L6SNE26SC
USER
MANUAL
EN
User Manual
Washing Machine

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L6SNE26SC and is the answer not in the manual?

Questions and answers

Related Manuals for AEG L6SNE26SC

Summary of Contents for AEG L6SNE26SC

  • Page 1 L6SNE26SC User Manual Washing Machine USER MANUAL...

  • Page 2: Table Of Contents

    18. ENVIRONMENTAL CONCERNS..............39 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments; areas for communal use in blocks of flats or in – launderettes. The appliance maximum load is 6 kg. Do not exceed •...

  • Page 5: Electrical Connection

    ENGLISH • Follow the installation instructions • Connect the mains plug to the mains supplied with the appliance. socket only at the end of the • Do not install or use a damaged installation. Make sure that there is appliance. access to the mains plug after the •...

  • Page 6: Product Description

    Prewash such fabrics by hand before pressure switches, thermostats and loading them into the washing sensors, software and firmware machine. including reset software, door, door • Do not touch the glass door while a hinge and seals, other seals, door programme operates.

  • Page 7: Appliance Overview

    ENGLISH 3.2 Appliance overview Worktop Drain hose Detergent dispenser Inlet hose connection Control panel Mains cable Door handle Transit bolts Rating plate Hose support Drain pump filter Feet for levelling the appliance The rating plate reports the model name (A) , product number (B), electrical ratings (C) and serial number (D).

  • Page 8: Installation

    Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, ex‐ cept where the low voltage equipment has no pro‐ tection against moisture Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 10 bar (1.0 MPa)

  • Page 9: Positioning And Levelling

    ENGLISH 6. Put the appliance back into an We recommend that you upright position. Remove the power keep the packaging and supply cable and the drain hose from the transit bolts for any the hose holder. transport of the appliance. 5.2 Positioning and levelling Adjust the appliance correctly to prevent vibration, noise and movement of the...

  • Page 10: The Inlet Hose

    5.3 The inlet hose You can extend the drain hose to maximum 4000 mm. 1. Connect the water inlet hose to the Contact the authorised back of the appliance. service centre for the other 2. Position it toward left or right...
  • Page 11 ENGLISH a loop to prevent particles going into the appliance from the sink. 6. Position the hose directly to a built-in drain pipe in the room wall and tighten it with a clamp. 4. To a stand pipe with vent-hole - Insert the drain hose directly into a drain pipe.

  • Page 12: Accessories

    Read carefully the instructions supplied Read carefully the instructions supplied with the accessory. with the accessory. Only appropriate accessories approved by AEG ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 7. CONTROL PANEL 7.1 Control panel description...
  • Page 13 ENGLISH 7.2 Display Maximum load indicator. The icon flashes during programme time es‐ timation (refer to "PROSENSE load detection" paragraph). Delay start indicator. Door locked indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. •...

  • Page 14: Dial And Buttons

    8. DIAL AND BUTTONS 8.1 Zap./Vyp. The display shows only the spin speeds available Pressing this button for a few seconds for the set programme. allows to activate or deactivate the • Activate the Rinse Hold option. appliance. Two different tunes sound The final spin is not performed.

  • Page 15: Odložený Start

    ENGLISH containing sand, dust , mud and other The display shows the indicator solid particles. (cold), and the indicator The options can increase the spin) and the indicator programme duration. • Activate the spin-only option (Skipping the wash and rinse 8.6 Jemné+ phases): Pouze odstřeďování.

  • Page 16: Programmes

    • If your laundry is normally or lightly This option removes micro-organisms soiled, it may be advisable to shorten thanks to a washing phase with the the washing programme. Touch this temperature maintained above 60°C for button once to decrease the duration.
  • Page 17 ENGLISH Programme Programme description Special programme for one down jackets, synthetic blanket, duvet, bedspread and so on. Péřová bunda Do not use fabric softener and make sure that Outdoor there is no softener residue in the detergent dispenser. Outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets with a removable fleece or inner insulation.
  • Page 18 Programme Default tempera‐ Reference spin Maximum load ture speed Temperature Spin speed range range 40 °C 1200 rpm 3 kg 60 °C - Cold 1200 rpm - 400 rpm Syntetika 30 °C 1200 rpm 1 kg 40 °C - Cold 1200 rpm - 400 rpm Jemné...
  • Page 19 ENGLISH Programme options compatibility Odstřeďování ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Rinse Hold ■ ■ ■ ■ ■ Extra Silent Pouze vypouštění ■ ■ ■ ■ ■ ■ ■...

  • Page 20: Settings

    Programme Universal Liquid Uni‐ Liquid for Delicates Special versal coloureds woollens powder Jemné prádlo ▲ ▲ ▲ ▲ Vlna/Hedvábí 20 min. - 3 kg ▲ ▲ ▲ ▲ ▲ Snadné žeh‐ lení ▲ ▲ Péřová bun‐ Outdoor ▲ ▲...

