User Manual
600 Induction Cooktop - Touch 4 Zone
AUPL-IT62B
IMPORTANT
Please ensure that you read through this manual prior to installation and use. This user
manual contains important information to ensure optimal performance and keep you safe.
Please retain your proof of purchase, as this will be needed in the event that you require a
warranty service. Remember to keep this user manual for future reference.
| platinumappliances.com.au
Advertisement
Related Manuals for Platinum AUPL-IT62B
Summary of Contents for Platinum AUPL-IT62B
- Page 1 User Manual 600 Induction Cooktop - Touch 4 Zone AUPL-IT62B IMPORTANT Please ensure that you read through this manual prior to installation and use. This user manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be needed in the event that you require a warranty service.
- Page 2 Contents Contents Warning & Safety Instructions Product Overview Electrical Connection Installation Operating Instructions Maintenance & Trouble Shooting Contact Details Page 2 600 Induction Hob Touch 4 Zone User Manual...
- Page 3 Warning & Safety Information IMPORTANT: To avoid the risk of accidents and damage to the appliance, please read these in- structions carefully before using it for the first time. They contain important notes on installation, safety, use and maintenance. INSTALLATION •...
- Page 4 Warning & Safety Information HOT SURFACE HAZARD detection feature to turn off the cooking ELECTRICAL SHOCK HAZARD zones when you remove the pans. • During use, accessible parts of this • Do not allow children to play with the appliance will become hot enough to appliance or sit, stand, or climb on it.
- Page 5 Product Overview 1. 160mm 1200/1500W zone 2. 210mm 2300/2600W zone 3. 160mm 1200/1500W zone 4. 210mm 2300/2600W zone 5. Control Panel 6. Glass Plate 1. Heating zone selectiion 2. Timer control 3. Slide touch control 4.Boost control 5. Child lock control 6.
- Page 6 Electrical Connection CONNECTING THE HOB TO THE MAINS POWER SUPPLY This hob must be connected to the mains power supply only by a suitably qualified person. Before connecting the hob to the mains power supply, check that: 1. The domestic wiring system is suitable for the power drawn by the hob. 2.
- Page 7 Installation SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant work surface material to avoid deformation caused by the heat radiation from the hotplate.
- Page 8 Installation BEFORE YOU INSTALL THE HOB, MAKE SURE THAT • The work surface is square and level, and no structural members interfere with space requirements • The work surface is made of a heat-resistant material • If the hob is installed above an oven, the oven has a built-in cooling fan •...
- Page 9 Operating Instructions A WORD ON INDUCTION COOKING Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. (suitable for induction cook top) BEFORE USING YOUR NEW INDUCTION HOB •...
- Page 10 Operating Instructions CHOOSING THE RIGHT COOKWARE • CAUTION // Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test.
- Page 11 Operating Instructions USING YOUR INDUCTION HOB 3. Touch the heating zone selection control, and an indicator next to the key will flash 4. Select a heat setting by touching the control. • If you don’t choose a heat setting within 1 minute, the Induction hob will automatically switch off.
- Page 12 Operating Instructions 4. Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. it can also be used as an energy saving func- tion if you want to heat further pans, use the hotplate that is still hot.
- Page 13 Operating Instructions USING THE TIMER You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. •...
- Page 14 Operating Instructions USING THE TIMER AS A COOKING ZONE COUNTDOWN TIMER Note: The selected cooking zone/s will turn off after elapsed time. Make sure the cooktop is turned on. Touch the heating zone selection control that you wish to set the timer for. Touch timer control, the time indicator show “10”...
- Page 15 Operating Instructions COOKING GUIDELINES Take care when frying as oil and fat heat up very quickly, particularly if you are using PowerBoost (on selected models. At extremely high temperatures oil and fat will ignite spontaneously and this presents a serious fire risk. COOKING TIPS •...
- Page 16 Maintenance & Troubleshooting CARE AND CLEANING The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the cooktop to find the settings that best suit you. 600 Induction Hob Touch 4 Zone User Manual Page 16...
- Page 17 Maintenance & Troubleshooting HINTS AND TIPS Unlock the controls. See ‘Operating Instructions’ section See ‘Maintenance & Troubleshooting’ section Page 17 600 Induction Hob Touch 4 Zone User Manual...
- Page 18 Maintenance & Troubleshooting FAILURE, DISPLAY AND INSPECTION If an abnormality comes up, the induction hob will enter the protective state automatically and display corresponding protective codes: CODE PROBLEM SOLUTION FAILURE Ceramic plate temperature sensor failure- Contact Customer Care -open circuit. Ceramic plate temperature sensor failure- -short circuit.
- Page 19 Page 19 600 Induction Hob Touch 4 Zone User Manual...
- Page 20 Norwest 2153 1300 985 815 customercare@platinumappliances.com.au platinumappliances.com.au Platinum is committed to ongoing research and development. Every effort has been made to ensure all information in this user manual is correct at time of going to print. Dimensions should only be used as reference only and actual dimensions should be taken from the physical product only.
