3 INSTALLATION
3.1 Unpacking
Carefully open the shipping carton and check for any
noticeable damage. Every Lab.gruppen amplifier is
tested and inspected before leaving the factory and
should arrive in perfect condition. If any damage
is discovered, please notify the shipping company
immediately. Only the consignee may institute a claim
with the carrier for damage incurred during shipping.
Save the carton and packing materials for the carrier's
inspection. Should you ever need to ship the amplifier,
always use the original packaging materials.
Figure 3.2b: Use washer for fixed installation
3.2 Mounting
Free airflow from front-to-rear of the amplifier must
be possible. Therefore, no doors or rack-lids should
be mounted in front of or behind the amplifiers.
Amplifiers may be stacked directly on top of each
other. There is no need for spacing in between units,
though this might enable more convenient installation
of cabling on the rear panel.
It is recommended that rear supports be mounted for
maximum long-term stability. Rear support brackets
are included.
2x
2x
2x
Figure 3.2c: Use tube for slide-on installation.
2x
Figure 3.2a: Rear support mounting hardware
