Summary of Contents for Renault MEGANE E-TECH ELECTRIC 2024

Page 1 vehicle user manual...
Page 3 Welcome to your new electric vehicle This user manual contains the information required: – for you to familiarise yourself with your vehicle, to use it to its best advantage and to fully benefit from the all the functions and the technical developments it incorporates. –...
Page 4: Table Of Contents
CONTENTS Welcome to your new electric vehicle........4 Driving ................. 167 Exterior ................4 Starting, stopping the engine........167 Passenger compartment ..........6 Gear control ..............170 Driver's position ............... 8 Regenerative braking system ........174 Driving aids ..............10 Parking brake...............
Page 5 CONTENTS Headlights, lights: replacing bulbs ....... 373 Wiper blades: replacement.......... 376 Fuses ................378 Important recommendations........383 Operating faults ............385 Technical specifications ............ 389 Information about the vehicle ........389 Replacement parts and repairs ........396 Service sheets ............. 397 Anticorrosion check .............
Page 6: 4 - We L C O M E T O Y O U R N E W E L E C T R I C V E H I C L E
EXTERIOR 4 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 7 EXTERIOR 1. Electric windows �� 339 2. Rear view mirrors �� 146 3. Screen wiper, washer �� 161 �� 164 Demisting �� 331 4. Lights: operation �� 152 Lights: replacement �� 373 5. Tyres �� 361 6. Load �� 30 7.
Page 8: Passenger Compartment
PASSENGER COMPARTMENT 6 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 9 PASSENGER COMPARTMENT 1. Adjusting your driving position �� 81 2. Passenger compartment storage/fittings �� 343 3. Rear headrests �� 79 Rear bench seat �� 80 4. Transporting objects �� 347 5. Child safety �� 94 6. Front headrests �� 72 Front seats with manual controls ��...
Page 10: Driver's Position
DRIVER'S POSITION 8 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 11 DRIVER'S POSITION 1. Instrument panel �� 139 2. Trip computer controls �� 126 3. Gear control �� 170 4. Window wiper(s)/washer(s) control �� 161 �� 164 5. Multimedia screen �� 337 6. Heated seat(s) �� 72 7. Heating system/air conditioning �� 329 �� 325 8.
Page 12: Driving Aids
DRIVING AIDS 1 0 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 13 DRIVING AIDS – Driver correction devices and aids �� 197 – Lane departure warning �� 202 – Lane departure prevention �� 207 – Emergency lane departure prevention �� 214 – Active emergency braking �� 230 – Active emergency braking in reverse gear �� 258 –...
Page 14: Safety On Board
SAFETY ON BOARD 1 2 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 15 SAFETY ON BOARD 1. Front airbags �� 86 Deactivating the passenger's front airbag �� 115 2. Central airbag �� 91 3. Curtain air bags �� 91 4. Seat belts �� 81 5. Side air bags �� 90 We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e - 1 3...
Page 16: Identifying A Vehicle - Labels
IDENTIFYING A VEHICLE - LABELS 1 4 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 17 IDENTIFYING A VEHICLE - LABELS 1. Technical information for the emergency services �� 389 2. Vehicle identification number reminder �� 389 3. Tyre pressure labels �� 192 �� 361 4. Engine identification �� 390 5. Vehicle identification plate �� 389 We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e - 1 5...
Page 18: The Engine Compartment (Routine Maintenance)
THE ENGINE COMPARTMENT (ROUTINE MAINTENANCE) 1 6 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 19 THE ENGINE COMPARTMENT (ROUTINE MAINTENANCE) 1. Battery �� 355 2. Brake fluid �� 353 3. “400 volt” electrical circuit�� 20 4. Coolant �� 352 5. Screen washer fluid �� 353 6. Opening the bonnet �� 350 We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e - 1 7...
Page 20: Breakdown Recovery
BREAKDOWN RECOVERY 1 8 - We l c o m e t o y o u r n e w e l e c t r i c v e h i c l e...
Page 21 BREAKDOWN RECOVERY 1. Replacing windscreen wiper blade(s) �� 376 2. Puncture �� 364 Tools �� 368 3. Fuses �� 378 4. Rear towing point �� 369 5. Replacing rear light bulbs �� 373 6 Replacing the rear screen wiper blade �� 376 7.
Page 22: Getting To Know Your Vehicle
VEHICLE E-TECH 100% ELECTRIC (EV) Electric vehicles have special features, but operate in a similar manner to conventional vehicles. The main difference in electric vehicles is the exclusive use of electric energy instead of fuel, as used in convention vehicles. We therefore recommend that you read these instructions describing your electric vehicle carefully.
Page 23 G e t t i n g t o k n o w y o u r v e h i c l e - 2 1...
Page 24 VEHICLE E-TECH 100% ELECTRIC (EV) Introduction Electric vehicle schematic diagram 2 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 25 VEHICLE E-TECH 100% ELECTRIC (EV) 1 Electric charging connection (passenger side) 2 400 V traction battery 3 Electric motor 4 Orange electrical power cables 5 Secondary 12 V battery G e t t i n g t o k n o w y o u r v e h i c l e - 2 3...
Page 26 VEHICLE E-TECH 100% ELECTRIC (EV) – a "400 V" traction battery; Connected services – secondary 12 V battery. "400 V" traction battery Introduction This battery stores the energy neces Your electric vehicle has connected sary to operate the motor in your elec services that provide information and/ tric vehicle properly.
Page 27 VEHICLE E-TECH 100% ELECTRIC (EV) "400 V" electrical circuit Bad weather, flooded roads: The vehicle drive system Do not drive through floods in an electric vehicle us if the depth of water is es a direct voltage of ap above the lower edge of the proximately 400 volts.
Page 28 VEHICLE E-TECH 100% ELECTRIC (EV) Driver obstruction Your electric vehicle is On the driver's side, only silent. Before leaving it, use mats suitable for the with your foot on the vehicle, attached with brake, stop the engine. the pre-fitted components, and RISK OF SERIOUS INJURY check the fitting regularly.
Page 29 VEHICLE E-TECH 100% ELECTRIC (EV) Important recommendations Please read these instructions carefully. Failure to follow these instructions may lead to a risk of fire, serious in jury or electric shocks which could result in death. In the event of an accident or impact In the event of an accident or an impact to the underside of the vehicle (e.g.
Page 30 VEHICLE E-TECH 100% ELECTRIC (EV) Risk of electric shock and a risk to life. 2 8 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 31 G e t t i n g t o k n o w y o u r v e h i c l e - 2 9...
Page 32: Schematic Diagram
VEHICLE E-TECH 100% ELECTRIC (EV) Charging Schematic diagram 3 0 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 33 VEHICLE E-TECH 100% ELECTRIC (EV) 1 Specific wall socket or recharging terminal 2 Charging cable 3 Electric charging connection (passenger side) If you have any questions regarding the equipment needed for charging, please ask an authorised dealer. Important recommendations for charging your vehicle Please read these instructions carefully.
Page 34 VEHICLE E-TECH 100% ELECTRIC (EV) Charging lead B Charging lead A Before cleaning the charg ing lead, make sure the lead is disconnected. Clean the cable using a cloth slightly dampened with water. When cleaning, make sure that the cloth does not come into con tact with the ends of the cable (connectors, charging pins) to avoid any risk of corrosion.
Page 35 VEHICLE E-TECH 100% ELECTRIC (EV) In all cases, read the charging lead B user instructions carefully. Never leave the socket hanging by the cord. Use the hooks C to hang it. If a malfunction occurs dur ing the charging process (red warning light appears on the unit D ), stop charging im...
Page 36 VEHICLE E-TECH 100% ELECTRIC (EV) Important recommendations Important recommendations for charging your vehicle Please read these instructions carefully. Failure to follow these instructions may lead to a risk of fire, serious in jury or electric shocks which could result in death. Choice of charging cord The standard charging cords supplied with the vehicle have been designed specifically for this vehicle.
Page 37 G e t t i n g t o k n o w y o u r v e h i c l e - 3 5...
Page 38 VEHICLE E-TECH 100% ELECTRIC (EV) Charging types that conform to Eu ropean standards 3 6 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 39 VEHICLE E-TECH 100% ELECTRIC (EV) If the information is displayed on the Alternating current (AC) vehicle charging flap, follow the in structions below. Before plugging in a charging lead, check that: – the colour and one of the letters of the input socket 1 correspond to the colour and one of the letters on the end 4 of the lead;...
Page 40 VEHICLE E-TECH 100% ELECTRIC (EV) Labels Charging type Alternating current (AC) Charging terminal 1 /Charging ca Connection Vehicle 3 /Charging cable 5 ble 4 Charging types that conform to European standards (for all other cases, please consult an approved dealer). 3 8 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 41 G e t t i n g t o k n o w y o u r v e h i c l e - 3 9...
Page 42 VEHICLE E-TECH 100% ELECTRIC (EV) Direct current (DC) If the information is displayed on the vehicle charging flap, follow the in structions below. Before plugging in a charging lead, make sure that the colour and one of the letters on the inlet socket 3 corre spond to the colour and one of the let...
Page 43 VEHICLE E-TECH 100% ELECTRIC (EV) Labels Charging type Direct current (DC) Connection Vehicle 3 /Charging cable 5 Charging types that con form to European standards (for all other cases, please consult an approved dealer). G e t t i n g t o k n o w y o u r v e h i c l e - 4 1...
Page 44 VEHICLE E-TECH 100% ELECTRIC (EV) cle for more than one month with high – the button 6 unlocks the Electric charging socket 3 charge, especially when the weather is charging cable; very hot. Favour charging the traction battery af – The button 7 launches imme...
Page 45 VEHICLE E-TECH 100% ELECTRIC (EV) Depending on the vehicle, Do not use the charging If fast-charging the vehicle when the charging flap is flap 8 to hang the charging (DC), the charging cable open or not properly lead 2 while recharging the between your vehicle and closed, the "Charging flap open"...
Page 46 VEHICLE E-TECH 100% ELECTRIC (EV) You do not need to wait until the The traction battery charg charge is at reserve levels to recharge your vehicle. ing time depends on the amount of energy remain Operating faults ing and the power delivered by If the warning light 9 is illuminated the charging terminal.
Page 47 VEHICLE E-TECH 100% ELECTRIC (EV) Label 13 – flashes in green: when Vehicle to Grid (V2G) �� 47 or Vehicle to Load It is imperative to follow the (V2L) �� 47 is enabled; unplugging steps in order. – when it lights up continuously in red this indicates an operating fault.
Page 48 VEHICLE E-TECH 100% ELECTRIC (EV) – close the flap again once discon nected; For safety reasons, carry – connect to a domestic socket, an al out these operations ternating current charging terminal or a when the vehicle is sta quick charging terminal; tionary.
Page 49 VEHICLE E-TECH 100% ELECTRIC (EV) Vehicle to Grid (V2G) charging Important recommendations The system provides AC power (up to 16 A/3.7 kW) using electrical energy Depending on the vehicle, with the ve stored in your vehicle's traction bat hicle stationary and connected using tery ��...
Page 50 VEHICLE E-TECH 100% ELECTRIC (EV) Do not place metal objects on the Take care of the V2L connector. – devices whose initial recom V2L connector. Do not disassemble it, immerse it mendations for use are not adapt Do not modify or interfere with the in water or pull on it while it is ed to the environment in which V2L connector while using the...
Page 51 VEHICLE E-TECH 100% ELECTRIC (EV) 2 Operation warning light; You must observe the order 3 On/Off switch; in which the V2L connector 4 Protective cover; is connected/disconnected. 5 AC output socket. The V2L connector is stored in the toolkit located underneath the luggage Before connecting or dis...
Page 52 VEHICLE E-TECH 100% ELECTRIC (EV) function is activated, the indicator light – an electrical device exceeding the discharging. The indicator light 2 goes on the charging socket 10 flashes in maximum power capacity is connect out, the indicator light on the green and the electrical device is sup...
Page 53 VEHICLE E-TECH 100% ELECTRIC (EV) Settings be displayed on the instrument panel: disconnect the electrical device and disconnect the V2L connector. Consult an approved Dealer. In the event of a failure of the V2L function from the device connected to the AC socket of the V2L connec tor, the "V2L discharge impossible Connected device fault"...
Page 54: Card
CARD – automatically closing the electric Note: if a door or the luggage com windows remotely �� 65; General information partment door is open or not properly – automatically opening the electric shut, the vehicle will not be locked. A windows remotely ��...
Page 55 CARD Fitting a hand strap 7 the vehicle from a distance when Interference parked in a car park. Press and hold Interference by factors in the immedi button 4 for approximately two sec ate vicinity (external installations or the onds to switch on the exterior lighting use of equipment operating on the and emit a sound.
Page 56 CARD Insert the hand strap into the compo nent 8 and pass the end of the strap Do not store the card any Driver's responsibility through the buckle. where it may come into when parking or stop Position the strap at the opening 6 and contact with other electron...
Page 57 CARD "Handsfree" unlocking when ap "Hands-free" locking when moving proaching the vehicle away from the vehicle If the card has been within the detec tion zone 1 for approximately 15 min utes, remote locking is deactivated. To With the card in the access zone 1 , With the card on you and the doors lock the vehicle, press the button 3 on the vehicle will be unlocked.
