- Page 1 EN User Manual | Washing Machine LFR73864CE aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................8 5. -
Page 3: General Safety
the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •... -
Page 4: Safety Instructions
• If a tumble dryer is stacked on the top of the washing machine, make sure to use the correct stacking kit approved by AEG (see more details in chapter "Accessories - Stacking kit"). 2. SAFETY INSTRUCTIONS 2.1 Installation... -
Page 5: Water Connection
appliance. Contact the Authorised Service appliance with the use of water in the Centre to ensure which accessories can factory. be used. • You can extend the drain hose to maximum 400 cm. Contact the Authorised 2.2 Electrical connection Service Centre for the other drain hose and the extension. -
Page 6: Product Description
• The Wi-Fi connection and Remote Start will be easier! enable you to start a cycle, to interact with • The AEG Steam Fragrance, thanks to the steam programmes offers the perfect your washing machine and to check the solution for refreshing even the most washing cycle status in remote control. -
Page 7: Appliance Overview
Access your appliance details, documentation and articles on how to use the best features (User Manual also available at aeg.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at aeg.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at aeg.com/ shop ) ENGLISH... -
Page 8: Technical Data
4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /57.6 cm Electrical connection Voltage 230 V Overall power 2100 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture ensured IPX4 by the protective cover, except where the low voltage equipment has no protection against moisture... - Page 9 5. Carefully put the appliance down on its rear side. 9. Remove the power supply cable and the 6. Put the front polystyrene packaging drain hose from the hose holders. element on the floor under the appliance. It is possible to see water flowing Make sure not to damage the hoses.
-
Page 10: Positioning And Levelling
A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation. When the appliance is installed on a plinth or a tumble dryer is stacked on the washing machine, use the accessories described in chapter 'Accessories'. -
Page 11: Water-Stop Device
already installed at the factory. CAUTION! Make sure that there are no leaks from the couplings. 45º 45º 20º 20º Do not use an extension hose if the inlet hose is too short. Contact the service centre for information on inlet hose replacement. -
Page 12: Electrical Connection
It is possible to connect the drain hose in different ways: min.600 mm max.1000 mm (*) Subject to change without notice. • Connect the drain hose to the spigot and tighten it with a clamp. • Position the hose directly to a built-in drain Make sure that the plastic guide cannot pipe in the room wall and tighten it with a move when the appliance drains and the... -
Page 13: Control Panel
required, also taking into account any other The power supply cable must be easily appliances may also be in use. accessible after installing the appliance. Connect the appliance to an earthed For any electrical work required to install this socket. appliance, contact our Authorised Service Centre. - Page 14 Extra Rinse touch button Spin touch button Time Save touch button Temperature touch button Stains/Prewash touch button permanent Child Lock option 6.2 Display Door locked indicator. Washing phase indicator. It flashes during pre-wash and wash phase. Rinsing phase indicator. It flashes during rinse phase. Spinning and draining phase indicator.
-
Page 15: Dial And Buttons
The digital indicator can show: • Programme duration (e. g. The time shown when the programme is set could not correspond to effective duration and change after ProSense phase. • Maximum load. • Finish in time (e. g. • Cycle end ( ). •... -
Page 16: Programme Dial
energy consumption in a few cases, you may The related led comes on and the related need to activate the appliance again. icon appears on display. For more details, refer to Stand-by paragraph in Daily Use chapter. If you set a programme via App and it 7.2 Programme dial does not match with the knob position, text appears alternating with... -
Page 17: Plus Steam
7.7 Start/Pause A small laundry load helps to reach better Touch the Start/Pause button to start, results. pause the appliance or interrupt a running programme. 7.9 Extra Rinse 7.8 Plus Steam With this option you can add a few rinses to This option adds a steam phase followed by a the selected washing programmes and short anti-crease phase at the end of the... - Page 18 the appropriate phase of the washing • Activate the Extra silent option. programme. All spinning phases (intermediate spin and final spin) are suppressed and the programme ends with water in the drum. This helps to reduce creasing. This option is not available with a As the programme is very quiet, it is temperature lower than 40 °C.
