KTX 3
Heating element heats the radiator that it is installed in and, at the
same time, controls its temperature. For temperature regulation
please use buttons
and
. LCD display panel shows current tem-
perature measured inside the radiator. After settings have been mod-
ified, display panel will flash showing the newly set temperature for
a few seconds and will go back to displaying current temperature.
Heating indicator
will come up on the display panel if the newly
set temperature is higher than the current one. In order to see the
set temperature, press one of the arrows on the display.
time settings (clock/dryer/timer)
on/off button
parameters regulation
active 24-hour timer
timer active zone code
clock
temperature
heating indicator
Construction of the device as well as physical characteristics of the
heating agent inside the radiator influence the way in which the heat
is distributed — the temperature of the bottom pipes of the radiator
(especially the two located at the very bottom of the radiator) may
be lower than the temperature of the remaining parts of the radia-
tor — this is a normal phenomenon.
Turning the device on does not mean that it uses the same maximum
power for the whole time it is on. On turning the device on, it op-
User Manual — Electric heating elements of the KTX series
51
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TERMA KTX 3
Summary of Contents for TERMA KTX 3
- Page 1 KTX 3 time settings (clock/dryer/timer) on/off button parameters regulation active 24-hour timer timer active zone code clock temperature heating indicator Heating element heats the radiator that it is installed in and, at the Construction of the device as well as physical characteristics of the same time, controls its temperature.
-
Page 2: Manual Mode
erates with the nominal power for a short period of time in order In the dryer mode, the heating temperature can be adjusted — the to heat up the radiator to the set temperature. After that it turns last temperature used in the dryer mode is memorised by the de- itself on and off periodically, using only as much energy as it is re- vice. -
Page 3: Clock Programming
Clock programming The start of every time zone is programmed subsequently from T1, T2, T3 to T4 (hour and minutes), and the temperature for every time zone is specified. The entire cycle is repeated every day on condi- Press both arrow buttons at the same time tion that the device is on and Timer is active. -
Page 4: Timer Programming
Timer programming Display panel is no longer flashing, TIMER icon and a relevant time zone code T(1-4) Turn on the device by pressing . depending on current time are on Press and hold → button ON or OF will TIMER programming is finished. start flashing Attention: When the 24 hour TIMER is on, the user can temporari- Activate (On) or deactivate (Of) the mode... -
Page 5: Problem Solving
Problem solving Problem Possible cause Solution Device is plugged in, LCD display is empty. Problem with the connection. Check the power wire connection, plug and the socket. Device does not heat, E9 is flashing on the Device signals malfunction, temperature sen- Disconnect the device from its electric supply and display panel.