Page 58 CARD "Hands-free" unlocking by opening the – if the card remains close to vehicle Using the card as a remote control zone 1 during approximately five min luggage compartment utes after the vehicle has been locked; – after several passes in the vicinity of zone 1 without the doors having been unlocked.
Page 59 CARD The front handles fold in and the haz While the engine is running, if the card is no longer in zone 2 after a door ard lights and side repeaters flash Driver's responsibility twice to indicate that the doors have is opened and closed, the "Keycard when parking or stop...
Page 60 CARD Card: deadlocking Locking is confirmed by two slow When the "Keycard Battery Low" mes flashes and three quick flashes of sage appears on the instrument panel, the hazard warning lights and side in replace the card battery: dicator lights. –...
Page 61 CARD Operating faults Note: when replacing the battery, do not touch the electronic circuit or con Precautions relating to If the battery is too weak to ensure cor tacts on the card. batteries: rect operation, you will still be able to start and lock/unlock the vehicle ��...
Page 62: Digital Key
DIGITAL KEY General information Secure access to the digi The digital key's operational tal key on the smart reach will depend on your Depending on the country and sub phone smartphone's Bluetooth® scription, you can install a digital key It is the responsibility of the owner connection.
Page 63 DIGITAL KEY the internet throughout the procedure seconds for the vehicle to identify the when parked in a crowded car park, for (via Wi-Fi or mobile networks); digital key installed on your smart example); – the occasional user's digital key is –...
Page 64 DIGITAL KEY To start/stop the engine, the system mobile network) at least once every 48 checks that the smartphone is present hours. Otherwise, connect your smart in the placement area 1 before allow phone to the internet for a few minutes ing the engine to be started.
Page 65: Doors And Opening Elements
DOORS AND OPENING ELEMENTS end A of the handle 1 using your fin Opening and closing the doors ger. Rear doors Opening from the outside Front doors The front doors are equipped with han dles that fold out and in automatically according to the vehicle status: –...
Page 66 DOORS AND OPENING ELEMENTS Opening from the inside Lights-on reminder buzzer Child safety A warning beep sounds when the driver's door is opened to warn you that the lights are still on. Door or luggage compartment lid open buzzer When the vehicle is stationary, the warning light appears on the in...
Page 67 DOORS AND OPENING ELEMENTS Access with key 2 – the vehicle is located in a high elec Driver's responsibility tromagnetic radiation zone; – vehicle locked using a digital key when parking or stop �� 60. ping the vehicle It is then possible: Never leave an animal, child or adult who is not selfsuffi...
Page 68 DOORS AND OPENING ELEMENTS Using the key integrated in the Locking the doors manually Interior locking/unlocking door con card trol With the door open, turn the screw 4 Move the lock cover 3 by pressing the (using the end of the key) and close The switch 5 simultaneously controls left part and insert the key 2 into the the door.
Page 69: Automatic Locking When Driving
DOORS AND OPENING ELEMENTS Door and tailgate status indicator When the door is closed, all the doors Automatic locking when driving and tailgate will be locked. With the ignition on, the switch 5 Operating principle Note: unlocking the vehicle from the warning light indicates the locking sta...
Page 70: Luggage Compartment
DOORS AND OPENING ELEMENTS Activating/deactivating the function Closing Driver's responsibility To activate it: with the vehicle station Lower the luggage compartment lid, If you decide to keep the ary and the engine running, press depending on the vehicle, initially us doors locked when you switch 1 for at least five seconds until ing the inside handle to assist you.
Page 71 DOORS AND OPENING ELEMENTS Charging lead storage tray – access the luggage compartment by folding down the rear bench If there is water in the seatback(s); charging lead storage – insert a flat-blade screwdriver or tray, signs of corrosion similar tool at the emergency opening or foreign bodies in the lever 2 and slide it to the left as shown charging lead connector or in the...
Page 72 DOORS AND OPENING ELEMENTS Rear parcel shelf – lower the rear headrests; – unhook the two suspension cords 4 ; – lift the shelf 5 to unclip it; Maximum weight on the rear parcel shelf: 2 kg evenly distributed. – push the shelf 5 inwards and turn it; –...
Page 73: Facial Recognition
FACIAL RECOGNITION The prestored settings will then be ac tivated (driving position, phone con nection, calendar, etc.). If the face image is not recognised by the camera during recognition, the sys tem suggests the last profile used. Note: make sure that the camera is not obscured (by dirt, mud, etc.).
Page 74: Front Seats
FRONT SEATS To remove the headrest Front headrests The headrest is an im Raise it to its highest position (tilt the portant safety compo seatback backwards). Press the button To raise the headrest nent: ensure that it is in 2 and lift the headrest to release it. place and in the correct To refit the headrest position.
Page 75 FRONT SEATS Raise the handle 1 to unlock. Release Heated seats the handle at the desired position and For safety reasons, carry make sure that it is locked. out any adjustments while the vehicle is sta Adjusting the lumbar support on the tionary.
Page 76 FRONT SEATS Front seats with electric controls Adjusting the seat position – a third press decreases the heating to minimum power. One integrated Use switch 1 to access the "Seats" To move the seat forwards or back warning light is illuminated; menu on the multimedia screen.
Page 77 FRONT SEATS Heated seats For safety reasons, carry out any adjustments while the vehicle is sta tionary. We would advise you not to re cline the seatbacks too far to en sure that the effectiveness of the seat belts is not reduced. Nothing should be placed on the floor (area in front of the driver) as these objects may slide under the...
Page 78 FRONT SEATS Functions Press and hold the switch A of the seat for which you would like to acti vate the "Lumbar activated" function, according to the defined parameters. Settings Refer to the multimedia instructions for information on accessing the settings. You can activate or deactivate the fol...
Page 79 FRONT SEATS Storing your driving position The seats move automatically. You can interrupt the movement by pressing – Adjust the driver's seat using buttons one of the seat adjustment buttons 3 , 3 , 4 and 5 �� 74; 4 and 5 . –...
Page 80 FRONT SEATS the multimedia screen to ask if you would like to activate the position. Dur ing activation, you can access the "Re lax position" settings; For further information on the "Relax position", please refer to the multime dia instructions. Before using "Relax po...
Page 81: Rear Seats
REAR SEATS Headrest folding position 2 Rear headrests Press button 1 and lower the headrest completely. To raise the headrest Position for use Lift the headrest fully until it locks. Check that the bonnet is correctly When the headrest is set at the low locked.
Page 82 REAR SEATS Rear bench seat: functions Pull the paddle 1 and lower seatback When refitting the seat Functions back, make sure it is Note: for safety reasons, the seatback A is equipped with a retaining system. correctly locked in place. You may experience resistance when If seat covers are fit...
Page 83: Seat Belts
SEAT BELTS Adjusting the seat belts Always wear your seat belt when trav Make sure that the rear elling in your vehicle. You must also bench seat �� 80 is locked comply with the legislation of the par ticular country you are in. in position correctly so that the rear seat belts will operate Before starting, first adjust your dri...
Page 84 SEAT BELTS The seat belt must be worn as close to – symbol in red: the seat is occupied Seat belt reminder warning the body as possible. e.g. avoid wear and the seat belt is not fastened; lights ing heavy clothing, keeping bulky ob –...
Page 85 SEAT BELTS – the graphic 6 is displayed for ap button 7 and raise or lower the seat proximately 180 seconds and the sym belt. Make sure that the seat belt is Check that the rear seat bol for the seat concerned changes to locked in position correctly after you belts are positioned and red.
Page 86 SEAT BELTS Warnings The following information applies to the vehicle’s front and rear seat belts. – No modification must be made to the originally-fitted restraint system components (seat belts, seats and their mountings). For special operations (e.g. fitting child seats) please contact an approved dealer. –...
Page 87: Additional Safety Devices
ADDITIONAL SAFETY DEVICES Pretensioners Methods of restraint in addition – Have the entire re to the front seat belts straint system checked following an accident. They consist of: – No operation whatsoever is per – seat belt inertia reel pretension mitted on any part of the system ers;...
Page 88 ADDITIONAL SAFETY DEVICES Driver and passenger front airbags Fitted to the driver and passenger sides. A symbol on the lower section of the windscreen indicates if this equipment is present (depending on the vehicle). Each airbag system consists of: – an airbag and gas generator fitted on the steering wheel for the driver and in the dashboard for the front pas...
Page 89 ADDITIONAL SAFETY DEVICES If it does not come on when the igni tion is switched on or if it stays on, there is a fault in the system. Contact your approved Dealer as soon as possible; Your protection will be reduced until this fault is rectified.
Page 90 ADDITIONAL SAFETY DEVICES – side impact at the front or rear of the The pretensioners or Airbags may The pretensioners or Airbags may be triggered by: not be triggered by: vehicle; – frontal impact, underneath the tail of – an impact underneath the vehicle –...
Page 91 ADDITIONAL SAFETY DEVICES Warnings Warnings in relation to the driver's airbag – Do not modify the steering wheel or the boss. – Do not cover the steering wheel boss under any circumstances. – Do not attach any objects (badge, logo, watch, telephone cradle, etc.) to the steering wheel boss. –...
Page 92 ADDITIONAL SAFETY DEVICES Side seat belt pretensioners Methods of restraint in addition – Have the entire re to the rear seat belts straint system checked following an accident. They consist of: – Any operation on the entire sys – side seat belt inertia reel preten tem (pretensioners, airbags, elec...
Page 93 ADDITIONAL SAFETY DEVICES Curtain airbag This airbag fitted in the ceiling along each side of the vehicle. They inflate along the front and rear door side win dows to protect the passengers in the event of a severe side impact. Central airbag This airbag fitted to the driver's seat and deployed between the driver's...
Page 94 ADDITIONAL SAFETY DEVICES Warnings Warning relating to the passengerairbag side airbag and theairbag central airbag – Fitting seat covers on the front seats is prohibited as this could hinder the operation of the passenger airbag status. – Do not place any accessories, objects or even pets between the seatback, the door and the internal fittings. Do not cover the seatback with objects such as clothes or accessories.
Page 95 ADDITIONAL SAFETY DEVICES Additional methods of restraint All of the following warnings are provided to avoid interference with the deployment of the airbag and to avoid direct serious injury due to objects being projected when it is inflated. The front passengerairbag is designed to complement the action of the seat belt, and theairbag and seat belts are integral parts of the same protection system.
Page 96: Child Safety
CHILD SAFETY General information A collision at 31 mph (50 Driver's responsibility km/ h ) is the same as when parking or stop Carrying children falling a distance of 10 ping the vehicle metres. Never leave an animal, Please ensure that you comply with Transporting a child without a re...
Page 97 CHILD SAFETY proved Dealer to find out which seats are recommended for your vehicle. Set a good example by al Never leave a child unat ways fastening your seat tended in the vehicle. The regulations on transporting chil dren are specific to each country. The belt and teaching your Check that your child is use of a child seat during transport de...
Page 98 CHILD SAFETY Forward-facing child seats Booster cushions Choosing a child seat Rear-facing child seats Up to 18 kg or 4 years, the child may From 15 kg or 4 years, the child can travel on a forward-facing seat. travel using a booster seat, which will Choose your seat according the child's enable the seat belt to be adapted to A baby’s head is, proportionally, heav...
Page 99 CHILD SAFETY Choosing a child seat mounting seat i-Size, the role of which is to The seat belt must never prevent the child seat from moving There are two ways to attach child in the event of a collision. be twisted or the tension seats: using the seat belt or using the relieved.
Page 100 CHILD SAFETY The ISOFIX anchorage points have been exclu sively designed for child seats with the ISOFIX system. Never fit a different type of child seat, seat belt or other objects to these fittings. Check that nothing is obstructing the anchorage points. If your vehicle has been involved in a road accident, have the ISOFIX anchorage points...
Page 101 CHILD SAFETY The ISOFIX anchorage points have been exclu sively designed for child seats with the ISOFIX system. Never fit a different type of child seat, seat belt or other ob jects to these fittings. Check that nothing is obstructing the anchorage points.
Page 102: Child Seats
CHILD SEATS ent child seat, check with the manufac Fitting a child seat, general in turer that it can be fitted. RISK OF DEATH OR formation SERIOUS INJURY: be In the front seat fore fitting a rear-facing Some seats are not suitable for fitting child seat on the front The laws concerning children travelling child seats.
Page 103 CHILD SEATS – move the seat in which the child will be seated as far back as possible; Installing a booster A child seat with a floor – Move the seat in front of the child seat (group 2 or 3) support must never be forwards, and set the position of the Check that the seat belt...
Page 104 CHILD SEATS Attachment by seat belt Fitting diagram 1 0 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 105 CHILD SEATS RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check that the airbag has been deactivated: – Before installing the seat in vehicles equipped with an airbag �� 115 deactivation/activation lock; –...
Page 106 CHILD SEATS Do not fit a child seat when the large seat back is in the folded position. 1 0 4 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 107 G e t t i n g t o k n o w y o u r v e h i c l e - 1 0 5...
Page 108 CHILD SEATS Installation table The table below summarises the information already shown on the diagram on the previous page, to ensure the regula tions in force are respected. Front passenger seat (7) Weight of the Rear side seats Rear centre Type of child seat With airbag de...
