MITSUBISHI ELECTRIC TRANE HVAC US
SPLIT-SYSTEM HEAT PUMP
TECHNICAL & SERVICE MANUAL
Indoor unit
[Model Name]
NTXCKS09A112BA
NTXCKS12A112BA
NTXCKS15A112BA
NTXCKS18A112BA
Model name
indication
INDOOR UNIT
WIRELESS REMOTE
CONTROLLER
(Option)
ON
RETURN SELECT
MENU
HOLD
OFF
WIRED REMOTE CONTROLLER
(Option)
No. TCHT013
CONTENTS
1. REFERENCE MANUAL ...................... 2
2. SAFETY PRECAUTION ...................... 2
4. SPECIFICATIONS ............................... 7
6. WIRING DIAGRAM ............................ 10
8. TROUBLESHOOTING ....................... 12
9. SPECIAL FUNCTION ........................ 26
10. 4-WAY AIRFLOW SYSTEM ............... 27
12. REMOTE CONTROLLER .................. 33
PARTS CATALOG (TCBT013)
August 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRANE HVAC US NTXMMX20A122AA and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric TRANE HVAC US NTXMMX20A122AA

Summary of Contents for Mitsubishi Electric TRANE HVAC US NTXMMX20A122AA

  • Page 1: Table Of Contents

    MITSUBISHI ELECTRIC TRANE HVAC US SPLIT-SYSTEM HEAT PUMP August 2023 No. TCHT013 TECHNICAL & SERVICE MANUAL Indoor unit [Model Name] NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA CONTENTS 1. REFERENCE MANUAL ...... 2 2. SAFETY PRECAUTION ...... 2 3. PARTS NAMES AND FUNCTIONS ..6 4.

  • Page 2: Reference Manual

    REFERENCE MANUAL OUTDOOR UNIT’S SERVICE MANUAL Model Name Service Manual No. / Parts catalog No. NTXMMX20A122AA NTXMMX20A122AC NTXMMX24/30A132AA NTXMMX36A142AA NTXMMX42A152AA NTXMPH20A122AA NTXMPH24/30A132AA NTXMMX20A122BA NTXMMX24/30A132BA NTXMMX36A142BA OBHT702 / OBBT702 NTXMMX42A152BA NTXMPH20A122BA NTXMPH24/30A132BA NTXMMX20A122CA NTXMMX24/30A132CA NTXMMX36A142CA NTXMMX42A152CA NTXMPH20A122CA NTXMPH24/30A132CA NTXMMX48/60A182BA NTXMPH36A142BA OCHT730 / OCBT730 NTXMPH42A152BA NTXMPH48A182BA NTXSKS09/12/15A112AA...
  • Page 3 Precautions during the repair service. Preparation before the repair service. • Prepare the proper tools. • Do not perform the work involving the electric parts • Prepare the proper protectors. with wet hands. • Provide adequate ventilation. • Do not pour water into the electric parts. •...

  • Page 4: Cautions For Service

    [1] Warning for service (1) Do not alter the unit. (2) For installation and relocation work, follow the instructions in the Installation Manual and use tools and pipe components specifically made for use with refrigerant specified in the outdoor unit installation manual. (3) Ask a dealer or an authorized technician to install, relocate and repair the unit.

  • Page 5: Service Tools

    Unit Electronic weighing scale [4] Service tools Use the below service tools as exclusive tools for R410A refrigerant. Tool name Specifications Gauge manifold · Use the existing fitting specifications . (UNF1/2) · Use high-tension side pressure of 5.3MPa·G [768.7 PSIG] or over. Charge hose ·...

  • Page 6: Parts Names And Functions

    PARTS NAMES AND FUNCTIONS Filter Removes dust and pollutants Horizontal Air Outlet from drawn in air. Sets horizontal airflow automatically during cooling or dehumidifying. Grille Auto Air Swing Vane Disperses airflow up and down and adjusts the angle of airflow direction. Air Intake Draws in air from room.

