User Manual
600 Ceramic Cooktop Touch
AUPL-CT62
IMPORTANT
Please ensure that you read through this manual prior to installation and use. This user
manual contains important information to ensure optimal performance and keep you safe.
Please retain your proof of purchase, as this will be needed in the event that you require a
warranty service. Remember to keep this user manual for future reference.
| platinumappliances.com.au
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Platinum 600 Ceramic Cooktop Touch
Summary of Contents for Platinum 600 Ceramic Cooktop Touch
- Page 1 User Manual 600 Ceramic Cooktop Touch AUPL-CT62 IMPORTANT Please ensure that you read through this manual prior to installation and use. This user manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be needed in the event that you require a warranty service.
-
Page 2: Table Of Contents
Contents Contents Warning & Safety Instructions Product Overview Electrical Connection Installation Operating Instructions Maintenance Your Cookware Product Specifications Contact Details Back Cover Page 2 600 Ceramic Hob Touch User Manual... -
Page 3: Warning & Safety Instructions
Warning & Safety Information CAUTION: Your safety is important to us. Please read this information before using your cooktop. INSTALLATION • This appliance is to be properly installed and earthed only by a suitably qualified ELECTRIC SHOCK HAZARD person. • Disconnect the appliance from the mains •... - Page 4 Warning & Safety Information HOT SURFACE HAZARD • After use, always turn off the cooking zones • Do not let your body, clothing or any item and the cooktop as described in this manual other than suitable cookware contact the (i.e.
-
Page 5: Product Overview
Product Overview 1100/2000W 1200W zone Flexi Zone Glass plate 1000/2200W 1200W zone Dual Zone Control Panel Heating zone Timer control ON/OFF control selection controls Timer regulating Heating zone Power slider Dual zone Keylock controls selection controls touch control control control 600 Ceramic Hob Touch User Manual Page 5... -
Page 6: Electrical Connection
Electrical Connection CONNECTING THE HOB TO THE MAINS POWER SUPPLY IMPORTANT: The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below: 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. -
Page 7: Installation
Installation For the purpose of installation and use, a minimum 5 mm space shall be preserved around the hole. Be sure the thickness of the table surface is at least 30mm. Ensure that the benchtop material is heat-resistant to avoid deformation caused by the heat radiation from the hotplate. As shown in Figure (1) Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. - Page 8 Installation NOTICE: Adjust the bracket positionto suit for different work surface’s thickness. CAUTION: • The ceramic cooker hob must be installed by qualified personnel or technicians. Please never conduct the operation by yourself. • The ceramic cooker hob shall not bemounted to cooling equipment, dishwashers and rotary dryers.
-
Page 9: Operating Instructions
Operating Instructions Timer Control The timer can be used as a minute reminder or as countdown timer to turn off a particular heating zone Minute timer NOTICE: The cooking zones will not turn off after elapsed time in this setting. To set a minute timer, touch the timer control. - Page 10 Operating Instructions Dual/Flexi Zone Control The front left (dual zone) and rear right (flexi zone) cooking zones have the ability to be used as a larger cooking surface. To activate: • Select the zone you would like to apply the larger cooking zone to and set it to your desiered heat setting.
-
Page 11: Maintenance
Maintenance 600 Ceramic Hob Touch User Manual Page 11... -
Page 12: Your Cookware
Your Cookware CHOOSING THE RIGHT COOKWARE Do not use cookware with jagged edges or a curved Always lift pans off the ceramic base. hob - do not slide, or they may scratch the glass. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. -
Page 13: Product Specifications
Product Specificatons Product Model AUPL-CT62 Cooking Zones 4 (1 dual, 1 flexi) Supply Voltage 220-240V Rated Frequency 50/60Hz Installed Electric Power 6000-7200W Product Size LxWxH (mm) 590x520x51 Built-in Dimensions LxW (mm) 560x490 600 Ceramic Hob Touch User Manual Page 13... -
Page 14: Contact Details
2153 1300 985 815 customercare@platinumappliances.com.au platinumappliances.com.au Platinum is committed to ongoing research and development. Every effort has been made to ensure all information in this user manual is correct at time of going to print. Dimensions should only be used as reference only and actual dimensions should be taken from the physical product only.
