Superfront BRUTA BASE Mounting Instructions

Content
3M wet wipe
3M
VHB™
Surface Cleaner Sachet
GB
For use with 3M™ VHB™ Tapes
Poche e de Ne oyage
FR
A utiliser avec les rubans 3M™ VHB™
Reinigungstuch
DE
Für den Einsatz mit 3M™ VHB™
Mounting sides
1.
Mount the frames, legs and plinth.
Mount your Ikea frames on the wall with the Ikea
suspension rail. A ach the Metod legs from Ikea
and then add the plinth from Superfront.
See separate mounting instructions.
NOTE! With the doors installed, the Bruta kitchen will
be deeper than standard. This means that the worktop
must be at least 65 cm deep + your desired overhang.
2.
Cut the sides to the correct height.
Measure from the floor to the top of the mounted
frames – both at the back and front. Then cut the
sides according to the measurements.
3.
Clean the surfaces.
Use the a ached 3M wet wipe to clean the surfaces
of the cabinet and the Superfront sides.
4.
A ach the MountPads to the frames.
Place the MountPads on the sides of the frames
as shown.
NOTE! Do not remove the cover paper from the
MountPads yet!
Note!
Avoid having open sawed ends near wet areas. A lacquered surface is best but if that is not possible be sure to seal the sawn part using paint or silicone.
MountPads 40x25mm
(9 per side)
Superfront /+46 8 68 44 18 14 / info@superfront.com / www.superfront.com
Mounting instructions BRUTA BASE 1/2
Screws
(the number varies)
A
5.
Mount the sides in place.
Do this step first without removing the cover paper
on the MountPads so that you get the hang of it before
you do it for real.
Place the side as shown below. NOTE! Make sure that
the back of the side is flush with the wall and in line
with the top edge of the frame.
Slowly tilt the side inwards until it touches the Mount-
Pads. Make sure that it ends up in the right position.
PRESS HARD OVER EACH MOUNTPAD FOR AT LEAST
30 SECONDS. This is important because the adhesive
in our MountPads cure under pressure.
6.
Drive the screws (A).
Press on the outside of the side at the point where
you drive the screw. Spread the screws as evenly as
possible without them being in the way of the hinges,
drawers or shelf supports.
PRESS HERE
PRESS HERE
B
A
