  • Page 1 Combi Dome Camera SCC-643(P) Owner’s Instructions...

  • Page 2: Safety Precautions

    Safety Precautions The purpose of this information is to ensure proper use of this product to prevent danger or damage to property. Please be sure to observe all precautions. * The precautions are divided into "Warnings" and "Cautions" as distinguished below: Warning: Ignoring this warning may result in death or serious injury.
  • Page 3 9. If this product fails to operate normally, contact the store of purchase or your nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted repair.) 10.
  • Page 4 Before Usage This is a basic instruction manual for the SCC-643(P) user. It contains all the instructions needed to use the SCC-643(P) from a simple introduction of the control locations and functions of the SCC-643(P) to installation methods in the set up menu.
  • Page 5 Approval of Standards Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interface in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 6: Table Of Contents

    Table of contents Before Usage --------------------------------------------------------------------------------------1-1 Chapter 1 SCC-643(P) Overview -----------------------------------------------------------1-5 SCC-643(P) Introduction ---------------------------------------------------------1-6 SCC-643(P)Locations of Control-----------------------------------------------1-7 SCC-643(P) FRONT --------------------------------------------------------------1-7 SCC-643(P) BACK ----------------------------------------------------------------1-8 ADAPTER CONNECTION-------------------------------------------------------1-9 INITIAL SETTING ----------------------------------------------------------------1-10 Setting RS-422A/RS-485 termination ---------------------------------------1-11 SWITCH SETTING --------------------------------------------------------------1-12 Chapter 2 SCC-643(P) Installation---------------------------------------------------------2-1 Before Installing -------------------------------------------------------------------2-2...
  • Page 7 - AGC ----------------------------------------------------------------------------3-10 - S.S ------------------------------------------------------------------------------3-10 - SLOW --------------------------------------------------------------------------3-11 - NORMAL ----------------------------------------------------------------------3-11 - FAST ---------------------------------------------------------------------------3-11 - F.F ------------------------------------------------------------------------------3-11 - WHITE BAL-------------------------------------------------------------------3-12 - SPECIAL ----------------------------------------------------------------------3-14 - AUTO FOCUS ---------------------------------------------------------------3-15 - D-ZOOM-----------------------------------------------------------------------3-15 - EXIT ----------------------------------------------------------------------------3-15 3. PRESET-------------------------------------------------------------------------3-16 4. AUTO MODE-------------------------------------------------------------------3-18 - AUTO PAN -------------------------------------------------------------------3-18 - PATTERN---------------------------------------------------------------------3-19 5.

  • Page 8: Chapter 1 Scc-643(P) Overview

    Chapter 1 SCC-643(P) Overview In this chapter we will briefly introduce the SCC-643(P) and show main functions, locations of control and Switch Setting.

  • Page 9: Scc-643(P) Introduction

    IC, it can catch clear images up to 220 times. The SCC-643(P) is a multifunction camera that is equipped with all of the key functions of the existing surveillance cameras: - Low-Light Surveillance function that enables image capture even under extremely low light conditions.

  • Page 10: Locations Of Control

    Locations of Control FRONT COVER BODY COVER DOME ZOOM LENS...
  • Page 11 BACK...

  • Page 12: Adapter Connection

    ADAPTER CONNECTION SCC-643(P) Adapter BOARD...

  • Page 13: Initial Setting

    Dip Switch setting is same as the following example: EX) CAMERA ADDR: When it's number 1, set as follows. SW500 Setting communication Protocol Use number 5~8 PIN of SW501 to set communication Protocol. A : SAMSUNG(SSC-1000)HALF PIN5 PIN6 PIN7 PIN8...

  • Page 14: Setting Rs-422A/Rs-485 Termination

    Setting RS-422A/RS-485 termination SW 501 As it is shown in the structure map, when Controller and RS-422A/RS-485 is connected it should be terminated according to the Cable feature of impedance on the each end of the transmitting line to transfer the signals in long distance by controlling the reflection of the signals to the lowest.