  • Page 7: Specifications

    SPECIFICATIONS Indoor unit service ref. NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA Mode Cooling Heating Cooling Heating Cooling Heating Cooling Heating Power supply (phase, cycle, voltage) Single phase 208/230 V, 60Hz Input [kW] 0.02 0.02 0.02 0.02 0.03 0.03 0.04 0.04 Current* 0.20 0.15 0.24 0.19...
  • Page 8 NOISE CRITERION CURVES <60Hz> <60Hz> NTXCKS09A112BA NTXCKS12A112BA NOTCH SPL(dB) LINE NOTCH SPL(dB) LINE High High Medium Medium NC-70 NC-70 NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 APPROXIMATE APPROXIMATE THRESHOLD OF THRESHOLD OF HEARING FOR HEARING FOR NC-20 NC-20 CONTINUOUS CONTINUOUS NOISE NOISE...

  • Page 9: Outlines And Dimensions

    OUTLINES AND DIMENSIONS NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA Unit: inch (mm) TCHT013...

  • Page 10: Wiring Diagram

    WIRING DIAGRAM NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA TCHT013...

  • Page 11: Refrigerant System Diagram

    REFRIGERANT SYSTEM DIAGRAM NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA Strainer Heat exchanger Refrigerant GAS pipe connection (Flare) Condenser/evaporator temperature thermistor (TH5) Refrigerant flow in cooling Refrigerant flow in heating Refrigerant LIQUID pipe connection (Flare) Pipe temperature thermistor/liquid Room temperature (TH2) thermistor (TH1) Strainer Distributor with strainer...

  • Page 12: Troubleshooting

    TROUBLESHOOTING 8-1. TROUBLESHOOTING <Check code displayed by self-diagnosis and actions to be taken for service (summary)> Present and past check codes are logged, and they can be displayed on the wired remote controller or controller board of out- door unit. Actions to be taken for service, which depends on whether or not the trouble is reoccurring in the field, are summa- rized in the table below.
  • Page 13 [Output pattern A] Errors detected by indoor unit Wired remote Wireless remote controller controller Symptom Remark Beeper sounds/OPERATION INDICATOR lamp blinks Check code (Number of times) Intake sensor error P2, P9 Pipe (liquid or 2-phase pipe) sensor error E6, E7 Indoor/outdoor unit communication error Float switch connector open Drain pump error...
  • Page 14 ● If the unit cannot be operated properly after test run, refer to the following table to find the cause. Symptom Cause Wired remote controller LED 1, 2 (PCB in outdoor unit) Please Wait For about 3 After LED 1, 2 are lit, LED 2 is turned •...
  • Page 15 Note: Errors to be detected in outdoor unit, such as codes starting with F, U or E (excluding E0 to E7), are not covered in this document. Please refer to the outdoor unit's service manual 8-3. SELF-DIAGNOSIS ACTION TABLE for the details. Check code Abnormal point and detection method Countermeasure...
  • Page 16 *1: only P-series outdoor unit Check code Abnormal point and detection method Countermeasure Cause Drain pump lock protection operation 12 Check if drain pump works. 1 Malfunction of drain pump 1 Suspected abnormality, if drain pump 2 Clogged drain pump Check if connector (CNP) is connected.
  • Page 17 *1: only P-series outdoor unit Check code Abnormal point and detection method Countermeasure Cause Pipe temperature thermistor/Condenser / Evaporator (TH5) 1 Defective thermistor 1– Check resistance value of thermistor. 1 The unit is in 3-minute resume protec- characteristics For characteristics, refer to (P1). tion mode if short/open of thermistor is detected.
  • Page 18 Abnormal point and detection method Countermeasure Check code Cause Remote controller transmission error(E3)/ signal receiving error(E5) 1 2 remote controllers are set as 1 Set a remote controller to main, and the other 1 Abnormal if remote controller could not “main.”...
  • Page 19 Check code Abnormal point and detection method Countermeasure Cause Forced compressor stop (due to water leakage abnormality) 1 The unit has a water leakage abnormality 1 Drain pump trouble 1 Check the drain pump. when the following conditions, a) and b), 2 Drain defective 2 Check whether water can be drained.
  • Page 20 8-4. TROUBLESHOOTING OF PROBLEMS Note: Refer to the manual of outdoor unit for the detail of remote controller. *1: only P-series outdoor unit Phenomena Cause Countermeasure (1) LED2 on indoor controller board • When LED1 on indoor controller board is also off. is off.
  • Page 21 Note: Refer to the outdoor unit's service manual for the detail of remote controller. Phenomena Cause Countermeasure (3)Upward/downward vane The vane is not downward during defrosting and heat Normal operation (The vane is set to hori- performance failure preparation and when the thermostat is OFF in HEAT zontal regardless of remote control.) mode.