Page 109 CHILD SEATS U = Seat enabling a child seat with "Universal" approval to be attached by seat belt: check that it can be fitted. B2 = Boosters in groups 2 and 3 (15 to 25 kg and 22 to 36 kg/33.1 to 55.1 lbs and 48.5 to 79.4 lbs). (2) A carrycot can be installed across the vehicle and will take up at least two seats.
Page 110 CHILD SEATS Attachment using the ISOFIX system Fitting diagram 1 0 8 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 111 CHILD SEATS For the front passenger seat, the use of a child seat with a floor support is recommended to avoid triggering the seat belt warning signal. Using a child safety system which is not approved for this vehicle will not properly protect the baby or child. They risk serious or even fatal injury.
Page 112 CHILD SEATS The front and rear seats are equipped with an anchorage point allowing an ISOFIX universal forward-facing child seat to be attached. The anchoring points are located on the passenger seatback for the front seat and on the bench seatback for the rear seats.
Page 113 G e t t i n g t o k n o w y o u r v e h i c l e - 111...
Page 114 CHILD SEATS Installation table The table below summarises the information already shown on the diagram on the previous page, to ensure the regula tions in force are respected. Front passenger seat (7) Weight of the Size of seat Rear side Rear centre With airbag With airbag...
Page 115 CHILD SEATS IUF-IL = Seat enabling a child seat with "Universal/Semi-universal or vehicle-specific" approval to be attached by ISOFIX (on equipped vehicles): check that it can be fitted. i-U = Suitable for "Universal" front-facing and rear-facing i-Size restraint devices. i-UF = Suitable only for "Universal" front-facing and rear-facing i-Size restraint devices. (1) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check that the airbag has been deactivated: –...
Page 116 CHILD SEATS (7) Deactivate the "Easy Access Seat" function before installing a child seat on the front passenger seat and/or on the rear seats �� 76. Risk of injury. 11 4 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 117: Child Safety: Deactivating, Activating The Front Passenger Airbag
CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG Child safety: deactivating, acti For vehicles not equipped The passenger airbag with a lock 1 �� 117. vating the front passenger may only be activated or airbag deactivated when the vehicle is stationary Front passenger airbag deactiva...
Page 118 CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG Activation of the front passenger airbag The markings on the dashboard and the labels A on each side of the pas DANGER senger sun visor 3 (see example of la As the deployment of the bel above) are provided to remind you front passenger airbag is of these instructions.
Page 119 CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG ferent types of seats �� 96 and the You should reactivate the airbag as methods for installing them �� 115. soon as you remove the child seat Activation or deactivation from the front passenger seat to en of the passengerairbag To find out the type of child seat autho...
Page 120 CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG the warning light stays on for approxi mately 65 seconds. After the initialisation phase, if the sys tem detects a change of status (e.g. passenger seat occupied when the ig nition is switched on, then not occu pied), the following messages are dis...
Page 121 CHILD SAFETY: DEACTIVATING, ACTIVATING THE FRONT PASSENGER AIRBAG A wet seat may affect the effectiveness Never switch off the igni DANGER of the passenger detection system. If the front passenger seat is wet, dry it tion before the vehicle After fitting a rear-facing immediately.
Page 122 1 2 0 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 123 G e t t i n g t o k n o w y o u r v e h i c l e - 1 2 1...
Page 124: Driving Position
DRIVING POSITION Driving position: left-hand drive 1 2 2 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 125 DRIVING POSITION 16. USB-C ports in the centre – lighting dimmer for control instru The fittings described below DE console. ments; PEND ON THE VEHICLE VERSION – the "My Safety" function AND COUNTRY. 17. "Hands-free" card holder. – activation/deactivation of the "Lane 1.
Page 126 DRIVING POSITION Driver’s position, righthand dri 1 2 4 - G e t t i n g t o k n o w y o u r v e h i c l e...
Page 127 DRIVING POSITION The fittings described below DE 21. Accessories socket. PEND ON THE VEHICLE VERSION 12. Controls for: 22. Cup holder. AND COUNTRY. – activating/deactivating the electronic 23. USB-C ports in the centre 1. Side air vents. parking brake; console. –...
Page 128: Trip Computer
TRIP COMPUTER Repeatedly press upwards/downwards the energy consumed on the electric General information on the switch 1 to browse between counter. these functions. Interpreting some of the values Trip computer and warning system From the instrument panel A : displayed after resetting a) trip settings: The values showing average energy –...
Page 129 TRIP COMPUTER Resetting the estimated range After the traction battery has been fully recharged, you can select two types of resetting: manual or automatic. Manual reset Select the trip setting to reset, then press and hold the switch 1 to reset the range.
Page 130 TRIP COMPUTER Journey settings The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY Examples of selections Interpreting the display selected a) Trip settings. Current energy consumption. + 13,4 Average energy consumption. The value is displayed after having travelled at least 400 metres since the last re 12,8 set.
Page 131 TRIP COMPUTER Examples of selections Interpreting the display selected – when a service is due, the "Service due" message is displayed accompanied by the first limit (distance or time); – range equal to 0 miles (0 km) or date of service reached: the message "Ser vice Required"...
Page 132: Information Messages
TRIP COMPUTER Information messages These can help in the vehicle starting phase, or give information about a selection or a driving status. Examples of information messages are given in the following pages. Examples of messages Interpreting the display selected "Disconnect the cable to start" Indicates that the charging cable is still plugged into the vehicle.
Page 133 TRIP COMPUTER Operating fault messages They appear along with the warning light and indicate that you should drive very carefully to an approved dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.
Page 134: Warning Messages
TRIP COMPUTER Warning messages They appear along with the warning light and indicate that for your own safety you must stop immediately, as soon as traffic conditions allow. Stop your engine and do not restart it. Call an approved Dealer. Some examples of warning messages are given below.
Page 135: Displays And Indicators
TRIP COMPUTER All of the available views display the Displays and indicators following essential information on the instrument panel: Instrument panel A – speedometer; – the information on the activated dri ving aids; – information area. Only while the vehicle is charging, the "Charge"...
Page 136 TRIP COMPUTER Information display Power meter 5 . Total mileage recorder 6 . Regenerative braking level warning light 8 . Battery information 9 (traction bat tery charging rate, estimated range). Speedometer 2 . The vehicle speed is limited to approxi mately 93 mph (150 km/h) (or 99 mph (160 km/h) depending on the vehicle).
Page 137 TRIP COMPUTER This comes on when the charging ca ble is plugged into the vehicle. Charge level 12 The gauge indicates the level of ener gy remaining. Remaining charging time 13 Traction battery charge rate 14 Reserve threshold Depending on the vehicle, when the traction battery charge reaches ap...
Page 138 TRIP COMPUTER Instrument panel in miles Please refer to the multimedia instruc Vehicle settings personalisation tions for more information. menu To use certain driving aid functions, it is necessary to change the unit of mea surement on the instrument panel in order to obtain the appropriate information when driving in a country where the speed units dif...
Page 139 TRIP COMPUTER Adjusting the settings ed (e.g. for the "Follow me home" func – heated seats; tion). – heated steering wheel; Select a tab then the function to be – setting selection (access, welcome, Please refer to the multimedia instruc modified (the display depends on the lighting, wiper, etc.);...
Page 140 TRIP COMPUTER Exterior temperature indicator Clock and outdoor temperature Special feature: Setting the time When the outside temperature is be tween -3°C and +3°C, the °C figures flash (this indicates a risk of ice forma tion). If the power supply is cut (battery disconnected, sup...
Page 141: Warning Lights
WARNING LIGHTS The display of information shown If no lights or sounds are below DEPENDS ON THE VEHICLE Warning light apparent, this indicates a EQUIPMENT AND COUNTRY. means you should drive fault in the instrument very carefully to an authorised panel.
Page 142 WARNING LIGHTS panied by a beep. recommendation, you risk damaging Bad weather warning light For your own safety, it requires you to your vehicle. stop immediately, as soon as traffic conditions allow. Switch off the engine "Adaptive Vision" lights mal Electrotechnical system and do not restart it.
Page 143 WARNING LIGHTS electrical assembly (traction battery Limited performance warning The "EVACUATE IN and electric motor). Contact your ap light proved Dealer straight away. SAFETY" message ac This appears when the traction battery companied by the warn temporarily does not deliver its nomi Electric motor fault warning nal power.
Page 144 WARNING LIGHTS light and a beep, it indicates that the Electronic Stability Program Speed limiter warning light fluid level in the circuit is low or that (ESC) and traction control system there is a braking system fault. unavailability warning light Stop as soon as traffic conditions allow Cruise control warning light and consult an approved Dealer.
Page 145 WARNING LIGHTS On the rear view mirror C (depending on the vehicle) Camera rear view function warning light �� 148 G e t t i n g t o k n o w y o u r v e h i c l e - 1 4 3...
Page 146: Steering
STEERING Activating the function Steering wheel For safety reasons, only With the ignition on, press the button 5 adjust the steering wheel on the multimedia screen 2 . Adjusting the steering wheel height when the vehicle is sta and depth tionary.
Page 147: Power-Assisted Steering
STEERING "Favourites" function the force needed to steer increases progressively as the speed rises (for enhanced safety at high speeds). Never switch off the igni tion when travelling downhill, and avoid do ing so in normal driving (power steering and brake servo will not function).
Page 148: Rear View
REAR VIEW Rear view mirrors For safety reasons, carry Objects observed in the out any adjustments rear view mirror glass Exterior rear view mirrors with while the vehicle is sta are actually closer than electrical adjustment: tionary. they appear. For your safety, take this into ac count in order to correctly assess Electrical folding mirrors the distance before any manoeu...
Page 149 REAR VIEW With the vehicle at a standstill and re The positions of the exterior rear view cle behind, shift the small lever 4 lo verse gear engaged, select the door mirrors in forward gear, reverse and of cated behind the rear view mirror. mirror using one of the switches 3 , the front seats are recalled.
Page 150: Camera Rear View
REAR VIEW Camera rear view This function is an addi Operating principle tional aid. It cannot, therefore, under any cir cumstances replace the vigilance or the responsibility of the driver. The driver should always be ready for sudden incidents while driving: always ensure that there are no small, narrow moving ob...
Page 151 REAR VIEW Operation Switching off the function Depending on your vision, an adaptation time may be necessary to focus on the camera view display. Objects which appear on the edge of the door mirror 2 may be distorted. In very bright light (snow, vehicle in sunshine, etc.), the camera view may be partially disturbed.
Page 152 REAR VIEW Use the lever 3 to switch between Press button 5 for "Menu" to access "mirror" mode and "screen" mode. the settings menu. For safety reasons, carry out any adjust The green LED 4 as well as the pic Repeatedly press buttons 6 and 7 to togram displayed at the top right of the scroll through the settings options.
Page 153 REAR VIEW screen 9 ) in addition to the information available through the rear view mirror �� 295 as there remains a rear view blind spot. Operating faults When the system detects an operating fault, the rear view mirror 2 turns black, the pictogram displayed at the top right of the rear view mirror...
Page 154: Lighting And Signals
LIGHTING AND SIGNALS gear lever is in the P position. Other Exterior lighting and signals wise, the "Unavailable position lights" message is displayed on the instru ment panel to inform you that it is not Daytime running lights possible to activate the side lights. Dipped beam headlights Manual operation Turn the ring 3 until the symbol is op...
Page 155 LIGHTING AND SIGNALS "Poor weather" function exterior light level, without any action pending on the steering wheel angle, on the stalk 1 . this function adapts the beam width to improve visibility on a bend or at a Depending on the vehicle, the dipped (depending on the vehicle) junction.
Page 156 LIGHTING AND SIGNALS Automatic main beam headlights – no other vehicle or lighting is detect the instrument panel and the main beam headlights will be activated. – the vehicle speed is above approxi mately 25 mph (40 km/h). The system may encounter If any of the above conditions are not difficulties under certain fulfilled, the system switches to dipped...
Page 157 LIGHTING AND SIGNALS Lights-on reminder buzzer Activating/deactivating the function Using a portable naviga For activation or deactivation of the ex If the lights are on after the engine is tion system at night in ternal welcome, refer to the multimedia switched off, a warning beep sounds the windscreen area be...
Page 158: Headlight Beam Adjustment
LIGHTING AND SIGNALS to any position, then return it to posi Warning light comes on the in tion AUTO. When driving in fog or strument panel. snow, or when transporting Note: if the Welcome and Goodbye function is activated, once the engine objects which are higher Operation of the fog lights depends on is switched off, the procedure for deac...
Page 159 LIGHTING AND SIGNALS the headlight beams according to the load. With the dipped beam headlights on, press or raise switch A as many times as required to select the required posi tion on the instrument panel. The posi tion selected is displayed on the instru ment panel for approximately 15 sec...
Page 160 LIGHTING AND SIGNALS Table of adjustment position examples Examples of positions for adjusting the control A according to the load Driver alone or with front passenger All seats occupied Driver with passengers and luggage (or load) reaching the maximum permissible all-up weight Driver without passengers and luggage (or load) reaching the maximum permissible all-up weight The table below gives some examples.
Page 161 LIGHTING AND SIGNALS half turn towards the + symbol to raise Temporary adjustment the beams. This can be adjusted using the multi media screen �� 136. Depending on the vehicle, the adjust ment must be carried out manually. Press or raise the switch A as many times as required to select position 0 on the instrument panel.