  • Page 15: Switch Setting

    SWITCH SETTING Receiver Address SW500-1 SW500-2 SW500-3 SW500-4 SW500-5 SW500-6 SW500-7 SW500-8 1-12...
  • Page 16 Receiver Address SW500-3 SW500-4 SW500-5 SW500-6 SW500-7 SW500-8 SW500-1 SW500-2 1-13...
  • Page 17 Receiver Address SW500-1 SW500-2 SW500-3 SW500-4 SW500-5 SW500-6 SW500-7 SW500-8 1-14...
  • Page 18 Receiver Address SW500-1 SW500-2 SW500-3 SW500-4 SW500-5 SW500-6 SW500-7 SW500-8 1-15...
  • Page 19 Receiver Address SW500-1 SW500-2 SW500-3 SW500-4 SW500-5 SW500-6 SW500-7 sw500-8 1-16...

  • Page 20: Chapter 2 Scc-643(P) Installation

    Chapter 2 SCC-643(P) Installation In this chapter, we will check the contents of the package before installing the SCC-643(P), and prepare a power adapter suitable for the power supply system. (Power Consumption: 18W; Voltage: 24VAC, 1.5A) Then, we will install the SCC-643(P) and connect the cables.

  • Page 21: Before Installing

    Before Installing Checking Package Contents Please check that all components listed below are included in the package: SCC-643(P) Bracket anchor Owner’s Instructions Screws Camera Holder Cover Body...

  • Page 22: Preparing The Cables

    To install and use the SCC-643(P), the following cables should be prepared. Power Adapter Cable The cable that plugs into the SCC-643(P) power input receptacle has the rated voltage of 24VAC, 1.5A. Check the rated voltage before using the cable.

  • Page 23: Cable Connection

    Cable. Use a driver to screw one part of the two lines of Power Adapter to Power Input Terminal of the SCC-643(P). 4. Adjust the switch below the Power Adapter to the proper voltage. Then, connect the Power Adapter's plug to the Power Connector.

  • Page 24: Installing Scc-643

    Installation Precautions 1) Make sure that the installation site can sufficiently support a minimum of four times the net weight of the SCC-643(P) Combi Dome Camera and other accessories. 2) Install in an area where the space above the ceiling board is over 18 cm (7 in.) high.
  • Page 25 3) INDOOR HOUSING (SHG-120) This housing is used for installing the Combi Dome Camera to an indoor wall or a ceiling. 4) OUTDOOR HOUSING (SHG-220) This housing is used for installing the Combi Dome Camera to an outdoor wall or a ceiling.
  • Page 26 5) CEILING MOUNT ADAPTOR (SADT-100CM) This adaptor is used for installing the indoor housing or the outdoor housing for the Combi Dome Camera to a concrete ceiling. 6) POLE MOUNT ADAPTOR (SADT-100PM) This adaptor is used for installing the WALL MOUNT ADPATOR (SBR-100WM) to a pole that is over 7 cm (2.76 in.) in diameter.

  • Page 27: Installing The Camera

    Installing the Camera 1. [Figure 1] Install the structure on the ceiling. (Refer to Installation reference for the Length of the structure) * Built in by the builder of the structure [Figure 1] Length of ceiling Hole 2. Make a hole in the ceiling where the camera will be installed. (The hole should be about ø180) 3.
  • Page 28 5. [Figure 5] Match the [Figure 5] BRKT-ANCHOR and CAMERA ADAPTER and use 4screws (PH M4 x 8) to assemble them. CAMERA ADAPTER 6. [Figure 6] Match the 3 holes on the back of the CAMERA and the [Figure 6] CONNECTOR and turn it left about 15 degrees.

  • Page 29: Chapter 3 Setup Menu Overview

    Chapter 3 Setup Menu Overview In this chapter, we will look over the Setup Menu of the SCC-643(P), First we'll look over the overall structure of the Setup Menu, and then we'll look at the functions of each menu.

  • Page 30: Structure Of The Setup Menu

    Structure of the Setup Menu CAMERA CAMERA ID ON.../OFF V-SYNC INT/LINE... COLOR/BW COLOR/BW/AUTO... ZOOM SPEED 1/2/3/4 MOTION DET ON.../OFF EXIT QUIT/SAVE/PRESET VIDEO SET IRIS ALC.../MANU... SHUTTER OFF~1/1OK/AUTO/FIX OFF/LOW/HIGH WHITE BAL ATW/AWC/MANU... + / - SPECIAL ON.../OFF POSI/NEGA ON.../OFF MIRROR ON/OFF H-DTL V-DTL AUTO FOCUS...
  • Page 31 CAM RESET LANGUAGE ENGLISH EXIT QUIT/SAVE The diagram shown above illustrates the overall structure of the Setup Menu. In this section, a description of the Setup menu features will enable users of the SCC-643(P) to tailor it to their personal needs.

