Sharper Image LYRA Quick Start Manual

DRONE LYRA 6.68INCH
8+
Contents
1 Drone
1 Remote Control
1 Micro USB Cable
1 Sticker Sheet
Battery Installation
Remote control:
1. Use a tool to press the button and release the battery
cover on the back of the remote control. Slide the
battery cover down to remove it.
2. Insert 3 AAA 1.5V batteries (not included) in the same
orientation as shown.
3. Slide the battery cover securely back into place.
Power Button
Speed
Left Joystick
Emergency Stop
Left / Right Trim
Power and Pairing
1. Plug the Micro USB charging cable into the Micro USB charging port on the drone. The indicator
light on the drone will light up while the drone is charging and will turn o when the drone is fully
charged. Once the drone is fully charged, unplug the Micro USB charging cable.
2. Place the drone on a level and solid surface to ensure a steady takeo .
3. Press the power button on the remote control to power on the remote control. The indicator light
on the remote control will fade on and o slowly to indicate the remote control is in pairing mode
and ready to pair with the drone.
4. Press the power button on the drone to power on the drone. The indicator light on the drone will
fade on and o to indicate the drone is in pairing mode and ready to pair with the remote control.
5. Push the left stick forward and quickly backward to pair the remote control to the drone. Once
successfully paired, the remote control will play a notification sound and the indicator lights on the
remote control and drone will both remain solidly lit.
6. If the remote control and drone do not pair successfully within 60 seconds, both the remote control
and drone will enter sleep mode. Power o and power on both the remote control and drone to
retry the pairing process.
7. If the connection between the remote control and drone is interrupted, the remote control and
drone will automatically enter pairing mode and attempt to pair again. The indicator lights on both
the remote control and drone will begin to fade on and o and then will remain solidly lit when
paired again. If the indicator light on either the remote control or drone does not begin to fade on
and o , either the remote control or drone has not entered pairing mode, and they will not
automatically pair again. Power o and power on both the remote control and drone to retry the
pairing process. If the indicator light on the remote control does not power on, change the batteries
in the remote control. If the indicator light on the drone does not power on, recharge the drone.
8. If there is no input on the remote control for 5 minutes, the remote control and drone will enter
sleep mode. To wake from sleep mode, press the power buttons on the remote control and drone.
9. To manually power o the remote control and drone, press the power buttons on the remote
control and drone again.
Controls
1. Choose either auto takeo or manual takeo to launch the drone.
2. Auto Takeo : Press the assisted flight button to launch the drone automatically. The drone will fly
up and hover at an altitude between 1.5 m and 2 m.
3. Manual Takeo : Press the left stick forward to launch the drone up to a chosen altitude and then
release the left stick to make the drone hover at that altitude.
4. After takeo , the drone should hover in place if there is no input from the remote control (minor
drift is to be expected when flying outdoors). Press the left / right trim and front / back trim
buttons as needed to calibrate the neutral flight of the drone and reduce any drift.
5. Push the left stick forward to fly the drone up and pull the left stick backward to fly the drone
down.
6. Push the left stick to the right to spin the drone clockwise and push the left stick to the left to spin
the drone counterclockwise.
7. Push the right stick forward to fly the drone forward and pull the right stick backward to fly the
drone backward.
8. Push the right stick to the right to fly the drone right and push the right stick to the left to fly the
drone left.
CONTENTS AND BATTERY INSTALLATION
Top
Indicator Light
Flight
Right Joystick
Auto Orientation
Front / Back Trim
9. Press the auto orientation button to activate auto orientation mode. Press it again to deactivate this
mode.
a. The drone will always move in the direction you press the right joystick in relation to the remote
control, no matter which direction the drone is currently facing.
b. Pressing the right joystick up will make the drone fly away from the remote control, and
pressing the right joystick down will make the drone fly towards the remote control.
c. When auto orientation is active, the remote control will beep every 6 seconds.
If the drone has stability issues after an impact, reset the gyroscope by simultaneously pointing the
left joystick to the bottom left and the right joystick to the bottom right as shown. The lights on the
drone will flash to indicate recalibration was successful and the drone is ready for flight.
If the resetting the gyroscope does not resolve the issue, power o and power on the drone and
remote control and pair both again.
Note: The recalibration process in step 1 can be used to clear previous trim settings before flights.
10. Press the speed button to switch to high speed. The remote control will beep twice.
11. Press the speed button again to switch to low speed. The remote control will beep once. Low
speed is the default flight mode and will be activated each time the remote control and drone are
paired.
12. Choose manual landing or auto landing to land the drone.
13. Manual Landing: Starting with the drone at any altitude, pull and hold the left stick backward to fly
the drone down slowly. When the drone lands, the propellers will shut o automatically within 3
seconds.
14. Auto Landing: Starting with the drone at any altitude, press assisted flight button and the drone
will automatically slowly land. The left stick will stop controlling whether the drone flies up or
down but will still control clockwise and counterclockwise spin. The right stick will continue to
function as normal. When the drone lands, the propellers will shut o within 3 seconds.
Note: If connection is lost during normal flight, the drone will hover and attempt to pair to the remote
control for 5 seconds. If pairing is unsuccessful, the drone will begin auto landing.
15. In the event of an emergency, press and hold the emergency stop button for 2 seconds. All the
propellers will stop immediately, and the drone will fall.
IMPORTANT: Only use the emergency stop when necessary. Unnecessary falls may damage or
destroy the drone.
16. Once the drone has landed and the propellers have stopped spinning, press the power buttons on
the remote control and drone to power o both.
Power Button
Indicator
Light
Bottom
Battery Cover Release
USB
Charging port