Page 162: Audible And Visual Signals
AUDIBLE AND VISUAL SIGNALS will return to its original position and Horn the direction indicator light concerned will flash three times. Hazard warning lights Press the steering wheel boss A to sound the horn. Headlight flasher Press the switch 2 . This switch To flash the headlights, pull the stalk 1 activates all four direction indicators towards you, then release.
Page 163: Wiper
WIPER Vehicle fitted with front windscreen Windscreen wash, wipe wiper rain sensor Vehicle fitted with intermittent windscreen wipers Special feature When driving the vehicle, the wiping speed slows down whenever the vehi The rain sensor is located on the wind cle stops.
Page 164 WIPER – damaged windscreen wipers: a film warning light appears on of water or traces left by a blade in the sensor's detection zone may increase the instrument panel to confirm that the response time of the automatic the function is activated. wiper, or increase the wiping frequen...
Page 165 WIPER Windscreen washer you may risk damaging both the blade and the wiper motor. Before any action involv – Do not activate the wipers on a dry ing the windscreen screen. This will lead to premature (washing the vehicle, de- wear or damage to the blades.
Page 166 WIPER Rear windscreen wash, wiper When working in the en Efficiency of a wiper Rear windscreen wiper gine compartment, en blade sure that the windscreen Check the condition of the wiper stalk is in position wiper blades. How long they last B (stop).
Page 167 WIPER Note: when washing using a roller with a vehicle settings customisation type car wash, return the ring 3 on the Efficiency of a wiper menu, you can opt to activate or deac tivate this function �� 136. stalk 1 to the stop position to deacti blade vate automatic wiping.
Page 168 WIPER a few seconds later, by a third (drip wiping function). When the stalk is released, it returns to the rear wipe position. Note: a rear washing action at stalk 1 lasting for more than 30 seconds may cause the windscreen washer pump to cut out.
Page 169: Driving
STARTING, STOPPING THE ENGINE Starting the engine During a system update via the multimedia system it will not be possible to start the vehicle. Wait for the update to be complet ed before starting the vehicle. For more information on system updates, please refer to the multi...
Page 170 STARTING, STOPPING THE ENGINE Operating faults area 3 (upper console A or lower con sole B , depending on the vehicle). Press the button 2 to start the vehicle. The message goes out. Stopping the engine "Handsfree" starting with the lug gage compartment open In certain cases, the "handsfree"...
Page 171 STARTING, STOPPING THE ENGINE With the engine switched off, any ac cessories being used (radio, etc.) will Driver's responsibility continue to function for approximately when parking or stop 45 minutes. ping the vehicle When the driver’s door is opened, the Never leave an animal, accessories stop working.
Page 172: Gear Control
GEAR CONTROL D: automatic mode Gear control, electronic lever B: depending on the vehicle, regener ation mode Electronic selector lever 1 P: parking, button 2 The gear engaged is displayed on the instrument panel as a reminder. One-touch selector Shift the selector lever 1 one or two notches upwards or downwards to the desired position (R, N, D or, depending on the vehicle, B) then release the...
Page 173 GEAR CONTROL To engage P position To disengage position P seconds and the "Press brake pedal" message is displayed on the instru With the vehicle stationary and the en ment panel for approximately five sec gine on, press the brake pedal and onds.
Page 174 GEAR CONTROL Move from D position to B or B to Parking the vehicle The next time the engine is restarted, position P is engaged automatically ac Position P is engaged automatically cording to the cases described earlier. (depending on the vehicle) and, if fitted, the electronic parking brake is applied when: To switch from one position to the oth...
Page 175 GEAR CONTROL An impact to the under side of the vehicle while manoeuvring (e.g. strik ing a post, raised kerb or other street furniture) may result in damage to the vehicle (e.g. de formation of an axle). To avoid any risk of accident, have your vehicle checked by an approved dealer.
Page 176: Regenerative Braking System
REGENERATIVE BRAKING SYSTEM Regenerative braking change Driving with paddles When releasing the accelerator pedal, paddles 1 and 2 the vehicle uses regenerative braking to slow down. Some of this energy is converted to electricity to recharge the traction bat tery. The paddles behind the steering wheel can be used to increase or decrease regenerative braking.
Page 177 REGENERATIVE BRAKING SYSTEM Activation The 3 warning light informs you of the until the "One Pedal activated" mes sage appears. The ONE PEDAL 3 regenerative braking level: warning light appears, accompanied – A : "Free-wheel" level for gentle, by a beep, to confirm that it is activat economical driving.
Page 178 REGENERATIVE BRAKING SYSTEM The function reactivates in D position the brake pedal, activating the elec beyond a certain speed threshold. The tronic parking brake or, depending on ONE PEDAL warning light appears in the vehicle, the handbrake. blue to confirm reactivation. Operating faults Note: the parking brake is applied au...
Page 179: Parking Brake
PARKING BRAKE Electronic parking brake The electronic parking brake can be used to im Assisted operation mobilise the vehicle. Be fore leaving the vehicle, check that the electronic parking brake is fully applied. Warning light 2 on switch 3 and warning on the instrument pan...
Page 180 PARKING BRAKE After the engine is switched off, the in Press the brake pedal then press the dicator light 2 goes out a few minutes switch 3 : the warning light 2 on the The electronic parking after the electronic parking brake has brake can be used to im...
Page 181: "Autohold" Function
PARKING BRAKE on "Manually releasing the electronic This means that you must stop as parking brake" on the previous page); soon as traffic conditions allow. Never leave your vehicle – depending on the vehicle, the park without moving the se ing brake is applied automatically.
Page 182 PARKING BRAKE The braking force is released as soon If the braking force is maintained, the as the driver accelerates sufficiently parking brake is applied automatically The electronic parking with a gear engaged. when: brake can be used to im –...
Page 183 PARKING BRAKE – the vehicle is not stationary on a very steep slope. The maintained braking force is con firmed by the warning light the instrument panel. Conditions for interrupting the brak ing force The following conditions must be met: –...
Page 184: Environment
ENVIRONMENT Recycling Manufacture Your vehicle is at least 85% recyclable Your vehicle has been designed with and at least 95% recoverable. respect for the environment in mind To achieve these objectives, many of for its entire service life: during its pro the vehicle components have been de...
Page 185: Driving Advice, Eco-Driving
DRIVING ADVICE, ECO-DRIVING Power meter "Energy consumption" C usage Eco-driving area The traction battery supplies the elec Driving advice, eco-driving trical energy required for the motor to move the vehicle. Range is accredited in according to a standard regulatory method. Identical for all manufacturers, this enables ve...
Page 186 DRIVING ADVICE, ECO-DRIVING ECO mode You can display the driving style indi ed when you take pressure off the ac cator by repeatedly pressing upwards/ celerator pedal. ECO mode is a function that optimises downwards on the switch 2 . vehicle range.
Page 187: Vehicle Range
DRIVING ADVICE, ECO-DRIVING Vehicle range Speed and driving style – keep an eye on the tools available to you to view the road conditions (charge meter, current consumption, Advice journey record, etc.)�� 183; In real usage, the range of an electric –...
Page 188 DRIVING ADVICE, ECO-DRIVING Heating levels Tyres The use of heating or air-conditioning An underinflated tyre increases ener reduces vehicle range. gy consumption. Comply with the specified tyre pressures for your vehi To maintain your vehicle range, we cle. recommend that you select the "pro gramming"...
Page 189: Tyre Pressure Monitoring System
TYRE PRESSURE MONITORING SYSTEM – when the standard tyre pressure needs to be changed to adapt to us age conditions (empty, carrying a load, motorway driving, etc.); – after swapping a wheel (however, this practice is not recommended); – after changing a wheel. It should always be done after check...
Page 190 TYRE PRESSURE MONITORING SYSTEM may remain after several successive restarts. For your safety, the Note: the tyre pressure reference val warning light ue cannot be less than that recom requires you to stop im mended and indicated on the edge of the door.
Page 191: Message Display
TYRE PRESSURE MONITORING SYSTEM Message display The table shows the possible messages related to the tyre resetting procedure. Steps Displays Readings With the ignition on and the vehicle stationary, to start resetting the pressure of all four tyres, press downwards and hold the switch 2 . The "---"...
Page 192 TYRE PRESSURE MONITORING SYSTEM Readjustment of tyre pressures Changing a wheel The system may take The pressure of the four tyres must several minutes depend be set when cold (refer to the label lo ing on use for the new cated on the edge of the driver's door).
Page 193 TYRE PRESSURE MONITORING SYSTEM Tyre pressure faults The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). The warning light for your own safety, it requires you to stop immediately as soon as traffic conditions allow. The table lists the warning messages which appear on the instrument panel 1 when the system detects a tyre pressure fault.
Page 194: Tyre Pressure Loss Warning
TYRE PRESSURE LOSS WARNING The system can be identified by the 1 shown on the tyre inflation pressure la bel (reference values) �� 363. label in the vehicle. Resetting should always be carried Operating principle out after checking the tyre pressure of all four tyres when cold.
Page 195 TYRE PRESSURE LOSS WARNING Resetting procedure via the A sudden loss of pressure multimedia screen 3 in a tyre (burst tyre, etc.) may not be immediately de tected by the system. Procedure for resetting the standard levels for the tyre pressures This should be performed: –...
Page 196 TYRE PRESSURE LOSS WARNING Message display The table below shows the possible messages related to the tyre resetting procedure. Steps Messages Readings Tyre pressure init. at stop The message is displayed during driving. If you want to reset the pressure of the four tyres, stop the vehicle.
Page 197 TYRE PRESSURE LOSS WARNING Tyre repair product and inflation pressure faults (e.g. deflated or Readjustment of tyre pressures punctured tyre). The pressure of the four tyres must Only use equipment approved by the be set when cold (refer to the label lo brand network, otherwise there is risk cated on the edge of the driver's of the system being activated late or...
Page 198 TYRE PRESSURE LOSS WARNING Fault message table Indicator lights Messages Readings This indicates that tyre underinflation or punc ture has been detected. Check and adjust the Inflate tyres and init. pressure of the four tyres when cold and reset comes on the system.
Page 199: Driver Correction Devices And Aids
DRIVER CORRECTION DEVICES AND AIDS You will feel a pulsation through the Depending on the vehicle, they com These functions are an brake pedal each time the system is prise: activated. The ABS does not in any additional aid in the –...
Page 200 DRIVER CORRECTION DEVICES AND AIDS panel accompanied by corrects the trajectory if necessary by the ESC and traction control system the "WARNING: Braking System" mes controlling the braking of certain are deactivated. sage: this indicates a fault with the wheels and/or engine power. In the Consult an approved dealer.
Page 201 DRIVER CORRECTION DEVICES AND AIDS – if you do not use the accelerator, the Hill start assistance system will not be triggered. The hill start assistance Depending on the gradient of the in system cannot complete Operating faults cline, this system assists the driver ly prevent the vehicle When the system detects an operating when starting on a hill.
Page 202 DRIVER CORRECTION DEVICES AND AIDS Operating principle Regenerative braking system The warning light When the airbag system detects a col When braking, the regenerative brak lision, the pretensioners or airbags are ing system can convert the energy pro for your own triggered ��...
Page 203: Additional Driving Aid Functions
ADDITIONAL DRIVING AID FUNCTIONS – overspeed sound alert �� 239; My Safety – lane departure prevention�� 207; Depending on the vehicle – driver vigilance warning �� 237; and on the length of time The "My Safety" function can be used –...
Page 204: Lane Departure Warning
ADDITIONAL DRIVING AID FUNCTIONS From the multimedia screen 2 Lane departure warning This function is an addi tional driving aid. This function is not under any circumstances intended to replace the due care and atten tion of the driver, who should at all times be in control of the vehicle.
Page 205 ADDITIONAL DRIVING AID FUNCTIONS Vehicle fitted with a switch 3 Vehicle fitted with switch 4 "Lane keeping system not configured" is displayed on the instrument panel. To deactivate the function, press the 4 switch or deselect "Lane departure warning" in the "Lane keeping system" menu.
Page 206 ADDITIONAL DRIVING AID FUNCTIONS Operation indicators turn to grey on the instru – the warning light and the left- ment panel. hand and right-hand line indicators 5 appear in white. Conditions for non-activation of the system The function triggers an alert if a line is crossed without the direction in...
Page 207 ADDITIONAL DRIVING AID FUNCTIONS In some cases, they are accompanied by the following message: – « Driving assist unavailable » ; – « Check Front camera » ; – « Check Driving assist ». Depending on the vehicle, the mes sage is accompanied by the display of on the in...
Page 208 ADDITIONAL DRIVING AID FUNCTIONS Warnings This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 209 ADDITIONAL DRIVING AID FUNCTIONS Activation/deactivation – performs corrective action on the Lane departure prevention steering system. From the multimedia screen 2 You can retake control of the vehicle at any time by operating the steering wheel. Location of the camera 1 Make sure the windscreen is not ob...
Page 210 ADDITIONAL DRIVING AID FUNCTIONS Using the switch 3 Operation – crosses a continuous line without ac tivating the indicator lights; – crosses a broken line without acti vating the direction indicators, if the "operation on broken line" setting is se lected.
