Sharp LC-60UE30U Service Manual

Sharp LC-60UE30U Service Manual

Lcd color television
Hide thumbs Also See for LC-60UE30U:

Advertisement

Quick Links

Download this manual
SAFETY PRECAUTION
CAUTION ............................................... . ............i
MAJOR SERVICE PARTS ..................... . ..........iv
[1]
SPECIFICATIONS ................................. . ....... 1-1
[1]
OPERATION MANUAL .......................... . ....... 2-1
[1]
DIMENSIONS ........................................ . ....... 3-1
[1]
(LC-60UE30U) ....................................... . ....... 4-1
[2]
(LC-70UE/UC/UH30U) .......................... . ....... 4-8
[3]
REMOVING OF MAJOR PARTS
(LC-80UE/UH30U) ................................ . ..... 4-15
[4]
THE LOCATION PUTTING ON THE HEAT
MEASURE SHEET ................................ . ..... 4-22
Parts marked with "
parts with specified ones for maintaining the safety and performance of the set.
LC-60UE30U/70UE30U/70UC30U/70UH30U/80UE30U/80UH30U
SERVICE MANUAL
MODELS
CONTENTS
" are important for maintaining the safety of the set. Be sure to replace these
No. S45A4LC70UE30
LCD COLOR TELEVISION
LC-60UE30U
LC-70UE30U
LC-70UC30U
LC-70UH30U
LC-80UE30U
LC-80UH30U
[5]
PRECAUTIONS FOR ASSEMBLY ..............4-24
CHAPTER 5. ADJUSTMENT
[1]
ADJUSTMENT PROCEDURE ......................5-1
[1]
cabinet ...........................................................6-1
[2]
error (POWER LED used) .............................6-1
[3]
TROUBLESHOOTING TABLE ......................6-3
[1]
MAJOR IC INFORMATIONS .........................7-1
[1]
70UH30U)......................................................8-1
[2]
(LC-80UE/UH30U).........................................8-2
[3]
SYSTEM BLOCK DIAGRAM .........................8-3
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