  • Page 22: Test Point Diagram

    8-5. TEST POINT DIAGRAM 8-5-1. Indoor controller board NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA LED2 CN90 CN4Z CN22 Power supply Connect to the wireless i-see Sensor (Sensor) (Wired remote controller) remote controller board (CNB) Connect to the terminal black (TB5) (Remote controller transmission line) Vane motor (MV) 12 V pulse output Model selection...
  • Page 23 8-6. FUNCTION OF DIP SWITCH Each function is controlled by the DIP switch on the indoor controller board. Model setting and capacity setting are preset in the nonvolatile memory of the indoor controller board. ■ The black square ( ) indicates a switch position. Setting by the DIP switch and jumper wire Switch Functions...
  • Page 24 8-7. TROUBLESHOOTING OF MAIN PARTS NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA Parts name Check method and criterion Room temperature Measure the resistance with a tester. thermistor (TH1) (Parts temperature 50 to 86°F) Pipe temperature Normal thermistor/liquid (TH2) 4.3 to 9.6 k" Condenser/evaporator temperature thermistor (TH5) (Refer to "8-7-1.
  • Page 25 8-7-1. Thermistor Characteristic Graph < Thermistor for lower temperature > <Thermistor characteristic graph> Room temperature thermistor (TH1) Thermistor for Pipe temperature thermistor/liquid (TH2) lower temperature Condenser/evaporator temperature thermistor (TH5) Thermistor R =15 k" ± 3% Fixed number of B=3480 ± 2% t(˚C)Rt=15exp { 3480( 273+t T(˚F)Rt=15exp { 3480(...

  • Page 26: Special Function

    SPECIAL FUNCTION BACK-UP HEATING FUNCTION 9-1. Operation The back-up heater turns ON when both of the following conditions have been satisfied: A) When the room temperature has not risen after the heater ON delay time has passed. Note: The heater ON delay time starts when the condition of “set temperature − room temperature > 1°F [0.5°C]” has been satisfied. B) Set temperature −...

  • Page 27: Way Airflow System

    4-WAY AIRFLOW SYSTEM 10-1. FRESH AIR INTAKE (LOCATION FOR INSTALLATION) At the time of installation, use the duct holes (cut out) located at the positions shown in following diagram, as and when required. Fresh air intake Detail drawing of fresh air intake (Unit: inch) 5-17/32 Burring hole...
  • Page 28 10-4. FIXING HORIZONTAL VANE Horizontal vane of each air outlet can be fixed according to the environment where it is installed. Setting procedure 1) Turn off the main power supply (Turn off the breaker). 2) Remove the vane motor connector in the direction of the arrow shown below with pressing the unlocking button as in the figure below.

  • Page 29: Disassembly Procedure

    DISASSEMBLY PROCEDURE NTXCKS09A112BA NTXCKS12A112BA NTXCKS15A112BA NTXCKS18A112BA Be careful when removing heavy parts. OPERATING PROCEDURE PHOTOS/FIGURES 1. Removing the air intake grille and air filter Figure 1 Grille hook (1) Slide the knob of air intake grille to the direction of the arrow 1 to open the air intake grille.