Page 211 ADDITIONAL DRIVING AID FUNCTIONS formed as a priority of the status of the You can interrupt the trajec function "Channel centriing"; – the "Lane Centring" function is put tory correction at any time – the warning light and on standby while the "Lane Departure the indicator 5 on the side of the by moving the steering Prevention"...
Page 212 ADDITIONAL DRIVING AID FUNCTIONS – operation of the Electronic Stability When the function is deactivated, the Control system; warning light is displayed in yel – operation of the anti-lock braking system; low on the instrument panel. – the active emergency braking sys tem is triggered;...
Page 213 ADDITIONAL DRIVING AID FUNCTIONS – "Vibration": adjust the steering wheel vibration for the "Lane departure pre vention" function; – "Lane exit anticipation": adjust the line detection sensitivity level. To do this, select: – “Late”: line detected upon cross ing; – “Standard”: line detected on ap proach;...
Page 214 ADDITIONAL DRIVING AID FUNCTIONS Warnings This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 215 ADDITIONAL DRIVING AID FUNCTIONS – the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an approved dealer); – the vehicle is towing a trailer or a caravan; – the vehicle is entering an area with several surface markings (an area with road works etc.). D r i v i n g - 2 1 3...
Page 216 ADDITIONAL DRIVING AID FUNCTIONS Using information from the radar 2 and Emergency lane departure pre the camera 1 , the function triggers This system provides an corrective action on the vehicle steer vention additional driving aid. ing system in the event of a risk of col This system is not, under lision with a vehicle coming from the any circumstances, in...
Page 217 ADDITIONAL DRIVING AID FUNCTIONS Activating/deactivating the function Detection of an oncoming vehicle From the A "My Safety" switch Please refer to the multimedia instruc tions for more information. Press A switch twice if the function has been disabled from the Personal mode of the "My Safety"...
Page 218 ADDITIONAL DRIVING AID FUNCTIONS lision with a vehicle coming from the opposite direction in an adjacent lane This function is an addi and within the detection zone C , with tional driving aid. out the direction indicator having been This function is not un activated, the system: der any circumstances –...
Page 219 ADDITIONAL DRIVING AID FUNCTIONS If case of overtaking While driving at a speed between ap proximately 40 mph (65 km/h) and 112 mph (180 km/h), when approaching a line (continuous or broken) and there is a risk of collision with a vehicle lo cated in the blind spot D and it is mov...
Page 220 ADDITIONAL DRIVING AID FUNCTIONS pears on the instrument panel on the – the camera does not simultaneously – The antilock braking system is mal side of the intervention; detect the two boundaries of the lane functioning; – A towbar is electrically connected to in which your vehicle is moving;...
Page 221 ADDITIONAL DRIVING AID FUNCTIONS Warnings This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 222 ADDITIONAL DRIVING AID FUNCTIONS – the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an approved dealer); – the vehicle is towing a trailer or a caravan; – the vehicle is being towed (breakdowns); –...
Page 223 ADDITIONAL DRIVING AID FUNCTIONS Special feature Blind spot warning Ensure that zone C around the radars The function does not notify on each side of the rear bumper are Using information from the sensors in the driver if the other vehi not obstructed (by dirt, mud, snow, stalled on each side of the rear cles are not moving.
Page 224 ADDITIONAL DRIVING AID FUNCTIONS Warning light 2 Display D If you cancel the direction indicator, the function will return to the initial warning (display D ). Conditions for non-function – When driving on a road with tight bends; – in reverse. If the vehicle is equipped with a towbar recognised by the system, the "Trailer: blind spot warning off"...
Page 225 ADDITIONAL DRIVING AID FUNCTIONS Due to the presence of sen sors behind the bumper, it is advisable to entrust any operation on the bumper (repair, replacement, paintwork, etc.) to a qualified professional. D r i v i n g - 2 2 3...
Page 226 ADDITIONAL DRIVING AID FUNCTIONS Warnings – The system’s detection range operates according to a standard lane width. If you are driving in wide traffic lanes, the system might not be able to detect a vehicle in the blind spot. – In the event of very bad weather conditions (heavy rain, snow, etc.), the system may be temporarily disrupted. Remain aware of driving conditions.
Page 227 ADDITIONAL DRIVING AID FUNCTIONS Limitation of the system operation – The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the system. – Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the sys tem.
Page 228 ADDITIONAL DRIVING AID FUNCTIONS Location of the radar 2 Activation/deactivation from the Safe distance alert multimedia screen 3 Ensure that the radar area is not ob structed (by dirt, mud, snow, a badly fitted front number plate etc.), impact ed, modified (including painting) or hid den by any accessory fitted on the front of the vehicle (on the grille or logo etc.).
Page 229 ADDITIONAL DRIVING AID FUNCTIONS Operation (very insufficient distance between the two vehicles). If the interval between the two vehicles is less than around 0.5 seconds, notifi cation 8 , display D , will remain lit red on the instrument panel. Under certain conditions, the time in...
Page 230 ADDITIONAL DRIVING AID FUNCTIONS Warnings The measurement is displayed for information: the system does not carry out any action on the vehicle. This function is not designed for use in urban conditions or for a dynamic driving style (sudden cornering, acceler ation, braking, etc.), but rather for stable driving conditions.
Page 231 ADDITIONAL DRIVING AID FUNCTIONS This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. System servicing/repairs –...
Page 232: Active Emergency Braking
ADDITIONAL DRIVING AID FUNCTIONS – and stationary vehicles; Active emergency braking This system can apply maximum braking to the – surrounding pedestrians and cy vehicle until it is completely clists. stationary if necessary. The system informs the driver if there For safety reasons, always wear is a risk of head-on collision to enable your seat belt when travelling in...
Page 233 ADDITIONAL DRIVING AID FUNCTIONS Note: if the driver presses the brake pedal and the system still detects a In the event of an emer risk of collision, the braking force may gency manoeuvre, you can be increased if it is not sufficient to pre stop the braking at any mo...
Page 234 ADDITIONAL DRIVING AID FUNCTIONS Activation/deactivation Stationary vehicles are detected by the system when: – your vehicle is travelling at a speed Depending on the vehicle, between approximately 5 mph (8 km/h) according to the length of and 50 mph (80 km/h). time following the last time Detection of pedestrians and cy...
Page 235 ADDITIONAL DRIVING AID FUNCTIONS The possible causes are: – the system is temporarily blinded (glare from the sun, dipped beam headlights, bad weather conditions etc.). The system will be operational again when visibility conditions are better; – the system is temporarily interrupted (e.g.
Page 236 ADDITIONAL DRIVING AID FUNCTIONS Warnings This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steering wheel, pedals etc.).
Page 237 ADDITIONAL DRIVING AID FUNCTIONS System disturbance Some conditions can disturb or damage the system's operation, such as: – a complex environment (metal bridge, tunnel, etc.); – poor weather conditions (snow, rain, hail, black ice, etc.); – poor visibility (night, fog, etc.); –...
Page 238 ADDITIONAL DRIVING AID FUNCTIONS Deactivating the function You must deactivate the function if: – the camera area has been damaged (e.g. on the inside or outside of the windscreen); – the front of the vehicle has been damaged (impact, distortion, scratch on the radar, etc.); –...
Page 239 ADDITIONAL DRIVING AID FUNCTIONS Operation Driver vigilance warning The driver vigilance warn ing constantly monitors the The driver vigilance warning is a func driver's attention and can tion that analyses the behaviour of the provide several warnings per jour driver (driving style, vehicle steering, ney.
Page 240 ADDITIONAL DRIVING AID FUNCTIONS Activating and deactivating alerts Activating and deactivating the using the "My Safety" button 3 alerts from the multimedia screen When the alerts are deacti vated, the system contin ues to assess the driver's state of fatigue. Depending on the vehicle, alerts are automatically de...
Page 241 ADDITIONAL DRIVING AID FUNCTIONS – winding roads; It mainly uses information taken from try, alongside the speed limit converted the camera 1 attached to the wind – trailer traction. to the unit used by the vehicle’s instru screen behind the rear view mirror. De ment panel.
Page 242 ADDITIONAL DRIVING AID FUNCTIONS Operation It remains illuminated on the instru ment panel as long as the vehicle is Depending on the length of exceeding the detected speed limit. time following the last time the engine was stopped, the sound alert is reactivated: Map subscription –...
Page 243 ADDITIONAL DRIVING AID FUNCTIONS The sound alert can be deactivated or Select ON or OFF. The system cannot detect the speed activated using "Custom" mode in the limit if: "My Safety" function �� 201. Variation of the limited speed or –...
Page 244 ADDITIONAL DRIVING AID FUNCTIONS Warnings This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
Page 245 ADDITIONAL DRIVING AID FUNCTIONS The cruising speed can adjust auto according to the legislation in the Active driver assist matically to a speed limit change (de country where they are driving; pending on the country and subscrip – the adaptive cruise control can brake tion).
Page 246 ADDITIONAL DRIVING AID FUNCTIONS mph (180 km/h) (depending on the version) without a vehicle in front. The "Lane Centring" function is a com fort feature. It is represented by the warning light. Note: in the event of a sharp bend, the function's lateral retention capacities are limited and require the driver to take immediate action on the steering...
Page 247 D r i v i n g - 2 4 5...
Page 248: Location Of Components
ADDITIONAL DRIVING AID FUNCTIONS Location of components 2 4 6 - D r i v i n g...
Page 249 ADDITIONAL DRIVING AID FUNCTIONS conditions. 1 Camera The radar and camera Detects markings on the ground and 4 Capacitive sensor zones must be kept the position of vehicles on the various Depending on the vehicle, it detects traffic lanes. clean and free of any hands on the steering wheel.
Page 250 ADDITIONAL DRIVING AID FUNCTIONS Controls 2 4 8 - D r i v i n g...
Page 251 ADDITIONAL DRIVING AID FUNCTIONS 9. Switch for selecting/deselecting the driving aids, depending on the vehicle: – the Active driver assist; – Adaptive Cruise Control; – speed limiter; – OFF. 10. Safe distance settings 11. Puts the function on standby and stores the limited speed (0).
Page 252 ADDITIONAL DRIVING AID FUNCTIONS Activating/deactivating the "Active The green warning light 22 Displays on the instrument panel driver assist" function the lefthand and righthand line indi 17. Stop and Go adaptive cruise con cators 21 are displayed on the instru Activating the function ment panel to confirm that the function trol function warning light...
Page 253 ADDITIONAL DRIVING AID FUNCTIONS "Lane Centring" function on stand To activate the position in the lane, the To exit the driving aids, "Lane Centring" function must be in adjustment mode, the green warning press switch 1 as many The "Lane Centring" function is put on light 22 must be displayed on the in...
Page 254 ADDITIONAL DRIVING AID FUNCTIONS "Keep hands on steering wheel" the steering wheel. If the driver does warning light 22 and the left- warning not respond, the "Active driver assist" hand and right-hand line indicators 21 activates the hazard warning lights and on the instrument panel.
Page 255 ADDITIONAL DRIVING AID FUNCTIONS In the case of a sharp bend Note: in some situations, the "Lane concerned appear in red on the instru Centring" function may no longer de ment panel. tect your hands on the steering wheel If the vehicle crosses a line com and may emit an alert: pletely and moves out of its lane or –...
Page 256 ADDITIONAL DRIVING AID FUNCTIONS Consult an approved dealer. 2 5 4 - D r i v i n g...
Page 257 ADDITIONAL DRIVING AID FUNCTIONS Warning The "Active driver assist" is an additional driving aid. it can under no circumstances replace the driver's responsi bility to respect speed limits and safe distances and to be vigilant. The driver must always be in control of the vehicle. The driver must always adapt their trajectory and speed according to the surroundings and driving conditions, re...
Page 258 ADDITIONAL DRIVING AID FUNCTIONS Deactivating the system You must deactivate the system if: – the vehicle is travelling on a winding road; – the vehicle is being towed (breakdowns); – the vehicle is towing a trailer or a caravan; – the vehicle is being driven in a tunnel or close to a metallic structure; –...
Page 259 ADDITIONAL DRIVING AID FUNCTIONS Some conditions can disrupt or damage the system operation, for example: – obstruction of the windscreen or the radar area (by dirt, ice, snow, condensation etc.) Frequently check the cleanliness and condition of the windscreen, front wiper blades and front bumper; –...
Page 260 ADDITIONAL DRIVING AID FUNCTIONS Operation Active emergency braking in re This function is an addi verse gear tional driving aid. This function is not under any circumstances intended to replace the due care and atten tion of the driver, who should at all times be in control of the vehicle.
Page 261 ADDITIONAL DRIVING AID FUNCTIONS Activating or deactivating the sys If the vehicle is fitted with a towbar warning light 3 is displayed recognised by the system and a trailer has been connected, active emer on the multimedia screen accompa gency braking in reverse gear is auto nied by, depending on the type of mal...
Page 262 ADDITIONAL DRIVING AID FUNCTIONS Warnings Active emergency braking in reverse gear This function is an additional driving aid. This function cannot, under any circumstances, replace the vigilance and responsibility of the driver. Some climatic and environmental conditions can disrupt or damage the system. As a consequence, the driver should always be ready for sudden incidents while driving: always ensure that there are no small, narrow moving obstacles (such as a child, animal, pushchair, bicycle, stone, post, etc.) in the blind spot when manoeuvring.
