CD RDS RECEIVER
DEH-6350SD
DEH-6350SD
This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-3269
CRT4488
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2010
Mech. Module
S11.1STD-DOUT
CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
DEH-6350SD/XSES
/XSCN5
Remarks
ORDER NO.
CRT4641
/XSES
K-ZZZ NOV. 2010 Printed in Japan