  • Page 32: Camera Set Menu

    CAMERA SET menu screen, select CAMERA ID to ON and press [Enter]. You will see the sub screen for deciding on the ID of the SCC-643(P). The Camera ID can have up to 12 alphanumeric characters, along with several special characters.

  • Page 33: Color

    COLOR/BW (CAMERA SET) In the COLOR/BW menu, you can switch ON or OFF the CAMERA ID IR (infrared) Filter. V-SYNC In low light conditions, IR Filter is turned OFF to the BW COLOR/BW AUTO... Mode and the sensitivity to low light increases to that of a ZOOM SPEED MOTION DET black and white camera.

  • Page 34: Zoom Speed

    ZOOM SPEED (CAMERA SET) In the ZOOM SPEED menu you can CAMERA ID select the speed of the ZOOM Key V-SYNC COLOR/BW AUTO... (Tele/Wide). ZOOM SPEED MOTION DET Use the [Left] or [Right] keys in the ZOOM SPEED menu to select EXIT QUIT the speed.

  • Page 35: Exit

    *Motion Detection function does not operate while handling slow SHUTTER, PRESET, SCAN, AUTO MODE(AUTO PAN, PATTERN) or MANUAL KEY (JOYSTICK, ZOOM, FOCUS, IRIS). EXIT The EXIT menu is used to quit the CAMERA SET (CAMERA SET) menu of the SCC-643(P) and return to the MAIN CAMERA ID MENU. V-SYNC COLOR/BW AUTO...

  • Page 36: Alc

    BLC (Submenu of the ALC menu) With conventional cameras, strong background lighting interferes with the clarity of objects, making them appear dark. In the SCC-643(P), setting the BLC (Back Light Compensation), submenu of ALC/MANU menu, will solve the problem of backlight and give you a clear screen.

  • Page 37: Manu

    SHUTTER In the SHUTTER menu, the high-speed Electric shutter and AUTO low speed shutter of the SCC-643(P) and the FIX low speed shutter can be set. The High speed Electric Shutter supports 7 different speeds from 1/100 to 1/10K of a second. The AUTO low speed shutter and FIX low speed shutter supports 12 different speeds from 2x to 128x magnifications.

  • Page 38: Agc

    If your press the left/right keys continuously, the speed will appear in the following order. Order © © © © © © 1/100(1/120) 1/250 1/500 1/1000 1/2000 © © © © © © 1/4000 1/10K AUTOX2 AUTOX4 AUTOX6 © © ©...

  • Page 39: Slow

    SLOW This enhances the resolution of a still image by selecting a low value for AGC GAIN and a slow speed for SHUTTER SPEED. (This is used mainly to monitor inanimate objects in dark places.) NORMAL This shows the normal picture by selecting a medium value for AGC GAIN and the normal speed for SHUTTER SPEED.

  • Page 40: White Bal

    WHITE BAL Lights are generally denoted as color temperatures and expressed in Kelvin (°K) units. The general light color temperatures are shown below. 10000°K Blue sky 9000°K Rainy 8000°K Cloudy 7000°K 6000°K Partly Cloudy Sunny 5000°K 4000°K Fluorescent lamp 3000°K Halogen lamp 2000°K Tungsten lamp...
  • Page 41 WHITE BAL The WHITE BAL menu insures that white is calibrated normally under any color temperature condition. When the WHITE BAL menu is set to the ATW mode, the white balance is automatically specified according to the color temperature. In the case of setting the WHITE BAL menu to AWC mode, pressing [ENTER] while having a white paper in front of the Camera will automatically set the white balance in accordance with the color temperature only one time.

  • Page 42: Special

    SPECIAL n the SPECIAL menu, POSI/NEGA, PIP, Mirror, and vertical and horizontal detail level can be adjusted. - POSI/NEGA: Video output signal is outputted normal/reverse. - PIP(Picture in Picture): When Digital Zoom is activated, the 1/16 minimized screen will be shown. - MIRROR: Reverse the video output signal horizontally.

  • Page 43: Auto Focus

    - MF: In MANUAL FOCUS MODE the user adjusts the Focus manually. - ONEAF : The ONEAF Mode performs Auto-focusing only when the SCC-643(P) stops after moving and when the SCC-643(P) is not moving it is same as MF mode.