-
Page 19: Settings
8. SETTINGS 8.1 Introduction 8.4 Permanent Extra Rinse With this option you can permanently have an extra rinse phase, if available with selected When pressing a key combination, do cycle, when you set a new programme. not tilt your fingers downwards . The •... -
Page 20: Factory Defaults
8.6 Factory Defaults 2. Press and hold the buttons for some seconds. This function allows to restore the factory default options. To activate this option follow 3. The display will show for about 5 steps below: seconds. 1. Switch the appliance on by pressing On/Off button. -
Page 21: Programme Chart
10.2 Programme Chart The programmes are described in this chart following the order of the selector dial from the top to the bottom. Washing programmes Programme Programme description Cotton and mixed synthetic fabrics. Ideal to wash your daily load in a short time, for a better clothes care and good cleaning already at 30°C. - Page 22 Programme Programme description Outdoor Do not use fabric softener and make sure that there is no softener residue in the detergent dispenser. Outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets with a removable fleece or inner insulation. The recommended laundry load is 2.0 kg.
- Page 23 Programme temperature, maximum spin speed and maximum load Programme Default tempera‐ Reference spin speed Maximum load ture Spin speed range Temperature range 30 °C 1600 rpm 5.0 kg 60 °C - 30 °C 1600 rpm - 400 rpm MixLoad 69min 1600 rpm 8.0 kg 1600 rpm - 400 rpm...
- Page 24 The Steam programmes do not remove particularly intense odour and do not perform any hygienic cycle. The fragrance is available on AEG web After the steam treatment the laundry can shop or by authorised dealer. be humid. Hang items out for a few minutes.
- Page 25 10.5 Options compatibility with programmes ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Spin ■ ■ ■ ■ ■ ■ ■ ■ ■ Rinse Hold ■ ■ ■ Extra Silent ■ No Spin ■ ■ ■ Stains ■ ■...
-
Page 26: Wi-Fi - Connectivity Setup
Suitable detergents for washing programmes Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder 1) MixLoad 69min ▲ ▲ Eco 40-60 ▲ ▲ ▲ Cottons ▲ ▲ ▲ Synthetics ▲ ▲ ▲ Delicates ▲ ▲ Wool ▲ ▲... - Page 27 11.2 Installing and configuring App sounds. Release the button. appears on the display for 5 seconds and the indicator starts blinking. The wireless module begins starting up. App allows you to control your laundry through a mobile device. It contains a large number of programmes, useful features and product information tailored perfectly to the appliance.
-
Page 28: Over-The-Air Update
To switch the wireless connection off, The indicators appear on the press and hold the Remote Start button programme summary screen and the door is for a few seconds until the first acoustic locked. Now it is possible to start the programme remotely. -
Page 29: Daily Use
The Wi-Fi Always On function may affect your energy consumption. 12. DAILY USE CAUTION! WARNING! Make sure that no laundry stays between Refer to Safety chapters. the seal and the door. There is a risk of water leakage or damage to the laundry. 12.1 Activating the appliance 1. -
Page 30: Check The Position Of The Flap
4. To use liquid detergent, turn the flap down. Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ). This quantity will however guarantee the best washing results. -
Page 31: Starting A Programme
12.8 The ProSense load detection set programme (only for a few seconds), the default temperature, the default spin speed and the washing phase indicators (when available). 2. To change the temperature and/or the spin speed, touch the related buttons. The programme duration in the display is 3. -
Page 32: Cancelling A Running Programme
2. Change the options. The given information in the display changes accordingly. About 20 minutes after the programme start, the programme duration could be 3. Touch the Start/Pause button again. adjusted again depending on the The washing programme continues. capacity of water absorption of the fabrics. -
Page 33: End Of The Programme
• The drum still turns at regular intervals to When the icon goes off, the door can be prevent the creases in the laundry. opened when the programme is complete. • The door stays locked. You may also set a spinning or draining •... -
Page 34: Hints And Tips
If you set a programme or an option that If the Wi-Fi Always On function is active, ends with water in the drum, the Stand- only the indicator goes on and off by function doesn't deactivate the intermittently. appliance to remind you to drain the water. -