Page 263: Speed Limiter
SPEED LIMITER Control A – Downwards: activates, decreases The speed limiter function controls the limited speed or stores the current engine and braking system to help you speed (SET/-). not to exceed a driving speed that you have chosen, known as the limit 5.
Page 264 SPEED LIMITER pedal will allow you to exceed the pro grammed speed except in an emer – Upwards: activates, increases limit gency (refer to information on "Ex ed speed or recalls the stored limited ceeding the limit speed"). speed (RES/+). –...
Page 265 SPEED LIMITER Control B Control B Varying the limit speed Control A Press the switch 6 . You can vary the limit speed by push ing the control 4 : The 8 warning light appears in grey. You can change the limit speed by re –...
Page 266 SPEED LIMITER system automatically limits the vehicle The speed limiter function is suspend ed when you press switch 2 (0). speed when a speed limit road sign is You must keep your identified and passed. feet near the pedals to The limit speed is stored and displayed be ready to react in an in grey on the instrument panel.
Page 267 SPEED LIMITER Control B If a speed has been stored, it can be recalled by pushing the 4 switch up wards or downwards. When the speed limiter is set to standby, pressing the 4 control upwards or down wards reactivates the function without taking into account the stored speed: it is the speed at which the vehicle is moving that is...
Page 268 SPEED LIMITER To exit the driving assis tance, press switch 1 as many times as necessary until you reach OFF. The "Driving Assistance deactivated" message appears on the instrument panel. In this case, the next time the en gine is started, the "Speed limiter" function will be activated and waiting for a speed limit to be stored.
Page 269: Cruise Control
CRUISE CONTROL Control A – Downwards: activates, decreases The cruise control function controls the cruising speed or stores the current engine and braking system to help you speed (SET/-). to maintain a driving speed that you have chosen, known as the cruising 5 Popup button (depending on the ve...
Page 270 CRUISE CONTROL 6. Start/stop speed limiter switch Switching on Control A 7. Cruise control On/Off switch 2. Put the function on standby (with cruising speed stored) (0). – Upwards: activates, increases cruis ing speed or recalls the stored cruising speed (RES/+). –...
Page 271: Activating Cruise Control
CRUISE CONTROL Control B The 8 warning light appears in grey. count. The cruising speed replaces the dashes. The "Cruise Cont. OK SET to activate" message appears on the instrument Cruise control is confirmed when the panel accompanied by dashes to indi memorised speed and warning light cate that the cruise control function is appear in green 8 .
Page 272 CRUISE CONTROL – upwards to (RES/+) to increase the Putting the function on standby This function is an addi speed; The function is set to standby if you: – downwards to (SET/-) to reduce the tional driving aid. – switch 2 (0) ; speed.
Page 273 CRUISE CONTROL control function without taking into ac The 8 warning light disappears from count the stored speed – it is the the instrument panel to confirm that speed at which the vehicle is moving the function has stopped. that is taken into account. Switching off the function Putting the cruise control on standby or switching...
Page 274: Stop And Go Adaptive Cruise Control
STOP AND GO ADAPTIVE CRUISE CONTROL (ground relief, weather conditions, Introduction etc.). The regenerative braking system and the paddles are The adaptive cruise control function Based on information from a radar or Stop and Go can be activated from 0 not available when the camera, the Stop and Go adaptive to 93 mph or 99 mph (0 to 150 km/h or...
Page 275 STOP AND GO ADAPTIVE CRUISE CONTROL Location of the camera 1 Controls This function is an addi tional driving aid. It can under no circum stances replace the driver's responsibility to respect speed limits and safe distances or to be vigilant. The driver must always be in con...
Page 276 STOP AND GO ADAPTIVE CRUISE CONTROL – Downwards: activates, decreases Displays Switching on cruising speed or stores the current speed (SET/-). Control A 7 Popup button (depending on the ve hicle): adapts the speed setpoint to de �� 239 tected speed limits 8 Adjusting the following distance.
Page 277 STOP AND GO ADAPTIVE CRUISE CONTROL accompanied by dashes to indicate – one or more doors are incorrectly celerate until it reaches the stored that the cruise control function is acti closed; cruising speed. – the "Hands-free parking" function is vated and waiting to store a cruising speed.
Page 278 STOP AND GO ADAPTIVE CRUISE CONTROL menu, select "Speed limit adaptive system and remains responsible for cruise control". Cruise control with advance the vehicle speed. speed limit sign recognition The letter "A" 17 is displayed on the When the function is not activated or instrument panel to confirm the activa...
Page 279 STOP AND GO ADAPTIVE CRUISE CONTROL tance". Then, from the "Comfort" Controlling cruising speed Note: the size of the 12 outline varies menu, select "Road layout adaptive according to the distance separating You can resume control of the vehicle you from the vehicle in front. The larg cruise control".
Page 280 STOP AND GO ADAPTIVE CRUISE CONTROL Note: the distance must be set accord Stopping the vehicle and setting ing to the traffic level, local regulation and weather conditions. If the vehicle in front slows down, the system adapts its speed to bring the vehicle to a complete stop if necessary The safe distance is adjust...
Page 281 STOP AND GO ADAPTIVE CRUISE CONTROL If the stop exceeds around three min vance recognition of the road layout firmed by the illumination of the cruis utes, the electronic parking brake is functions. ing speed in green. automatically applied and the Stop and The two functions are automatically re...
Page 282 STOP AND GO ADAPTIVE CRUISE CONTROL In some situations (e.g. coming up Switching off the function on a much slower vehicle, vehicle in To exit the driving assis front changing lanes quickly, etc.) tance, press switch 3 as the system may not have time to re many times as necessary act.
Page 283 STOP AND GO ADAPTIVE CRUISE CONTROL Temporary unavailability (cam not operate correctly if the radar detec – "Check Camera/Radar", accompa tion area is obscured or if its signal is nied, depending on the vehicle, by the era) disrupted. The system cannot operate if the cam warning light If the radar detection area is obstruct...
Page 284 STOP AND GO ADAPTIVE CRUISE CONTROL Detection during cornering Detection of vehicles in adjacent the system only once it enters the lanes camera and radar detection areas. The system may trigger inappropri ate or delayed braking. When entering a corner or bend, the radar and/or camera may be temporar...
Page 285 STOP AND GO ADAPTIVE CRUISE CONTROL The system will not detect vehicles hidden due to variations in ground re lief or those located outside of the camera and radar detection areas when driving uphill or downhill. Vehicles outside the camera and radar detection areas.
Page 286 STOP AND GO ADAPTIVE CRUISE CONTROL – vehicles in front 17 that change Non-detection of fixed obstacles lane, discovering a stationary vehicle and objects of a small size Always be ready to re 18 (e.g. S ); The system cannot detect: spond in all circum...
Page 287 STOP AND GO ADAPTIVE CRUISE CONTROL Detection of vehicles moving into lane at high speed If your vehicle is overtaken by another vehicle driving at high speed 20 (mo torcycle, car, etc.) and the vehicle is temporarily between you and the vehi cle in front 21 , the system may trig...
Page 288 STOP AND GO ADAPTIVE CRUISE CONTROL Warnings This function is an additional driving aid. It can under no circumstances replace the driver's responsibility to re spect speed limits and safe distances or to be vigilant. The driver must always be in control of the vehicle. Apart from the speed limit signs and road map information from the mapping (vehicles fitted with the "Road sign detection"...
Page 289 STOP AND GO ADAPTIVE CRUISE CONTROL Deactivating the function You must deactivate the function if: – the vehicle is being towed (breakdown recovery); – the vehicle is towing a trailer or a caravan; – the vehicle is being driven in a tunnel or close to a metallic structure; –...
Page 290 STOP AND GO ADAPTIVE CRUISE CONTROL In the event of system disturbance Some conditions can disturb or damage the system's operation, such as: – the windscreen or bumper is obscured in the radar area (by dirt, ice, snow, condensation, number plate, etc.); –...
Page 291: Parking Aids
PARKING AIDS The function does not take into ac Parking distance control count towing or carrying systems that An impact to the under are not recognised by the system. side of the vehicle while Operating principle manoeuvring (e.g. strik ing a post, raised kerb or This function is an addi...
Page 292 PARKING AIDS Operation In the event of a change in trajectory during a manoeu vre, the risk of collision with an obstacle may be signalled late. Special case of obstacles detected on the side Most objects located less near the front, rear and sides of the vehicle are The display 2 shows the vehicle sur...
Page 293 PARKING AIDS gets nearer. The area where the obsta proximately five seconds and an ob cle 3 has been detected is displayed stacle is detected (such as when in a (display D ). traffic jam, etc.); – if there is no risk of collision, no –...
Page 294 PARKING AIDS If it the fault persists, consult an ap Each time the vehicle is proved dealer. started, the function re sumes the activation status saved the last time the engine was stopped. Special cases You can manually deactivate sound alerts or, depending on the vehicle, the detection zone concerned in the event that:...
Page 295 PARKING AIDS Advice When the vehicle is travelling at a speed below approximately 6 mph (10 km/h), some noises (motorcycle, lorry, pneumatic drill, etc.) may trigger the Park Assist system audible warnings. System servicing/repairs – In the event of an impact, the alignment of the sensors may be altered and their operation may consequently be af fected.
Page 296 PARKING AIDS Limitation of the system operation – The area around the sensors must be kept clean and free of any modifications in order to ensure the proper opera tion of the system. – Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the sys tem.
Page 297: Reversing Camera
PARKING AIDS Reversing camera Operation Fixed guide lines 3 Trailer guide lines 5 The fixed gauge includes coloured This is shown in blue on the multime markers A , B and C indicating the dia screen 2 . This indicates the trajec distance behind the vehicle: tory of the trailer towbar according to the steering wheel position.
Page 298 PARKING AIDS Settings If an obstacle is detected behind the black screen is displayed temporarily on the multimedia screen 2 . vehicle, the function "Zoom auto" switches the current display to a top This may be caused by a fault affecting rear view.
Page 299 PARKING AIDS Difference between the estimated distance and actual distance Reversing towards a steep downhill Reversing towards a protruding ob slope ject The fixed guidelines 6 show the dis Position H seems further than position Reversing towards a steep uphill tances as further than they actually J on the screen.
Page 300 PARKING AIDS Location of the ultrasonic sensors Hands-free parking This function is an addi tional driving aid. Ensure that the area around the ultra Under no circumstances sonic sensors indicated by the arrows should it replace the 1 is not obscured (by dirt, mud, snow, a badly fitted/attached number plate, driver's care or responsibility etc.), impacted, modified (including...
Page 301 PARKING AIDS Choice of manoeuvre Operation The system can perform three types of manoeuvre: This function is an addi – parking the vehicle in a parallel or tional driving aid. perpendicular parking space; Therefore, it can under – moving out of a parallel parking no circumstances re...
Page 302 PARKING AIDS the vehicle, you must select the de – activate the direction indicator lights – an obstacle in the direction of move sired space by activating the direction on the side on which you wish to exit ment prevents the manoeuvre from be indicator.
Page 303 PARKING AIDS and the reason for cancelling the ma light comes on the instrument noeuvre will be displayed on the multi media screen 4 . panel. Follow the instructions shown on the Function unavailable multifunction screen 4 . When you select one of the system ac Cancelling the manoeuvre tivation methods, if the operating con...
Page 304 PARKING AIDS Warnings This function is an additional driving aid. This function is not under any circumstances intended to replace the due care and attention of the driver, who should at all times be in control of the vehicle. Make sure that the manoeuvre complies with the applicable traffic regulations in your location.
Page 305 PARKING AIDS Operation 360° camera – bird's eye view (using cameras 1 , 2 and 3 ): standard bird's eye view and The cameras transmit several sepa popup bird's eye view (when an ob rate views to the multimedia screen 5 . Using information from cameras 1 , 2 stacle is detected);...
Page 306 PARKING AIDS Front camera 1 Rear camera 3 This function is an addi tional aid. It cannot, therefore, under any cir cumstances replace the vigilance or the responsibility of the driver. The driver should always be ready for sudden incidents while driving: always ensure that there are no small, narrow moving ob...
Page 307 PARKING AIDS This is shown in blue on the multime dia screen 5 . It indicates the vehicle For the rear views, the mul trajectory according to the position of timedia screen 5 shows a the steering wheel in the front and the reverse image of the rear rear view.
Page 308 PARKING AIDS bird's eye view to the front side view. In the combined repre Please refer to the multimedia instruc In "bird's eye view" mode, tions for further information. sentation from the cam the objects displayed on eras: the multimedia screen are Bird's eye view actually further away than they –...
Page 309 PARKING AIDS Front panoramic view or rear 3D view "Trailer view" panoramic view On the multimedia screen, by pressing In forward gear, if a trailer is connect On the multimedia screen, press the the dedicated button 11 , you get a 3D ed, press the "360°...
Page 310 PARKING AIDS – yellow: obstacle between approxi To activate or deactivate the "Zoom mately 30 and 50 cm; auto" function, please refer to the mul – red: obstacle within approximately timedia instructions. 30 cm. Activation/deactivation These indicators also show the loca tions where obstacles are detected, as indicated by their positions in relation to the "Vehicle"...