  • Page 44: Preset

    3. PRESET This is the menu that user sets the PAN/TILT location, Zoom/Focus, and screen condition, so the camera can monitor the presetting area on demand. A total of 128 presets are available. Among the 128 PRESETS HOME POSITION, PRESET 1: ALARM1, PRESET 2: ALARM2, PRESET 3: ALARM3, PRESET 4: ALARM4,PRESET 5: set as special preset corresponding MOTION.

  • Page 45: Video Set

    POSITION SET... PRESET NO.0 From "POSITION SET..." press [ENTER] to get SET PAN/TILT into the PAN/TILT, FOCUS/ZOOM SET screen SET ZOOM/FOCUS to set the PAN/TILT location and FOCUS/ZOOM condition then press [ENTER] to return to a higher menu. VIDEO SET This is the screen setting function for each PRESET.

  • Page 46: Auto Mode

    4. AUTO MODE AUTO PAN and PATTERN functions are in AUTO MODE. AUTO PAN After selecting the locations of two points (PAN/TILT) of START and END, it loops continuously in the set up SPEED. (AUTO MODE) * * MAIN MENU * * AUTO PAN CAMERA...

  • Page 47: Pattern

    DIRECTION This sets up the movement direction of the START to END location (PAN location standard) "RIGHT " : "LEFT " : ENDLESS This is a 360-degree rotation function that stops for the DWELL TIME only in the START and END positions without running between the START and END positions.

  • Page 48: Alarm Set

    PATTERN can be set upto 3. Choose 1, 2, or 3 with the left or right key in the "PATTERN SET" and press [ENTER] to get into the PATTERN set up screen. From the moment "PATTERN 1 SET" is gone for 30 seconds, it memorizes the MANUAL movements and after 30 seconds it will return to a higher menu.

  • Page 49: Alarm Out

    ALARM OUT ALARM OUT Each ALARM input corresponds to one of the ALARM1 ALARM2 3 ALARM OUT. ALARM3 ALARM4 MOTION EXIT QUIT ALARM PATTERN This sets the operation of PATTERN movements when inputting ALARM. When the ALARM is working, it will stay in the ALARM PATTERN PRESET location corresponding the ALARM for ALARM1...

  • Page 50: Other Set

    6. OTHER SET HOME RETURN When there is no KEY input or other movement for a certain time, the camera moves to the HOME location automatically. The HOME location can be assigned from the HOME POSITION menu. (OTHER SET) * * MAIN MENU * * HOME RETURN 12HOUR ➜...

  • Page 51: Privacy Zone

    PRIVACY ZONE Pan/Tilt position and the size of Masking area can be set for up to 8 privacy zones. When shooting the areas where privacy zones are set, the relevant areas will be concealed from view to protect privacy. Privacy Zones can be set as follows: (OTHER SET) (PRIVACY ZONE MAP) HOME RETURN 12HOUR...

  • Page 52: Cam Reset

    PRIVACY ZONE SET 1 PRIVACY ZONE SET 1 ➜ SET PAN/TILT ... SET PAN/TILT ... ➜ SET AREA SET AREA [Enter] KEY Entering the [Down] KEY AREA Setup Mode SET LEVEL SET LEVEL EXIT QUIT EXIT QUIT To set the area, select "SET AREA" and then press the [Enter] key. With OSD showing "SET", use the [up, down, left, right] key to set the AREA size.

  • Page 53: Product Specifications

    Product specifications SCC-643 Contents Items Zoom lens single body COMBI DOME CAMERA Product Type - AC 24 ± 10% (60Hz ± 0.3Hz) Power Input - 18W Power Consumption - NTSC STANDARD COLOR SYSTEM Broadcasting Type - 1/4 inch IT CCD...
  • Page 54 Product specifications SCC-643P Contents Items Zoom lens single body COMBI DOME CAMERA Product Type - AC 24 ± 10% (50Hz ± 0.3Hz) Power Input - 18W Power Consumption - PAL STANDARD COLOR SYSTEM Broadcasting Type - 1/4 inch IT CCD Image Device - 752(H) x 582(V) Effective Pixels...
  • Page 55 Cautions • The copyright of the manual belongs to Samsung Electronics Co., Ltd. • Without the permission of Samsung Electronics it cannot be reproduced electronically, mechanically, audibly, or by any other method. • This manual will be modified according to product enhancements.
  • Page 56 Part : AB68-00321A Printed in Korea...