  • Page 21: Daily Use

    ENGLISH programme dial are deactivated To deactivate/activate the acoustic (except Zap./Vyp. button ). signals when the programme is • Before you touch the Start/Pauza completed, touch the Skvrny/Předpírka button: the appliance cannot start. and the Antialergický buttons The appliance keeps the selection of this simultaneously for about 6 seconds.

  • Page 22: Using Detergent And Additives

    Always obey the instructions that you find on the packaging of the detergent products. Detergent compartment for pre‐ wash phase or soak programme (if available). Add the detergent for prewash and soak before the start of the programme. Detergent compartment for washing phase.

  • Page 23: Setting A Programme

    ENGLISH 12.5 Setting a programme 1. Turn the programme dial to select the desired washing programme. The related programme indicator comes The indicator of the Start/Pauza button flashes. The display shows the maximum declared load for the programme, the default temperature, the default spin speed, the washing phase indicators (when available) and an indicative The position B of the detergent...

  • Page 24: Cancelling The Delay Start After The Countdown Has Started

    12.9 Programme phase The PROSENSE adapts starts at the end of the indicators countdown. When the programme starts the indicator Cancelling the delay start of the running phase flashes and the after the countdown has other phase indicators are steady on.

  • Page 25: Opening The Door - Adding Garments

    ENGLISH 12.12 Opening the door - 2. Remove the laundry from the appliance. Adding garments 3. Make sure that the drum is empty. 4. Keep the door and the detergent dispenser slightly ajar to prevent While a programme or the delay start mildew and odours.

  • Page 26: Stand-By Option

    12.15 Stand-by option The display shows the end of the last set programme. The Stand-by function automatically Turn the programme dial to set a new deactivates the appliance to decrease cycle. the energy consumption when: If you set a programme or an •...

  • Page 27: Care And Cleaning

    ENGLISH wash performance, but also helps to • sudsing, avoid waste and protect the environment: • reduced washing effect, • inadequate rinsing, • Use only detergents and other • a greater impact for the environment. treatments specially made for washing machines. First, follow these 13.4 Ecological hints generic rules: –...

  • Page 28: Removing Foreign Objects

    Indicative periodic cleaning schedule: The regular detergents already contain water softening agents, but we Descaling Twice a year recommend to run a cycle with empty drum and a descaling product Maintenance wash Once a month occasionally. Clean door seal...

  • Page 29: Cleaning The Drum

    ENGLISH Always obey the instructions that you find on the packaging of the product. 14.7 Cleaning the drum Regularly examine the drum to prevent unwanted deposits. Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron.

  • Page 30: Cleaning The Drain Pump

    14.9 Cleaning the drain pump Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: • The appliance does not drain the water. • The drum does not turn. • The appliance makes an unusual noise because of the blockage of the drain pump.
  • Page 31 ENGLISH WARNING! Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. Make sure also that you tighten the filter correctly to prevent leakages.

  • Page 32: Cleaning The Inlet Hose And The Valve Filter

    When you drain the water with the emergency drain procedure, you must activate the drain system again: 1. Put 2 litres of water in the main wash compartment of the detergent dispenser. 2. Start the programme to drain the water.

  • Page 33: Troubleshooting

    ENGLISH WARNING! Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. 15. TROUBLESHOOTING WARNING! Refer to Safety chapters. 15.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation.
  • Page 34 • Make sure that the door is properly closed. The appliance door is open or not closed correctly. • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. Internal fail. No com‐...

  • Page 35: Consumption Values

    ENGLISH Problem Possible solution • Make sure that a washing programme that ends with water in tub, has not been selected. • Make sure that the washing programme is finished. You cannot open the • Set the drain or the spin programme if there is water in the appliance door.
  • Page 36 The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance.

  • Page 37: Quick Guide

    ENGLISH 16.4 Common programmes These values are indicative only. Programme Litres h:mm °C Bavlna 2.15 3:55 1200 95°C Bavlna 1.50 3:25 1200 60°C Bavlna 0.30 2:10 1200 20°C Syntetika 0.75 2:10 1200 40°C Jemné prádlo 0.30 0:50 1200 30°C Vlna/Hedvábí 0.20 1:05 1200...

  • Page 38: Cleaning The Drain Pump Filter

    2. Set the desired options by means of At the end of the programme, remove the the corresponding touch buttons. laundry. 3. To start the programme, touch the Start/Pauza button. 17.2 Cleaning the drain pump filter Clean the filter regularly and, especially,...

  • Page 39: Environmental Concerns

    ENGLISH 18. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste. Return the Put the packaging in relevant containers product to your local recycling facility or to recycle it. Help protect the contact your municipal office. environment and human health by recycling waste of electrical and electronic appliances.
  • Page 40 www.aeg.com/shop...