Page 311 PARKING AIDS – after approximately three seconds, The fixed guidelines 13 show the dis when shifting from reverse gear to the tances as closer than they actually are. – Do not use this func N or P position; The objects shown on the screen are tion while the door mir...
Page 312 PARKING AIDS Limitation of the system operation Adjusting the display For example, if the screen displays an object at G , the actual distance of the object is at F . Driving or reversing towards a pro truding object The system is unable to display ob From the multimedia screen, when the jects located in certain areas.
Page 313 PARKING AIDS Adjusting the camera settings the driver when another vehicle ap pears in the detection zone B . – panoramic rear view; From the multimedia screen, while the The function is activated if: "360° camera" system is displayed, press the "Settings" button to add or –...
Page 314 PARKING AIDS Operation the instrument panel. Clean the area This function is an addi where the sensors are located. tional driving aid. This Activation/deactivation from the function is not under any multimedia screen 1 circumstances intended to replace the due care and atten tion of the driver, who should at all times be in control of the vehicle.
Page 315 PARKING AIDS played on the instrument panel: "Dri ving assist unavailable". Limitation of the sys tem operation If the system detects a fault, the "Check Side radars" message is dis – The radar area should played on the instrument panel. Con be kept clean and free of any sult an approved dealer.
Page 316 PARKING AIDS Safe passenger exit This function is an addi System disturbance Description tional driving aid. This Some conditions can function is not under any disrupt or damage the circumstances intended system operation, for ex to replace the due care and atten ample: tion of the driver, who should at all –...
Page 317 PARKING AIDS Special feature Operation Using information from the sensors in stalled on each side of the rear Ensure that zone C around the radars When a door is opened, when a mov bumper (area C ), the function warns on each side of the rear bumper are ing object is detected, the warning light the driver:...
Page 318 PARKING AIDS Activating/deactivating the function – there are moving objects (motor from the multimedia screen 4 bikes, bicycles, pedestrians, vehicles, etc.) moving towards or near your ve hicle at a low speed that is not consid ered a risk by the system; –...
Page 319 PARKING AIDS This function is an addi tional driving aid and may not detect certain vehicles or objects in movement in the vicinity of your vehicle. This function is not in any way a substitute for the vigilance and responsibility of the driver and the occupants of the vehicle, who are always responsible for paying particular attention to the...
Page 320: Emergency Call
EMERGENCY CALL If the vehicle is equipped, the emer gency call function can be used to call the emergency services (without charge) automatically or manually in the event of an accident or illness, re ducing the time it takes for the emer gency services to arrive.
Page 321 EMERGENCY CALL Manual mode The emergency call starts automatical In some cases, the emergency call ly in the event of an accident that has may not work (e.g. low battery, etc.). The emergency call can be initiated required the activation of the protective If the system detects an operating equipment (seat belt pretensioners, fault, the warning light 1 is illuminated...
Page 322 EMERGENCY CALL Without the emergency call To guarantee your safety feature, the system is not and the proper operation trackable and will not be of the system, any oper under constant surveillance. Data ation carried out on the is automatically and constantly battery (removal, disconnection, erased, and the system stores on...
Page 323: Your Comfort
MULTI-SENSE Accessing the menu be managed to reduce consumption Depending on the vehicle, the MULTI- �� 183. SENSE system enables you to choose from several driving modes that affect "Sport" mode the driving, ambient lighting, comfort and driving position: This mode authorises increased en –...
Page 324: Air Vents, Heating And Air Conditioning
AIR VENTS, HEATING AND AIR CONDITIONING Air vents: air outlets Air outlets 3 2 2 - Yo u r c o m f o r t...
Page 325 AIR VENTS, HEATING AND AIR CONDITIONING 1. Driver’s position air vents 2. Windscreen demister outlet 3. Passenger air vents 4. Side window demister outlet 5. Footwell heater outlets for front passengers 6. Footwell heater outlets for rear passengers 7. Rear passenger central air vents. 8.
Page 326 AIR VENTS, HEATING AND AIR CONDITIONING Passenger air vents 3 Air flow Driver's position air vents 1 To control the air flow from the air Direction Direction vents 1 and 3 , press or raise the con trol 12 to the level desired. To direct the air flow, turn the air vents To direct the air flow, turn the air vents using the tabs 11 .
Page 327: Manual Air Conditioning
AIR VENTS, HEATING AND AIR CONDITIONING Rear seats Direction Manual air conditioning To direct the air flow, turn the air vents The controls 7 using the tabs. Air flow To check the flow of the air vents 7 turn the knob 13 according to the de sired opening: –...
Page 328 AIR VENTS, HEATING AND AIR CONDITIONING Stopping the system 8. Passenger compartment air distrib The system cannot be switched on if ution adjustment. the ventilation power is zero. Press the button 7 : The air conditioning system is used 9. Activation control for the "A/C MAX" –...
Page 329 AIR VENTS, HEATING AND AIR CONDITIONING Adjusting the air temperature "Clear View" function The positions are in the following or der: All the air is then directed to the windscreen and front side window demisting vents. The air flow is distributed be tween front side window demisting vents, the windscreen demisting vents and the footwells.
Page 330 AIR VENTS, HEATING AND AIR CONDITIONING ables rapid demisting/de-icing of the Air recirculation operates as fol rear screen and the rear view mirrors Recommendations lows: (on equipped vehicles). In the event of freezing, – isolating the vehicle from the exter To exit this function, press button 12 manually deice the wind...
Page 331: Automatic Climate Control
AIR VENTS, HEATING AND AIR CONDITIONING ECO mode Automatic climate control 8. Passenger compartment air distrib ution indicator. The controls 9. Passenger heating temperature in dicator. 10. Adjusting the passenger's air tem perature. 11. Passenger compartment air distri bution adjustment. 12.
Page 332 AIR VENTS, HEATING AND AIR CONDITIONING Press the control 14 to activate the button 14 , then press upwards to acti system or set the control 17 to the de vate FAST mode. sired ventilation speed. When the air conditioning starts in au tomatic mode, the system returns to Stopping the system the last programme used.
Page 333 AIR VENTS, HEATING AND AIR CONDITIONING footwells. – adjusting using the SYNC function to windows and door mirrors (depending synchronise the passenger side with on the vehicle). It automatically acti the driver's side. vates the air conditioning and rear The air flow is mainly directed to screen de-icing functions.
Page 334 AIR VENTS, HEATING AND AIR CONDITIONING "Favourites" function the rear screen and de-icing of the rear – air flow at its maximum power; view mirrors (on equipped vehicles). – activation of the air conditioning; – air recirculation. To exit this function, press button 15 again.
Page 335 AIR VENTS, HEATING AND AIR CONDITIONING ECO mode Air conditioning: programming Air conditioning programming You can save several comfort pro grammes by activating the following From the MULTISENSE menu acces settings: sible from the multimedia screen 20 or – temperature adjustment; by pressing the switch 21 , you can ac...
Page 336 AIR VENTS, HEATING AND AIR CONDITIONING Immediate activation of the air- – the bonnet is open; conditioning Driver's responsibility – you press one of the switches on the control panel; when parking or stop It is possible to carry out immediate –...
Page 337 AIR VENTS, HEATING AND AIR CONDITIONING Do not add anything to Use the air conditioning Do not open the refrig the vehicle’s ventilation system regularly, even in erant circuit. The fluid circuit (for example, to cold weather, running it at may damage eyes or remove bad odours).
Page 338 AIR VENTS, HEATING AND AIR CONDITIONING The presence and location of the infor – (1) 0.450 kg/1.050 kg mation on label A depends on the ve – (2) GWP 4 – (3) 0.002t/0.004t hicle. Type of refrigerant fluid Do not open the refrig erant circuit.
Page 339: Multimedia Equipment
MULTIMEDIA EQUIPMENT 1. Multimedia screen. 2. USBC multimedia ports in the up per A and lower B centre console. 3. Steering column control. 4. Voice command. 5. USB-C multimedia ports for the rear passengers. Please refer to the multime dia instructions for further information.
Page 340 MULTIMEDIA EQUIPMENT Microphone 6 Induction charging zone 7 �� 343 (for the phone and voice assistant) Using the telephone We remind you of the need to conform to the legislation in force con cerning the use of such equip ment. 3 3 8 - Yo u r c o m f o r t...
Page 341: Passenger Compartment Equipment
PASSENGER COMPARTMENT EQUIPMENT One-touch electric windows Electric windows These systems operate with the igni tion on or off, until one of the front doors is opened (limited to about 3 minutes). Driver's responsibility Never leave your vehicle with the card or key in side, with a child, adult who is not self-sufficient or a pet in the vehicle, even for a short...
Page 342: Interior Lighting
PASSENGER COMPARTMENT EQUIPMENT Note: if the window detects resistance It is recommended that the user only Interior lighting when almost fully closed (e.g. a tree operates the system when the vehicle can be seen clearly and no one is in branch), it stops and then lowers again Map reading lights by a few centimetres.
Page 343 PASSENGER COMPARTMENT EQUIPMENT Luggage compartment light Sun visor, mirror Sun visor The light 4 comes on when the lug When the doors are un gage compartment is opened. locked and opened, the Lower the sun visor 5 over the wind courtesy and footwell lights screen or unclip it and flip it over to the come on temporarily.
Page 344 PASSENGER COMPARTMENT EQUIPMENT Accessories socket Connect accessories Accessories socket 1 with a maximum power of 120 watts (12 V) only. When several accessory sockets are used at the same time, the total power of the con nected accessories must not ex ceed 180 watts.
Page 345: Passenger Compartment Storage, Fittings
PASSENGER COMPARTMENT STORAGE, FITTINGS Centre console storage com Front door storage compart Depending on the country partment or induction charging ment 1 area 2 and the subscription, the in duction charging zone is al so the placement zone for smart phones equipped with a digital key ��...
Page 346 PASSENGER COMPARTMENT STORAGE, FITTINGS Centre console storage com Centre armrest storage com When turning corners, partment 4 partment 9 accelerating or braking, ensure that the recepta cle being held by the cup holder is not dislodged. There is a risk of burning if hot liquid escapes.
Page 347: Glove Box
PASSENGER COMPARTMENT STORAGE, FITTINGS Sun blind storage compartment Glovebox Grab handle 12 To open, press the handle 11 . This offers support and can be held when the vehicle is moving. Can be used to hold motorway toll tick It can hold a box of tissues, a bottle of ets, maps, etc.
Page 348 PASSENGER COMPARTMENT STORAGE, FITTINGS Rear door storage compartment Storage pocket 14 (depending on the vehicle) Ensure that no hard, heavy or pointed objects are placed in the "open" storage compartments in such a way that they may fall onto passengers during sharp turning, sudden braking or in the event of an accident.
Page 349: Transporting Objects
TRANSPORTING OBJECTS Luggage compartment storage Transporting objects in the luggage compartment Always position the objects transport ed so that the largest surface is against: – the front seatbacks with the rear seatbacks folded down, as is the case Always position the for maximum loads (example B ).
Page 350 TRANSPORTING OBJECTS Towbar Roof bars Accessing the mounting points Permissible nose weight, maximum permissible towing weight while braked and unbraked: �� 394. Choice and fitting of towing equipment Towbar (cross member and hitch) not originally fitted to the vehicle: the entire towbar and mountings must not exceed 25 kg.
Page 351 TRANSPORTING OBJECTS Spoiler A Before operating the luggage compart ment door, check the objects and/or accessories (bicycle rack, roof box, etc.) fitted on the roof bars: these must be correctly positioned and secured, and must not prevent the luggage compartment door from operating cor rectly.
Page 352: Maintenance
ACCESSING THE ENGINE, LEVELS Bonnet Do not press down on The vehicle drive system the bonnet as there is a in an electric vehicle us Unlocking the bonnet catch risk that the bonnet may es a direct voltage of ap accidentally close.
Page 353 ACCESSING THE ENGINE, LEVELS Opening the bonnet Closing the bonnet When working in the en gine compartment, en sure that the windscreen wiper stalk is in the park position. Risk of injury. Ensure that the bonnet is properly locked. Ensure that nothing is preventing locking (grit, cloths, etc.).
Page 354: Coolant Level
ACCESSING THE ENGINE, LEVELS Coolant level cold must be between the "MINI" and "MAXI" marks on the coolant reser The vehicle drive system voirs 1 and 2 . Coolant level in an electric vehicle us Top this level up when cold before the es a direct voltage of ap...
Page 355 ACCESSING THE ENGINE, LEVELS If the level needs to be topped up, only Levels, filters Topping up use products approved by our Techni After any operation on the hydraulic cal Department which ensure: Brake fluid level circuit, a specialist must replace the –...
Page 356 ACCESSING THE ENGINE, LEVELS Topping up Open the cap 3 , fill until you can see the fluid, then refit the cap. Fluid Only use windscreen washer fluid con taining antifreeze. We advise you to consult an approved dealer or a qualified professional. Note: Do not use hard water (risk of damage to the priming pump, limescale building up on the pump and...
Page 357: Battery
BATTERY Maintenance/replacement Secondary 12 V battery The vehicle drive system The secondary 12 V battery 1 charg in an electric vehicle us ing status may diminish, especially if es a direct voltage of ap you use your vehicle: proximately 400 volts. –...
