Before using this product, please read this guide carefully and keep it for
future reference. Parents and guardians should read this guide carefully to
ensure that children Observe safety precautions.
This product is designed with full attention to safety, but users still need
to abide by the basics in order to ensure safety, please abide by the
following rules:
*Only operate away from water and wet environments.
*Only 100-240V voltage can be connected, and it is imperative to ensure
that the power supply is well grounded.
*Please make sure that the base power switch is off, then plug the power
adapter into the base, and insert the three-pin 100-240V plug.
*When disassembling the base, steering wheel or other accessories,
please make sure that the device is powered off.
*When playing force feedback games, the recommended game time is 1
hour, with a 5-minute break every 20 minutes. Play time should not exceed
120 minutes.
**If the force feedback feels too difficult to control when playing the game,
please stop the game immediately and adjust it accordingly.
*It is not recommended to operate the device at high temperatures (≥
60°C), do not touch the surface of the case if it gets abnormally hot.
*Be sure to turn off the device when not in use.
*It is not advisable to knock, collide or disassemble the device without
authorization.
*The use of unofficial power adapters, antennas and other accessories is
prohibited.
*It is not recommended to and plug and unplug all the interfaces (power
supply, USB, antenna, etc.) on the base with the unit powered on.
Precautions before use
About safety

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT2 and is the answer not in the manual?

Questions and answers

Summary of Contents for CAMMUS GT2

  • Page 1 Precautions before use Before using this product, please read this guide carefully and keep it for future reference. Parents and guardians should read this guide carefully to ensure that children Observe safety precautions. About safety This product is designed with full attention to safety, but users still need to abide by the basics in order to ensure safety, please abide by the following rules: *Only operate away from water and wet environments.
  • Page 2 CAMMUS may formulate. *CAMMUS is not responsible for all losses caused by the user not using the product in accordance with this "User Guide", and the resulting equip- ment damage, CAMMUS has the right to refuse the warranty.
  • Page 3: Packing List

    This product is compatible with the CAMMUS DDWB 2021 base and LP8 base. This manual is applicable to the steering wheel developed and produced by CAMMUS. When playing force feedback games, the recommended game time is 60 minutes, with a 5-minute break every 20 minutes,and the playing time should not exceed 120 minutes.
  • Page 4: Outline Dimensions

    Outline Dimensions Basic data HUB length,width and height 269*171*94mm Steering wheel length, width and height 300*300*33mm Steering wheel spokes Aluminum alloy Steering wheel covering Leather Steering shaft Steel Carbon fiber Paddle shifter Supports PC mainstream racing games. Requirements (PC): Windows10, 50 MB free hard disk space, USB 2.0 port.
  • Page 5 Use the installation instructions Steering wheel Decorative circle Quick release module Installation steps: Align the four parts according to the order of the decorative plate,steering wheel, HUB, and quick-release modules, and then screw on the screws (M6*45mm). Steering wheel Wheelbase Install the steering wheel to the base: hold the quickrelease sleeveportion, put the sleeve into the wheelbase base shaft, release the sleeve, and the sleeve will fall automatically.
  • Page 6 To secure the steering wheel: Hold the front of the base and rotate the steering wheel until it clicks and locks.
  • Page 7 3-5 seconds. If successful,there will be two beeps. After that, you can use the CAMMUS APP to connect via bluetooth, enter the channel setting mode, and communicate with the installation base. Press and hold the rotating,knobs at the same,time for 3-5...
  • Page 8 Interface: 1 in total, see the figure below for details. USB Type-C interface USB Type-C interface:It can be connected to a computer directly to use with other bases,or connected to a computer to upgrade the firmware of the steering wheel through the CAMMUS app.
  • Page 9: Software Introduction

    Software Introduction Homepage: You can check the connection status of each device, quickly start the game, and upload personal practice results data at the same time. Parameters: Base setting interface, including basic settings of the base and game effect settings. Beginner players can quickly match the appropriate feel to play the game by adjusting the basic settings.
  • Page 10 Equipment:Check the status of all CAMMUS equipment, including the settings of the handbrake, steering wheel, pedals, motionrig, etc. Set the maximum/minimum value of the pedal: Enter the pedal setting interface, click the minimum value of the accelerator, and wait for the prompt to set the function. At this time, step on the accelerator fully, hold it and click the maximum value until the prompt setting is successful;...
  • Page 11 Firmware upgrade: You can view the firmware version of the existing device. Open the firmware update assistant to quickly update to the latest firmware of the device with one click.
  • Page 12 APP acquisition and usage tutorial Users can obtain the control software [CAMMUS] in the following ways. Users can enter the corresponding support page to download according to the guidelines (cammusracing.com). Contact customer service at the designated sales outlets and channels of CAMMUS to obtain the download file.
  • Page 13: Warranty

    With the product warranty card, valid invoice or/and other valid certificates for purchasing the product, users can enjoy the product within the valid period. In order for you to enjoy the warranty support of CAMMUS, please do not artificially damage the machine, and do not operate the machine or system abnormally under the guidance of the official or official authorized...
  • Page 14: Supplementary Note

    Damaged due to user behavior (self-refitting, repairing, or dismantling, refitting, repairing, etc. by a third party not authorized by CAMMUS). Software failure of peripherals or accessories that are not configured by the product itself and cause product failure. The use of third-party software that is not pre-installed on the product fails and causes product failure.
  • Page 15 合格证 CERT I FI CAT E 产品型号: Pro du c t nu m be r 检 验 员: In spe c t or: 生产日期: Pro du c tio n D a te:...
  • Page 16 保 修 卡 Warranty card 为了您的保修权益, 请务必如实填写以下信息 For the sake of your warranty rights, please be sure to fill out the information truthfully 联 系 方 式 购买日期 顾客姓名 contact Date of purchase Customer name information 产品型号 Product number 地 址...
