Whirlpool AFB18402 Quick Manual

Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
CONTROL PANEL
ON/STAND-BY
Press the button for 3 seconds to turn the appliance off. In
Stand-by mode the light in the refrigerator compartment does not turn
on. Press the button again briefly to reactivate the appliance.
Note: this does not disconnect the appliance from the power supply.
TEMPERATURE DISPLAY
The display may alternately show the freezer compartment between
(-16°C and -24°C).
To avoid an increase of food waste, refer to recommended setting and
Storage Time in User manual online.
TURNING OFF THE SOUND ALARM
To turn off the sound alarm, briefly press the
FREEZER COMPARTMENT TEMPERATURE
It is possible to set a different temperature with the "Freezer" button.
Recommended setting:
Freezer compartment: -18°C
FAST FREEZE
Press the "Freezer" button for 3 seconds 24 hours before
putting large quantities of food to freeze in the freezer compartment.
When the function is turned on the icon lights up
The function turns off automatically after 48 hours, or manually by
pressing the "Freezer" button again for 3 seconds.
Note: avoid a direct contact between the fresh food and the food that is
already frozen. To optimise the freezing speed, drawers can be removed
and the food can be placed directly on the bottom of the compartment.
BLACK OUT ALARM
This alarm is triggered in the event of a prolonged power
outage that has caused the temperature inside the freezer
compartment to rise. The red indicator light flashes
signal is triggered, which will remain active until the door is closed.
The freezer compartment temperature indicators may flash. To turn
the sound signal off, press the "Turn off alarm" button
freezer compartment has not yet reached the temperature for the
optimal preservation of the food items, the temperature alarm may be
triggered (see temperature alarm). Check the food before consuming it.
* Available only on certain models
www . whirlpool . eu/ register
6. 1. 2.
5. 4.
button.
.
and an acoustic
. If the
Before using the appliance carefully read the Safety
Instruction.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally filled
appliance. Position the antibacterial anti-odour filter in the fan as
demonstrated in the filter packaging (if available). If the audible signal
sounds, it means that the temperature alarm has intervened: press the
button to switch off the acoustic alarms.
3.
ECO NIGHT FUNCTION (ECO NIGHT)
Eco Night function allows one to concentrate the energy
consumption of the product during off-peak time (usually coinciding
with night time), when energy is available in large quantity and it costs
less than during the day (only in specific countries –using multiple-rate
system based on off-peak times- check your rate plan with your utility
company). To activate the function, press the button Eco Night at the
reduced rate start time (depending on the specific rates plan). For
example, if the reduced rate applies starting at 10:00 p.m., press the
button that corresponds to that time. When the LED is ON, the function
is active. After you activate the function, the product automatically
starts to adapt the energy consumption to the time (i.e. Consuming
more energy during the night then during the day).
Important: In order to work properly, the function must be enabled
both during the night and during the day. The function will remain
enabled until deactivated (it will also be deactivated in the event of a
blackout, or whenever the appliance is turned off). To deactivate the
function, press the button again. When the LED is OFF, the function is
not active.
Note: the power consumption of the appliance is declared with the Eco
night function disabled.
FREEZE CONTROL
"Freeze Control" is an advanced technology that reduces
temperature fluctuations in the whole freezer compartment to
minimum, thanks to an innovative air system, totally independent from
the fridge. Freeze burns are reduced up to 50% and food preserves its
original quality and color. To activate/deactivate the "Freeze Control"
function press for 3 seconds the "Eco Night" button
works properly in a defined range of temperature: between -22°C and
-24°C. When the function is engaged and the current temperature in
the freezer is set to the warmer set point than -22°C, the temperature is
automatically set to -22°C to match the working range. If the function
is engaged and the user modify the freezer temperature out of the
working range, the function is automatically switched off. In case of
"Fast freeze" is engaged, the function "Freeze control" is inhibited until
the "Fast Freeze" function switched off.
1.
Temperature Display
2.
Freezer temperature - Fast freeze
3.
Turning off the sound alarm
4. Black out alarm
5. Eco Night function
6.
On/stand-by
EN
. The function