  • Page 30: Operating Procedure

    OPERATING PROCEDURE PHOTOS/FIGURES 3. Removing the electrical parts Photo 4 (1) Loosen the 2 screws on the control box cover. Control box cover (2) Slide the control box cover as indicated by the arrow to remove. <Electrical parts in the control box> •...
  • Page 31 OPERATING PROCEDURE PHOTOS/FIGURES Photo 8 6. Removing the pipe temperature thermistor/liquid (TH2) Fan motor and pipe temperature thermistor/gas (TH5) Pipe temperature Band cable thermistor/gas (TH5) (1) Remove the panel. (Refer to procedure 2) (2) Remove the room temperature thermistor (TH1). (Refer to procedure 4) (3) Remove the drain pan.
  • Page 32 OPERATING PROCEDURE PHOTOS/FIGURES Photo 11 8. Removing the drain pump (DP) and float switch (FS) (1) Remove the panel. (Refer to procedure 2) Clamp (2) Remove the room temperature thermistor (TH1). (Refer Screw to procedure 4) Inner cover (3) Remove the control box cover. (Refer to procedure 3) (4) Remove the drain pan.

  • Page 33: Remote Controller

    REMOTE CONTROLLER 13-1. REMOTE CONTROLLER FUNCTIONS <TAR-41MAA> Controller interface The functions of the function buttons change depending on the screen. Refer to the button function guide that appears at the bottom of the LCD for the functions they serve on a given screen. When the system is centrally controlled, the button function guide that corresponds to the locked button will not appear.

  • Page 34: Room Temperature

    Display The main display can be displayed in two different modes: “Full” and “Basic”. The initial setting is “Full”. To switch to the “Basic” mode, change the setting on the Main display setting. (Refer to operation manual included with remote controller.) <Full mode>...
  • Page 35 Menu structure Main menu Press the button. MENU Move the cursor to the desired item with the buttons, and press the button. SELECT/HOLD Operation Vane · Louver · Vent. (Lossnay) High power Comfort Manual vane angle 3D i-See sensor Timer menu Timer ON/OFF timer Auto-OFF timer...
  • Page 36 Continue from the previous page. Maintenance menu Error information Filter information Cleaning Auto descending panel Descending operation Descending adjustment Service menu Test run menu Test run Drain pump test run Maintenance information Model name input Serial No. input Dealer information input Initialize maintenance info.

  • Page 37: Main Menu List

    Main menu list Main Setting and display items Setting details menu Operation Vane · Louver · Vent. Use to set the vane angle. (Lossnay) • Select a desired vane setting. Use to turn ON/OFF the louver. • Select a desired setting from "ON" and "OFF." Use to set the amount of ventilation.
  • Page 38 Setting and display Main menu Setting details items Initial Display Main display Use to switch between "Full" and "Basic" modes for the Main display, and use setting setting to change the background colors of the display to black. Display de- Make the settings for the remote controller related items as necessary.

  • Page 39: Controller Interface

    <PAR-SL101A-E> Controller interface Transmission area Remote controller display Set Temperature buttons OFF/ON button Mode button (Changes operation mode) Fan Speed button (Changes fan speed) Airflow button (Changes up/ i-see button* down airflow direction) Timer ON button Menu button Timer OFF button SET/SEND button Weekly timer ON/OFF button* CANCEL button...

  • Page 40: Error Information

    13-2. ERROR INFORMATION When an error occurs, the following screen will appear. Check the error status, stop the operation, and consult your dealer. 1. Check code, error unit, refrigerant address, model name, and se- Error information rial number will appear. Error code The model name and serial number will appear only if the informa- Error unit...
  • Page 41 • Checking the error information Maintenance menu While no errors are occurring, page 2/2 of the error information can be Error information viewed by selecting "Error information" from the Maintenance menu. Filter information Errors cannot be reset from this screen. Cleaning Main menu: RETURN Cursor...

  • Page 42: Service Menu

    13-3. SERVICE MENU Maintenance password is required 1. Select "Service" from the Main menu, and press the [SELECT/HOLD] button. Main Main menu *At the main display, the menu button and select "Service" to make the maintenance setting. Service 2. When the Service menu is selected, a window will appear asking for the pass- Service menu word.

