COLOUR TELEVISION AV-29BS26 AV-21BS26 AV-29BX16 AV-21BX16 AV-29MS26 AV-21BX16B AV-29MX16 AV-21MS26 AV-29MX56 AV-21MX16 AV-29MX76 AV-21MX56 AV-29SS26 AV-21MX76 AV-29SX56 AV-29SX76 AV-25MS26 AV-25MX16 AV-25MX56 AV-25MX76 EQUALIZER • CINEMA SURROUND • COMPONENT INPUT Contents Knowing your TV’s features ...3 Remote control buttons and basic functions ...4 TV buttons and functions ...6...
Never rub it forcefully. Never use any cleaner or detergent on it. Thank you for buying this JVC colour television. 7 This TV can be turned on/off power by connecting/disconnecting the AC plug into AC outlet. While this TV is being installed, enough space should be reserved for connection/disconnecting the AC plug into AC outlet by hand.
Knowing your TV’s features Main features DVD MENU MaxxBass EXIT PIP (Picture In Picture) TELETEXT FAVORITE CH (Channel) A2/NICAM (STEREO / I . II) AI ECO SENSOR ECO MODE AI VOLUME TINT Conﬁ rm your TV’s functions Some functions written in this instruction manual may not be available for your TV. Please see the chart below and check the functions that are equipped for your TV’s model number.
Remote control buttons and basic functions No. Press 1 POWER Turn on or off the TV from standby mode. 2 MENU/OK Display menu and conﬁ rm selected function. 3 5 / ∞ / 2 / 3 Select and adjust menu function. 4 CHANNEL -/+ Select the desired channel number.
Remote control buttons and basic functions (continued) How to operate menus and menus locations Operation Display the MENU Press the MENU/OK button 2. PICTURE MENU is displayed on ﬁ rst press. Press 2/3 buttons 3 to choose Choose a Top menu a menu title when the cursor is pointing at MENU.
TV buttons and functions The illustrations shown below is for AV-21BS26 and AV-29SS26 only, which are used for explanation purpose. Your TV may not look exactly the same as illustrated. Front of the TV AV-29SS26 POWER TV/VIDEO MENU/OK CHANNEL VOLUME...
(VIDEO-2) OUTPUT INPUT MONO JVC logo will appear on the screen again at the phase of “SETUP TOUR RESTART?” function. Then the initial setting can be performed according to page 8. Note: While in the INSTALL menu with the cursor pointing at INSTALL, pressing the blue button will also display the JVC logo.
Setting up your TV (continued) Making the initial settings Set up your TV by pressing MENU/OK button or waiting for 15 seconds, then operate the TV by following the steps below: LANGUAGE TEXT LANGUAGE TEXT LANGUAGE ENGLISH GROUP–1 êìëëäàâ GROUP–2 GROUP–3 GROUP–4 FRANÇAIS...
Basic setting for picture COLOUR SYSTEM You can select the appropriate colour system when the picture is not clear or no colour appears. Press the COLOUR SYSTEM button to select a setting. AUTO SECAM NTSC4.43 To operate this function with a menu: MENU INSTALL menu COLOUR SYSTEM...
Basic setting for picture (continued) PICTURE SETTING You can adjust the desired picture setting when selecting USER in PICTURE MODE. Select USER in PICTURE MODE under PICTURE menu. MENU PICTURE menu USER Select PICTURE SETTING in PICTURE menu, then adjust the setting.
Advanced setting for picture AI ECO SENSOR (ECO)/ECO MODE You can adjust TV screen contrast according to the brightness of your room. Press the ECO button to select the desired mode. Cancel the function. MODE-1/ECO-1 Mild contrast (recommended.) MODE-2/ECO-2 Even contrast. DISPLAY (for AI ECO SENSOR only) Display the graphic of the function.
Original features for picture You can display a sub picture within the main picture on the screen. Press the PIP operation buttons to display and change the sub picture setting. PIP Display the sub picture. To cancel, press the PIP button again. Notes: •...
Original features for picture (continued) TEXT LANGUAGE You can set the Teletext language group that corresponds to the programmes. Select TEXT LANGUAGE in the INSTALL menu, then choose the desired language group. MENU INSTALL menu GROUP-1 English, German, Swedish, Finnish, Danish, Hungarian, Italian, French, Spanish, Portuguese, Turkish GROUP-2 Polish, German, Estonian, Slovenian, Czech, Slovakian,...
Basic setting for sound SOUND SYSTEM You can select an appropriate sound system when abnormal sound occurs even when the picture appears normally. Press the SOUND SYSTEM button to select a setting. This function is not available in video mode. For the sound system in each country or region, see the table below: Area Country or Region...
Advanced setting for sound CINEMA SURROUND You can enjoy an enhanced sound for wider audience. Press the CINEMA SURROUND button to select a setting. Cancel the function. Listen to sound with wider audience effect. This function is not available when SOUND MODE is set to SOUND TURBO.
DVD Menu AUTO SIGNAL DETECT When the DVD input signal is detected, the input mode will be changed to VIDEO-2 automatically. And when the DVD input signal is not detected, the input mode will be changed to RF previous input mode. Select AUTO SIGNAL DETECT in DVD MENU under FEATURES menu then choose ON or OFF (Factory setting is ON).
Customized setting You can reduce the picture noise. Select VNR in PICTURE menu, then choose a setting of VNR function. MENU PICTURE menu VNR is turned off. AUTO Effect of VNR is automatically controlled. Effect of VNR becomes minimum level. Effect of VNR becomes maximum level.
Customized setting (continued) VIDEO-2 SETTING You can set the VIDEO-2 SETTING according to the video signal output from external devices connected to the VIDEO-2 terminal. Select VIDEO-2 SETTING in INSTALL menu, then choose a setting (Factory setting is COMPONENT). MENU INSTALL menu VIDEO If a normal video signal (composite video signal) is input.
TV channel presetting To register the TV channels automatically (AUTO PROGRAM) You can register the TV channels into the TV’s channel list automatically. Display the INSTALL menu. MENU INSTALL menu Choose AUTO PROGRAM, then press the MENU/OK button. AUTO PROGRAM function starts, and the channels received are registered in the channel list (PR LIST) automatically.
TV channel presetting (continued) To edit the channel list (PR LIST) (MOVE and DELETE in the EDIT menu) You can edit the TV channel list as you like. Note: After this operation, other channel’s PR numbers will be changed. Display the INSTALL menu. MENU INSTALL menu Choose EDIT/MANUAL, then press the MENU/OK button.
TV channel presetting (continued) CH/CC number When you want to use the INSERT function on page 20, find the CH/CC number corresponding to the channel number of the TV channel from this table. Channel No. Country United States, Philippines, etc.. CCIR Middle East, Southeast Asia, etc..
Additional preparation The illustrations shown in this section are for AV-21BS26 and AV- 29SS26 only, which are used for explanation purpose. Your TV may not look exactly the same as illustrated. Before connecting • Read the manuals provided with the devices for the proper connection.
Troubleshooting If a problem occurs when you are using the TV, check the below troubleshooting guide before calling for repair. • No picture, no sound • Deactivate the BLUE BACK function if it is turned on. • Choose the appropriate sound system. Refer to “SOUND SYSTEM”...
Speciﬁ cations TV RF systems B, G, I, D, K, M Colour systems PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz Receiving channels VHF low channel (VL), VHF high channel (VH), UHF channel (U) Receives cable channels in mid band, super band and hyper band. Power requirements For Australia: AC 220 to 240 V, 50 Hz / 60 Hz...
