EW6T634W
EN
Washing Machine
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the EW6T634W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux EW6T634W

Summary of Contents for Electrolux EW6T634W

  • Page 1 EW6T634W Washing Machine User Manual...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS..............35 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: General Safety

    1.2 General Safety This appliance is for washing domestic-type, machine- • washable laundry only. This appliance is designed for single household • domestic use in an indoor environment. This appliance may be used in, offices, hotel guest • rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels.

  • Page 5: Safety Instructions

    ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected The installation must comply to a grounding connection in the with relevant national building. regulations. • Always use a correctly installed shockproof socket. •...

  • Page 6: Product Description

    Authorised Service Centre for the related equipment including hoses, other drain hose and the extension. valves, filters and aquastops, printed • Make sure that there is access to the circuit boards, electronic displays, tap after the installation. pressure switches, thermostats and sensors, software and firmware 2.4 Use...

  • Page 7: Appliance Overview

    ENGLISH washing results in the minimum "The SensiCare System load possible time. Read the paragraph detection " for more details. 3.2 Appliance overview 9 10 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Feet for levelling the appliance Rating plate Inlet hose...

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,8 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except...

  • Page 9: The Inlet Hose

    ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.

  • Page 10: Water Drainage

    5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description Programme dial Centrifuga reduction options touch button Display • No Spin option Partenza Ritardata touch button • Rinse Hold option Time Manager touch button • Notturna option Avvio/Pausa touch button On/Off push button Più...

  • Page 12: Dial And Buttons

    Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g. Time Manager bars level indicator. Drum clean indicator. Child safety lock indicator. Add garments indicator. Illuminates at the beginning of the Wash phase, while the user can still pause the appli‐...

  • Page 13: Partenza Ritardata

    ENGLISH creasing. The washing programme Use this option for people with allergies ends with water in the drum. to detergent residues and with sensitive The lid stays locked and the drum skin. turns regularly to reduce creasing. This option increases the You must drain the water to unlock programme duration.

  • Page 14: Programmes

    (max. half load ■ ■ ■ recommended). ■ ■...
  • Page 15 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Rapido 14' 800 rpm 1,5 kg Synthetic and mixed fabric items. Lightly 30 °C (800 - 800) soiled items and items to freshen up.
  • Page 16 Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] 1000 rpm Outdoor 2 kg Do not use fabric softener and (1000 - 30 °C make sure that there is no soften‐...
  • Page 17 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range [rpm ] Denim 800 rpm 2 kg Special programme for Denim clothing 30 °C (1000 - with delicate washing phase to minimize 40 °C - Cold 800)
  • Page 18 Programme ■ ■ ■ ■ Lana Sport ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Outdoor Denim ■ ■ ■ ■ ■ ■ ■ Suitable detergents for washing programmes Universal Liquid Liquid for Delicates Programme Special...

  • Page 19: Settings

    ENGLISH 8.2 Woolmark Wool Care - Blue The wool wash cycle of this machine has been approved by The Woolmark Compa‐ ny for the washing of wool garments label‐ led as «hand wash» provided that the products are washed according to the in‐ structions on the garment label and those issued by the manufacturer of this washing machine.

  • Page 20: Daily Use

    11. DAILY USE 11.3 Detergent compartments. WARNING! Using detergent and additives Refer to Safety chapters. 1. Measure out specified detergents and 11.1 Activating the appliance the fabric conditioner. 2. Put the detergent and the fabric 1. Connect the mains plug to the mains socket.

  • Page 21: Liquid Or Powder Detergent

    ENGLISH Detergent compartment for washing phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid). Compartment for liquid additives (fabric conditioner, starch). The mark is the maximum level for the quantity liquid additives. Flap for powder or liquid detergent. 11.4 Liquid or powder detergent CLICK CLICK...

  • Page 22: The Sensicare System Load Detection

    1. The SensiCare System starts The drain pump can operate estimating the weight of the load to shortly before the appliance calculate the real programme fills water. duration. During this phase the Time Manager bars placed below the 11.7 Starting a programme with time digits play a simple animation.

  • Page 23: End Of The Programme

    ENGLISH There is also an alternative way of When you activate the cancelling: appliance again, the display 1. Rotate the selector knob to the "Reset" shows the end of the previous programme. Turn position the programme dial to set a 2.

  • Page 24: Hints And Tips

    • You do not use the appliance for 5 If the dial is rotated to the "Reset" minutes when no programme is position , the appliance automatically running. turns off in 30 seconds. Press the button On/Off to activate the appliance again.

  • Page 25: Care And Cleaning

    ENGLISH 12.3 Detergent type and • sudsing, • reduced washing effect, quantity. • inadequate rinsing, • a greater impact for the environment. The choice of detergent and use of correct quantities not only affects your 12.4 Ecological hints wash performance, but also helps to avoid waste and protect the environment: To save water, energy and to help •...

  • Page 26: Removing Foreign Objects

    After each cycle, keep the lid and the CAUTION! drum door ajar to get air circulation and Do not clean the metal dry the humidity inside the appliance: this surfaces with chlorine-based will prevent mildew and odours. detergent. If the appliance is not used for a long time: close the water tap and unplug the 13.4 Descaling...

  • Page 27: Cleaning The Detergent Dispenser

    ENGLISH 13.7 Lid seal Always follow the instructions that you find on Regularly examine the seal and remove the packaging of the all objects from the inner part. Clean it product. when needed, using ammonia cream Do not clean the drum with cleanser agent without scratching the acidic descaling products, seal surface.

  • Page 28: Cleaning The Inlet Hose And The Valve Filter

    13.9 Cleaning the inlet hose and the valve filter 13.10 Cleaning the drain filter WARNING! • Disconnect the mains Regularly check the drain pump filter and plug from the mains make sure that it is clean. socket. Clean the drain pump if: •...

  • Page 29: Emergency Drain

    ENGLISH 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
  • Page 30 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the fil‐ not drain the water.
  • Page 31 ENGLISH Problem Possible solution • Set the spin programme. The spin phase does • Make sure that the drain filter is not clogged. Clean the fil‐ not operate or the ter, if necessary. Refer to "Care and cleaning". washing cycle lasts •...

  • Page 32: Consumption Values

    15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
  • Page 33 ENGLISH Eco 40-60 pro‐ Litres hh:mm °C gramme Quarter load 0.200 29.0 2:35 55.00 1251 1) Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.50 0.50 4.00 Time to Off/Standby mode is 15 minutes maximum. 15.4 Common programmes These values are indicative only.

  • Page 34: Quick Guide

    16. QUICK GUIDE 16.1 Daily use Connect the mains plug to the mains 2. Set the desired options (1) by means socket. of the corresponding touch buttons. To start the programme, touch the Open the water tap. Avvio/Pausa (2) button.

  • Page 35: Environmental Concerns

    ENGLISH Programmes Load Product description Delicate fabrics such as acrylics, viscose, Delicati 2 kg polyester items. Cotton and synthetic lightly soiled items or Rapido 14' 1,5 kg once worn items. All fabrics, except woollens and very deli‐ Risciacquo 6 kg cate fabrics.
  • Page 36 www.electrolux.com/shop...
