- Page 1 COLOR TELEVISION AV-21M201/29M201 INSTRUCTIONS...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONNECTIONS Front & Rear Panel Diagrams ....... 3 Thank you for purchasing this JVC color Connecting the Antenna and VCR ......4 television. Connecting other External Devices ....... 4 To ensure your complete understanding, GETTING STARTED please read this manual thoroughly be- Remote Control ............ -
Page 3: Connections
C O N N E C T I O N S FRONT & REAR PANEL DIAGRAMS Front Panel Rear Panel... -
Page 4: Connecting The Antenna And Vcr
C O N N E C T I O N S CONNECTING THE ANTENNA AND VCR • For further details, refer to the manuals provided with the devices you are connecting. • Connecting cables are not supplied. VHF/UHF outdoor antenna If not connecting a VCR, do 1. - Page 5 C O N N E C T I O N S CONNECTING OTHER EXTERNAL DEVICES Note: When connecting mon- aural audio to the TV, use the L/MONO jack. Note: The sound and picture that you are watching are output from VIDEO/ AUDIO (L/R) output Illustration of AV-T2122 jacks on the rear panel.
-
Page 6: Getting Started
G E T T I N G S T A R T E D REMOTE CONTROL RM-C373 CHANGING THE BATTERIES Be sure to use only size AA/R6/UM-3 batteries. Raise the latch on the remote's back cover to remove it. Insert the two supplied batteries, carefully noting the “+”... -
Page 7: Power
G E T T I N G S T A R T E D POWER Press the Power button ( ) on the TV front panel. The Power lamp will light red. If the TV will not be turned on even if you press the P button, the TV is in the stand-by OWER mode. -
Page 8: Using The Menu
U S I N G T H E M E N U INITIAL SETUP ITEMS USING THIS GUIDE: Throughout this guide there are certain symbols AUTO TUNER SETUP NOISE MUTING ON OFF we use as shorthand to show you what to do. BACKGROUND BLACK CLEAR When you see them, keep these factors in mind:... -
Page 9: Initial Setup
I N I T I A L S E T U P AUTO TUNER SETUP CLOSED CAPTION NOTE: During Auto Tuner Setup, the TV will If they are included in a program, you automatically scan through all avail- can view closed captions or text infor- During Initial able channels and memorize the mation. -
Page 10: Tint
P I C T U R E S E T T I N G S TINT (NTSC ONLY) BRIGHT NOTE: Tint allows you to adjust the levels of Adjust the degree of light and dark in To exit the Picture red and green in the picture. -
Page 11: Sound Settings
S O U N D S E T T I N G S BASS MTS (Multi-Channel The Bass level adjustment feature Television Sound) allows you to increase or decrease the MTS technology gives you a choice level of lower frequencies in the TV’s among stereo, mono, and Second sound. -
Page 12: General Items
G E N E R A L I T E M S SET CLOCK ON/OFF TIMER The Clock is the heart of all timer Use the On/Off Timer as an alarm to functions. You must set the clock wake up, as a program reminder, or as before any timer functions will work. -
Page 13: Channel Summary
G E N E R A L I T E M S CHANNEL SUMMARY CHANNEL GUARD - LOCK NOTES: You can add or delete channels from the channel scanning. You can also There are two œ❷ To CHANNEL SUMMARY sections in lock out any “unauthorized”... -
Page 14: Set Lock Code
G E N E R A L I T E M S SET LOCK CODE CHILD LOCK The Lock Code locks and unlocks You can disable the front control Channel Guard. Write this three digit buttons of the TV. number down and keep it where When this function is set to ON, the TV would-be viewers will not look for it! can be operated using only the re-... -
Page 15: Button Functions
B U T T O N F U N C T I O N S DISPLAY VIDEO STATUS NOTE: The Display screen shows the current The Video Status button lets you status of timers and inputs. select the settings when you play a Please note that game, watch a movie, or want to reset if the clock,... -
Page 16: Number Buttons (10 Key Pad)
B U T T O N F U N C T I O N S TV / VIDEO NUMBER BUTTONS TV/Video selects the input mode. 10 KEY PAD Press two of the number buttons to move TV/V IDEO to single and double digit channels. >... -
Page 17: Return
B U T T O N F U N C T I O N S RETURN+ PICTURE BOOSTER There are two kinds of Return. You can select the sharpness of picture when receiving RF. Return+ — Set a “Return Channel” to return to after scanning with C HANNEL ICTURE... -
Page 18: Troubleshooting
T R O U B L E S H O O T I N G PROBLEMS CHECK There is no power • See if the power cord became unplugged. • Perhaps you have experienced a blown circuit breaker or fuse or a power outage. There is no picture •... -
Page 19: Specifications
S P E C I F I C A T I O N S AV-T2122 MODEL PAL-M, PAL-N, NTSC-M Color systems M, N TV RF systems VHF 2 to 13, VHF 14 to 69 Channels Sub Mid, Super, Hyper and Ultra bands BTSC (Multi Channel Sound) Sound-multiplex system AC 110 to 240 V, 50/60 Hz (operating AC 90 to 260 V, 50/60 Hz) - Page 20 VICTOR COMPANY OF JAPAN, LIMITED LCT1040-001A-D 0601-TN-JII-AUD...
