Sealey BT06 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
Refer to
instruction
manual
1. SAFETY
Ensure that the tester is in good condition before use.
9
If the battery terminals are corroded or dirty clean them before using the tester.
9
Keep children and unauthorised persons away from the work area.
9
DO NOT disassemble the tester for any reason. The tester must only be checked by qualified service personnel.
8
DO NOT in damp, or wet locations and DO NOT use in the vicinity of flammable liquids or gases.
8
DO NOT use the tester for a task for which it is not designed.
8
DO NOT short the terminals of any battery.
8
For different instruments which use battery for power, the required battery charge level may vary. Refer to the instrument's user manual
9
for detailed information.
When not in use, store the tester carefully in a safe, dry, childproof location.
9
2. INTRODUCTION
Easy to use, with colour coded analogue display needle; Good/Green, Low/Yellow, Replace or Recharge/Red. Tests levels of AAA, AA, C, D,
1.5V, 9V and button type batteries, household and automotive fuses and domestic filament bulbs. Audible continuity tester via test probes
(supplied). Lightweight and compact design for easy portability. Not to be used to test lead acid batteries. Operated by 9V battery (supplied).
3. SPECIFICATION
Model No: ..................................................................... BT06
Power: ................................................................... 9V Battery
Weight: ...................................................................... 0.180kg
4. FEATURES
1, 4: Metal contacts for testing 1.5V batteries
2, 3: Metal contacts for testing fuses
7, 8, 9: Metal contacts for testing bulbs
10, 11: Metal contacts for testing 9V batteries
5: Display scales
6: Needle
12: Jack plugs for test leads
13: Storage compartment
5. FIT BATTERY
5.1. Slide off battery compartment cover on rear of battery.
5.2. Connect cable to battery terminals, install battery, refit cover.
NOTE: Use this tester to test the 9V battery.
© Jack Sealey Limited
MULTIPURPOSE BATTERY, BULB, FUSE AND
CONTINUITY TESTER
BT06
MODEL NO:
Original Language Version
fig.1
BT06 Issue 1 02/10/24