Page 35: Water Hardness
• unsatisfactory washing results, • the wash load to turn grey, • greasy clothes, • mould in the appliance. Excessive detergent may cause: • sudsing, • reduced washing effect, • inadequate rinsing, • a greater impact for the environment. 13.3 Detergent type and quantity 13.4 Savings tips The choice of detergent and use of correct To save water, energy and detergent we... -
Page 36: Care And Cleaning
14. CARE AND CLEANING 14.3 External cleaning WARNING! Clean the appliance with mild soap and warm Refer to Safety chapters. water only. Fully dry all the surfaces. Do not use a scouring pads or any scratching 14.1 Periodic cleaning schedule material. -
Page 37: Cleaning The Drum
powder detergent or, if available, run the Machine Clean programme. Always follow the instructions that you 14.6 Door seal find on the packaging of the product. 2. Remove all laundry from the drum. This appliance is designed with a self 3. -
Page 38: Cleaning The Drain Pump
14.9 Cleaning the drain pump the upper and lower part of the recess. Use a small brush to clean the recess. WARNING! Disconnect the mains plug from the mains socket. Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: •... - Page 39 4. Turn the filter 180 degrees in anti- 10. Clean the filter under the water tap. clockwise direction to open it, without removing. Let the water flow out. 11. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages.
-
Page 40: Cleaning The Inlet Hose And The Valve Filter
When you drain the water with the 3. Clean the valve filter on the back of the emergency drain procedure, you must appliance with a toothbrush. activate the drain system again: a. Put 2 litres of water in the main wash compartment of the detergent dispenser. -
Page 41: Frost Precautions
1. Put 2 litres of water in the main wash 4. Empty the drain pump. Refer to the compartment of the detergent dispenser. emergency drain procedure. 2. Start the programme to drain the water. 5. When the drain pump is empty, install the inlet hose again. - Page 42 With some problems, the display shows an alarm code and the Start/ Pause button may flash continuously: If the appliance is overloaded, remove some items from the drum and/or keep pressed the door while touching the Start/Pause button until the indicator stops flashing (see the picture below).
- Page 43 • Wait until mains supply is stable. The mains supply is unsta‐ ble. • Disconnect the appliance and close the water tap. Contact the Authorised Service Centre. The anti-flood device is on. If the display shows other alarm codes, deactivate and activate the appliance.
- Page 44 Problem Possible solution • Check the wireless signal. • Make sure that the wireless connection is on. Refer to paragraph "Configuring the washing machine wireless connection" in "Wi-Fi - Connectivity setup" chapter. The display does not show the wireless indicator •...
-
Page 45: Emergency Door Opening
After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre. The necessary data for the service centre are on the rating plate. 15.2 Emergency door opening To open the door, proceed as follows: In case of power failure or functioning failure 1. -
Page 46: Consumption Values
16. CONSUMPTION VALUES 16.1 Comment The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance. -
Page 47: Quick Guide
Programme Litres hh:mm °C Cottons 1.800 95.0 03:00 44.00 55.0 1600 60°C Cottons 0.300 95.0 02:50 44.00 20.0 1600 20°C Synthetics 0.600 60.0 02:10 35.00 40.0 1200 40°C Delicates 0.350 55.0 01:10 35.00 30.0 1200 30°C Wool 0.250 50.0 01:10 30.00 30.0 1200... -
Page 48: Cleaning The Drain Pump Filter
17.2 Cleaning the drain pump filter 180˚ Clean the filter regularly and, especially, if the alarm code appears on the display. 17.3 Programmes Programmes Load Product description Cotton and synthetic items. This programme ensures a good washing performance in a short time. The standard program duration has been developed on a laun‐... -
Page 49: Environmental Concerns
Programmes Load Product description All fabrics, except woollens and very delicate fabrics. Pro‐ 8.0 kg gramme for rinsing and spinning. Rinse To spin the laundry and to drain the water in the drum. All fab‐ 8.0 kg rics, except woollens and delicate fabrics. Spin/Drain Washing programme. - Page 52 The software in this product contains components that are based on free and open source software. AEG gratefully acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://aeg.opensoftwarerepository.com (folder NIUS)