  • Page 43: Test Run Operation

    13-4. TEST RUN 13-4-1. TAR-41MAA 1. Select "Service" from the Main menu, and press the [SELECT/HOLD] button. Test run Input maintenance info. Settings Check Select "Test run" with the F1 or F2 button, and press the [SELECT/HOLD] button. Others : RETURN SELECT MENU RETURN...
  • Page 44 13-4-2. PAR-SL101A-E 1. Press the button to stop the air conditioner. • If the weekly timer is enabled ( is on), press the button to disable it ( is off). 2. Press the button for 5 seconds. • comes on and the unit enters the service mode. 3.

  • Page 45: Function Setting

    13-5. FUNCTION SETTING Settings menu 13-5-1. TAR-41MAA Function setting 1. Select "Service" from the Main menu, and press the [SELECT/HOLD] button. Select "Setting" from the Service menu, and press the [SELECT/HOLD] button. Service menu: MENU Select "Function setting", and press the [SELECT/HOLD] button. SELECT MENU RETURN...
  • Page 46 13-5-2. PAR-SL101A-E 1. Going to the function select mode Press the button between of 5 seconds. (Start this operation from the status of remote controller display turned off.) [CHECK] is lit and "00" blinks. (Fig. 1) Press the button to set the "50". Direct the wireless remote controller toward the receiver of the indoor unit and press the button.

  • Page 47: Error History

    13-6. ERROR HISTORY 1. Select "Service" from the Main menu, and press the [SELECT/HOLD] button. Test run Input maintenance info. Settings Check Others : RETURN Select "Check" with the F1 or F2 button, and press the [SELECT/HOLD] button. SELECT MENU RETURN HOLD 2.

  • Page 48: Self-Diagnosis

    13-7. SELF-DIAGNOSIS 13-7-1. TAR-41MAA 1. Select "Service" from the Main menu, Diagnosis and press the [SELECT/HOLD] button. Self check Remote controller check Select "Check" from the Service menu, and press the [SELECT/HOLD] button. Service menu: MENU Cursor Select "Diagnosis" from the Check menu, and press the [SELECT/HOLD] button.
  • Page 49 13-7-2. PAR-SL101A-E 1. Press the button 1 to stop the air conditioner. is on), press the button 3 to disable it ( is off). 2. Press the button 2 for 5 seconds. 3. Press the button 5 to select the refrigerant address (M-NET address) B of the indoor 4.

  • Page 50: Remote Controller Check

    13-8. REMOTE CONTROLLER CHECK If operations cannot be completed with the remote controller, diagnose the remote controller with this function. 1. Select "Service" from the Main menu, and Diagnosis press the [SELECT/HOLD] button. Self check Remote controller check Select "Check" from the Service menu, and press the [SELECT/HOLD] button.
  • Page 51 13-9. SMOOTH MAINTENANCE Check menu 1. Select "Service" from the Main menu, and press the [SELECT/HOLD] button. Error history Diagnosis Smooth maintenance Request code Select "Check" with the F1 or F2 button, and press the [SELECT/HOLD] button. Service menu: MENU Cursor Select "Smooth maintenance"...

  • Page 52: Request Code

    ■ Refrigerant address Single refrigerant system Multi refrigerant system (group control) In the case of single refrigerant system, the refrigerant address Up to 16 refrigerant systems (16 outdoor units) can be con- is "00" and no operation is required. nected as a group by 1 remote controller. To check or set the Simultaneous twin, triple units belong to this category refrigerant addresses.
  • Page 54 MITSUBISHI ELECTRIC TRANE HVAC US LLC HEAD OFFICE: 1340 SATELLITE BOULEVARD, SUWANEE, GA 30024, USA MITSUBISHI ELECTRIC CONSUMER PRODUCTS (THAILAND) CO., LTD. 700/406 MOO 7, TAMBON DON HUA ROH, AMPHUR MUANG, CHONBURI 20000 THAILAND Published: Aug. 2023. No. TCHT013 Made in Thailand...