Page 358 BATTERY Label A Breakdown recovery To avoid damaging your ve hicle, do not recharge the secondary 12 V battery us ing: – an external battery charger; – a battery from another vehicle. Call an approved Dealer. Do not disconnect the secondary 12 V battery.
Page 359: Cleaning
CLEANING ment (never use abrasive products). Observe local regulations about wash Bodywork maintenance Rinse thoroughly beforehand using a ing vehicles (e.g. do not wash your ve jet washer: hicle on a public highway). Bodywork maintenance – spots of tree resin and industrial pol When washing the vehicle with a high- lution;...
Page 360 CLEANING Do not do the following Doing this could give rise to corrosion Cleaning the headlights, sensors and or operational faults. cameras Wash the vehicle in bright sunlight or freezing temperatures. Use a soft cloth or cotton wool. Using a roller type car wash Do not scrape off mud or dirt without If this is not sufficient, moisten the Return the wiper stalk to the Park posi...
Page 361 CLEANING Interior trim maintenance wipe clean using another soft damp Special instructions for sweets or cloth or cotton wool. chewing gum Interior trim maintenance Finally, dry off carefully with a soft dry Place an ice cube on the stain to solid cloth.
Page 362 CLEANING Do not do the following Position objects such as deodorants, scents etc. near air vents as this could damage your dashboard trim. Use high-pressure cleaning equipment or sprays inside the passenger com partment: without careful use, this equipment could impair the correct functioning of the electrical or electronic components in the vehicle, or have other detrimen...
Page 363: Practical Advice
TYRES become visible 2 : it is then neces Tyres sary to replace your tyres because Incorrect tyre pres the tread rubber is 1.6 mm deep at sures lead to abnormal most, resulting in poor road-holding Maintaining the tyres tyre wear and unusually on wet roads.
Page 364 TYRES Fitting new tyres Chains cannot be fitted to tyres Please be aware that a which are larger than those originally To fit new tyres, consult an approved fitted to the vehicle. poorly tightened or miss dealer. ing valve cap can make One-way tyres the tyres less airtight and An one-way tyre must only be fitted in...
Page 365: Tyre Pressure
TYRES Tyre pressure Depending on the vehicle, after each Chains may only be fit reinflation or readjustment of the tyre pressure, you should reset the tyre Label A ted to tyres of the same pressure reference value �� 192 or size as those originally Tyre pressure monitoring system.
Page 366 TYRES Tyre inflation kit Vehicle fitted with a tyre For your safety and to Tyre inflation kit pressure loss warning or comply with the law. tyre pressure monitoring When they need to be system (depending on the vehi replaced, only tyres of cle) the same make, size, type and In the event of under-inflation...
Page 367 TYRES The kit repairs tyres Do not attempt to use The kit is only approved when the tread A has the inflation kit if the tyre for inflating the tyres of been damaged by ob has been damaged as a the vehicle originally jects smaller than 6 mm.
Page 368 TYRES – disconnect any accessories that are connected to the vehicle's accessories Before using the kit, park sockets; the vehicle at a sufficient – on vehicles fitted with a towing de distance from traffic, vice, disconnect the towbar socket if switch on the hazard needed;...
Page 369 TYRES tance of 2 miles (3 km), stop and check the pressure. Please be aware that a – If the pressure is higher than 1.3 bar poorly tightened or miss but lower than the recommended pres ing valve cap can make sure (refer to the label affixed to the the tyres less airtight and edge of the driver's door), adjust it.
Page 370 TYRES Tools Do not leave the tools Tool kit unsecured inside the ve hicle as they may be projected during braking. After use, check that all the tools are correctly clipped into the tool kit, then position it correctly in its housing to reduce the risk of in...
Page 371: Breakdown Recovery
BREAKDOWN RECOVERY Towing: breakdown Breakdown recovery P r a c t i c a l a d v i c e - 3 6 9...
Page 372 BREAKDOWN RECOVERY Before any towing, including on a Do not leave the tools When the engine is flatbed truck, set the gear control to unsecured inside the ve stopped, steering and position N and release the parking brake. hicle as they may be braking assistance are projected during braking.
Page 373 BREAKDOWN RECOVERY Press zone A and maintain the pres sure while pulling zone B (using a flat- – Use a rigid tow bar. If blade screwdriver or similar tool) to a rope or cable is used open the flap 4 . (where the law allows this), the vehicle being towed Sport version...
Page 374 BREAKDOWN RECOVERY Rear towing point Insert a flatblade screwdriver or simi lar tool into the recess provided, then pull to open the flap 8 . 3 7 2 - P r a c t i c a l a d v i c e...
Page 375: Headlights, Lights: Replacing Bulbs
HEADLIGHTS, LIGHTS: REPLACING BULBS Consult an approved dealer. Exterior lighting: replacing bulbs Any operation on (or LED reversing lights and rear fog lights modification to) the elec Front headlights trical system must be performed by an ap Consult an approved dealer. LED dipped beam/main beam head...
Page 376 HEADLIGHTS, LIGHTS: REPLACING BULBS Courtesy mirror lights 3 Side indicator lights 5 Interior lighting: changing bulbs Reading lights 1 and 2 Consult an approved dealer. Consult an approved dealer. Consult an approved dealer. 3 7 4 - P r a c t i c a l a d v i c e...
Page 377 HEADLIGHTS, LIGHTS: REPLACING BULBS Light for luggage compartment 4 Consult an approved dealer. P r a c t i c a l a d v i c e - 3 7 5...
Page 378: Wiper Blades: Replacement
WIPER BLADES: REPLACEMENT Replacing windscreen wiper blades 2 Refitting To refit the wiper blade 2 , insert it into Check the condition of the its housing in the arm 3 , then clip it un wiper blades. You are re til you hear a click.
Page 379 WIPER BLADES: REPLACEMENT Rear screen wiper blade 5 Check the condition of the Before changing the rear wiper blades. You are re wiper blade, make sure sponsible for their service the stalk is in the stop life: position (deactivated). Risk of injury. –...
Page 380: Fuses
FUSES Unhook the wire 3 to release the Fuse box glovebox door in order to access the fuse box. Once open, turn the stops 2 a quarter of a turn (movements B and C ) to re move them. If any electrical component does not Move the glovebox door A downwards work, check the condition of the fuses.
Page 381 FUSES Fuse box D Clamp 6 Check the fuse in ques tion and, if necessary, replace it (replacement fuse must have the same rating as the original. If a fuse is fitted with too high a rating, it may cause the electrical circuit to overheat (risk of fire) in the event of an item of equipment using an excessive amount of...
Page 382 FUSES Vehicles equipped with a fuse allo Icon Allocation cation label Towbar socket Depending on the vehicle, Multimedia accessories you can use the fuse allo socket, multimedia screen cation label in the storage compartment to identify the fuses. Cigarette lighter, front and Fuse compartment D : the fuse al...
Page 383 FUSES P r a c t i c a l a d v i c e - 3 8 1...
Page 384 FUSES Num Num Allocation Allocation ESP/ABR ECU Brake Switch Lefthand front exterior open ing control Righthand rear window con trol motor Rear screen de-icer/Heated rear screen interference filter Driver’s side window control motor Retractable electric handle Interior lighting 1st row accessories socket Lefthand rear window con...
Page 385: Important Recommendations
IMPORTANT RECOMMENDATIONS Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, position of the aerial, etc.), make sure it is compatible with your vehicle. Contact an approved dealer. Before connecting an accessory to a socket, please ensure that it does not exceed the maximum power autho rised for the socket��...
Page 386 IMPORTANT RECOMMENDATIONS On the driver's side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the pedals. 3 8 4 - P r a c t i c a l a d v i c e...
Page 387: Operating Faults
OPERATING FAULTS The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always con tact an approved dealer as soon as possible. FAULTS POSSIBLE CAUSES ACTION REQUIRED Impossible to charge the The outdoor temperature is lower than -26°C. Recharge your vehicle in a more suitable envi...
Page 388 OPERATING FAULTS FAULTS POSSIBLE CAUSES ACTION REQUIRED area �� 167 and press the "START" button to synchronise the card. The "Place the card near The card battery is flat or the card is Check the card battery status or place the card in the dedi cated placement area ��...
Page 389 OPERATING FAULTS Electrical equipment POSSIBLE CAUSES ACTION REQUIRED Direction indicators flashing Faulty bulb. Consult an approved Dealer. more quickly. The indicators are On one Faulty bulb. Consult an approved Dealer. not working. side: Replace the fuse or have it replaced �� 378. On both –...
Page 390 OPERATING FAULTS Stopped POSSIBLE CAUSES ACTION REQUIRED The air conditioning compressor and the ventilation fan Consult an approved Dealer. switch on for more than 30 minutes when the ignition is switched off. �� 333. The programmable air conditioning One of the usage conditions is not complied with (the fails to work.
Page 391: Technical Specifications
INFORMATION ABOUT THE VEHICLE 9. Paint reference (colour code). Vehicle identification plates Technical Information for the emergency services The information shown on the vehi cle identification plate should be quoted on all correspondence or or ders. The presence and location of the in formation depends on the vehicle.
Page 392 INFORMATION ABOUT THE VEHICLE Engine specifications Engine identification, engine specifications Engine identification Engine type: 6AM Please quote the information on the engine plate or label A in all corre spondence or orders. (Location varies depending on engine) 1. Engine type. 2.
Page 393 INFORMATION ABOUT THE VEHICLE Information on lifting The lifting points are compatible with the use of a jack equipped with a flat To prevent any risk of in plate and a diameter between 80 mm jury or damage to the ve and 140 mm.
Page 394 INFORMATION ABOUT THE VEHICLE Dimensions (in metres) 3 9 2 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 395 INFORMATION ABOUT THE VEHICLE Length 0,800 2,685 0,715 4,200 1.555 to 1.565 1.505 unladen 1.545 to 1.555 1.768 to 1.782 2.055 with door mirrors folded out 1.860 with door mirrors folded in Te c h n i c a l s p e c i f i c a t i o n s - 3 9 3...
Page 396: Weights (In Kg)
INFORMATION ABOUT THE VEHICLE Weights (in kg) 3 9 4 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 397 INFORMATION ABOUT THE VEHICLE (in kg) The weights indicated are for a basic vehicle without optional fittings: they vary according to your vehicle's equip ment. Consult yourapproved dealer. Maximum Permissible All-up Weight ( MMAC ) Weights indicated on the manufacturer's plate �� 389 Maximum Permissible Weight ( MMTA ) Gross Train Weight ( MTR ) Braked Towing Weight *...
Page 398: Replacement Parts And Repairs
REPLACEMENT PARTS AND REPAIRS Original parts are based on very stringent specifications and are subjected to specific tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out in the approved dealer network with original parts are guaranteed according to the conditions stated on the back of the repair or...
Page 399: Service Sheets
SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
Page 400 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
Page 401 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
Page 402 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
Page 403 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
Page 404 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
Page 405: Anticorrosion Check
ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 4 0 3...
Page 406 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: 4 0 4 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 407 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 4 0 5...
Page 408 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: 4 0 6 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 409 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 4 0 7...
Page 410 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: 4 0 8 - Te c h n i c a l s p e c i f i c a t i o n s...
Page 411 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 4 0 9...
Page 412: Alphabetical Index
Card: hands-free, Additional restraint devices, Card: locking/unlocking the opening elements, Airbag, Card: use, Airbag : activating the front passenger airbag, Card RENAULT: use, Airbag: airbag, Central door locking, Airbag : deactivating the front passenger airbag, Changing bulbs, 373, Airbags : child safety,...
Page 413 ALPHABETICAL INDEX Child restraint system, Driving advice, 183, 183, Child safety, 117, Driving aids, 202, 207, 221, 226, 239, 243, 258, 272, 298, 303, Child seats, Cleaning: vehicle interior, Driving position, Closing/Opening the doors, Driving position: settings, Closing/Opening the luggage compartment, Closing/Opening the sunroof, Closing the doors, ECO driving,...
Page 414 ALPHABETICAL INDEX Front seat adjustment, Front seat belt pretensioners, Lane Centring, Front seats, Lane departure prevention, Front seats: adjustment, 202, Lane departure warning, Fuses, Levels, 350, Levels: coolant, Lighting signals, Gear control, Lights: adjustment, Lights: replacing bulbs, Locking/unlocking the doors, Hands-free parking, Locking the doors, Hands-free telephone integrated control,...
Page 415 ALPHABETICAL INDEX Navigation, Radio, Navigation system, Rear headrests, Rear seats, Rear view mirrors, Replacement and repair parts, Opening element/door controls, Replacing windscreen wiper blades, Opening elements, Restraint devices in addition to the rear seat belts, Opening the doors, Restraint in addition to the seatbelts, Operating faults, 272, Reversing camera,...
Page 416 ALPHABETICAL INDEX Starting the engine, 167, 167, Steering wheel: adjustment, Warning: parking exit, Stopping the engine, 167, Warning lights, Storage compartment/fittings: passenger compartment, Warning lights on the instrument panel, Washing, Wiper, 161, 161, Tools, Wiper blades: replacement, Towing: breakdown, Towing rings, Traction battery, Traction battery range, Traction control,...
Page 418 RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 122-122 BIS, AVENUE DU GENERAL LECLERC 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / renaultgroup.com NU 1402-7 – 77 11 416 640 – 07/2024 – Edition anglaise...

Save PDF
