the Web Interface PPPoE / PPPoA Connection If you selected the PPPoE/PPPoA connection type in the previous window, you will see the Setup Wizard window pictured here. Type in the Username and Password used to identify and verify your account to the ISP. If you have been instructed to change the VPI number and VCI number, type in the new values.
  • Page 18 Configuring the Router via the Web Interface Setup Completed All the settings for the connection are now completed. Click the Restart button to save the new settings and restart the Router. The following Restarting window will open to indicate the system is in the middle of rebooting. It will take about two minutes to restart the Router.
  • Page 19 To connect to the network, make sure the network adapter in your computer is configured properly. The following section describes how to configure the network adapter to obtain an IP address automatically for the DSL-504T ADSL Router. For Microsoft Windows XP Go to Start >...
  • Page 20 The dialog box displays with a list of currently installed network items. Click Internet Protocol (TCP/IP) Click Properties Make the choice to get IP settings assigned automatically. Select Obtain an IP address automatically Click...
  • Page 21 Technical Support You can find software updates and user documentation on the D-Link website. D-Link Australia 1 Giffnock Avenue, North Ryde, NSW 2113 Sydney, Australia TEL: +61-2-8899-1800 FAX: +61-2-8899-1868 Australia: 1300-766-868 New Zealand: 0800-900-900 URL: www.dlink.com.au www.dlink.co.nz E-MAIL: support@dlink.com.au...
