Instructions for use
Refrigerator freezer
RFN2386SL
RFN2386SR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFN2386SL and is the answer not in the manual?

Questions and answers

Related Manuals for Asko RFN2386SL

Summary of Contents for Asko RFN2386SL

  • Page 1 Instructions for use Refrigerator freezer RFN2386SL RFN2386SR...
  • Page 2 We thank you for the confidence you have shown by purchasing our appliance. We wish you find a lot of pleasure in its use. The appliance is intended solely for household use. Refrigerator freezer (hereinafter: the appliance) consists of two parts: the upper part is the refrigerator and the lower part is the freezer.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND WARNINGS ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE APPLIANCE DESCRIPTION DESCRIPTION 10 INSTALLATION AND CONNECTION 12 CHANGING THE DIRECTION OF DOOR OPENING 13 OPERATING THE APPLIANCE 18 APPLIANCE INTERIOR EQUIPMENT 21 RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE STORING AND 22 STORING FOOD IN THE REFRIGERATOR FREEZING FOOD...

  • Page 4: Important Notes And Warnings

    IMPORTANT NOTES AND WARNINGS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 5 Before connecting the appliance to the power mains, let the appliance rest in a vertical position for approximately 2 hours. This will reduce the possibility of operation faults due to the effect of transport on the cooling system. The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations.
  • Page 6 To protect the environment, take the obsolete appliance to an authorized home appliance collection center. Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Rating plate can be found in the appliance interior. If the language on the rating plate is not the language of your choice or the language of your country, replace it with the one supplied.
  • Page 7 The symbol on the product or its packaging indicates that the product should not be treated as normal household waste. The product should be taken to an authorized collection center for waste electric and electronic equipment processing. Correct disposal of the product will help prevent any negative effects on the environment and health of people which could occur in case of incorrect product removal.

  • Page 8: Advice For Saving Power With Refrigeration Appliances

    ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance).

  • Page 9: Appliance Description

    APPLIANCE DESCRIPTION A Refrigerator Control unit 2 LED lighting of refrigerator interior 3 Pull-out glass shelf (height- adjustable) 4 Crisper (fruit and vegetables drawer) 5 Height-adjustable door bin 6 Bottle shelf B Freezer 7 Freezer drawers 8 Glass shelves • The drawers are protected against pulling out. To remove a drawer from the appliance, pull it out as far as it will go, then lift at the front and pull out completely.

  • Page 10: Installation And Connection

    INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Class Temperature from +10°C to +32°C...
  • Page 11 • Do not expose the appliance to direct sunlight and do not place it near any source of heat. If this cannot be avoided, install an insulation panel. • The appliance may stand alone or it may be placed ext to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram).

  • Page 12: Changing The Direction Of Door Opening

    CHANGING THE DIRECTION OF DOOR OPENING Door opening direction cannot be changed for this appliance.

  • Page 13: Operating The Appliance

    OPERATING THE APPLIANCE A Appliance on key and refrigerator compartment off key B Acoustic alarm off key C Super cool on/off key D Refrigerator compartment temperature keys E Refrigerator temperature display F Freezer compartment on key and appliance off key G ECO function on/off key H Super freeze on/off key Freezer compartment temperature keys...

  • Page 14: Switching The Appliance On/Off

    SWITCHING THE APPLIANCE ON/OFF Switching the appliance on: Switch on the appliance by briefly pressing the key A. With this model, it is possible to only switch on the freezer compartment while the refrigerator compartment is switched off. This setting can be made in two ways: - briefly press the F key to switch on the freezer compartment only;...
  • Page 15 • To set the temperature in the freezer compartment use the keys I: lower temperature ; higher temperature. • Temperature in the freezer compartment can be set from -24°C to -16°C. • After one of the I keys is pressed, the most recent temperature setting will fl...

  • Page 16: High Temperature Alarm

    • With this setting, the compressor will operate continuously and the temperature in the freezer compartment will drop considerably. • If the setting is not deactivated manually (by pressing the »H« key), it will be deactivated automatically after approximately one day. Freezer compartment temperature will return to the most recent setting.
  • Page 17 ECO FUNCTION To activate the Eco function, press the G key. With this function activated, appliance will operate with optimum settings. SAFETY BLOCK (CHILD SAFETY LOCK) Use this function if you do not wish to manually adjust the appliance settings. To activate, press and hold the B key (for three seconds);...

  • Page 18: Appliance Interior Equipment

    APPLIANCE INTERIOR EQUIPMENT (* Equipment depends on the model) SHELF • For easier access to food and clarity, the shelves can be partly pulled out. • The shelves may be adjusted tu suit your preferences using the guides in the refrigerator interior.
  • Page 19 INTERIOR SIDE OF THE REFRIGERATOR DOOR Mounted on the refrigerator door are compartments (shelves or bins) intended fro storing cheese, butter, eggs, yoghurt and other smaller packages, tubes, cans, etc. There is a bottle shelf at the lower end of the door. ADJUSTABLE DOOR BINS The height of door bins/shelves can be adjusted to your preferences without...
  • Page 20 IONIZER (IONAIR)* • Air ionizer installed in the refrigerator compartment keeps the air permanently fresh. As a result, the food remains fresh and tasty longer. • Air ionizer can be switched on and off using the switch located on the fan housing or on the side of the cooling tower (depending on the model).

  • Page 21: Recommended Distribution Of Food In The Appliance

    RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE Sections of the refrigerator: - upper part: canned food, bread, wine, pastry etc. - middle part: dairy products, ready-made meals, desserts, soft drinks, beer, cooked food, etc. - ZeroZone bin: - meat, meat produce, delicatessen; - Fruit and vegetable bin: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips etc.

  • Page 22: Storing Food In The Refrigerator

    STORING FOOD IN THE REFRIGERATOR IMPORTANT WARNINGS REGARDING FOOD STORAGE Correct use of the appliance, appropriate packaging, maintaining the right temperature, and observing the food hygiene standards has a decisive impact on the quality of food storage. Observe the expiry dates for the food, specified on the packaging.

  • Page 23: Freezing And Storing Frozen Food

    FREEZING AND STORING FROZEN FOOD FREEZING PROCESS Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;...

  • Page 24: Important Warnings On Freezing Fresh Food

    IMPORTANT WARNINGS ON FREEZING FRESH FOOD Only freeze the food that is suitable for freezing in the freezer. Make sure the food you freeze is of high quality and fresh. Choose appropriate packaging and use the packaging correctly. Packaging should not be permeable to humidity; it should be airtight to prevent the food from drying out and loss of vitamins.

  • Page 25: Frozen Food Storage Time

    FROZEN FOOD STORAGE TIME Recommended storage time in the freezer Type of food Time fruit, beef from 10 to 12 months vegetables, veal, poultry from 8 to 10 months Venison from 6 to 8 months Pork from 4 to 6 months minced meat 4 months bread, pastry, ready-to-eat meals, lean...

  • Page 26: Defrosting The Appliance

    DEFROSTING THE APPLIANCE AUTOMATIC REFRIGERATOR DEFROSTING Refrigerator does not need defrosting because the ice on the back interior wall is thawed automatically. Any accumulated ice will melt when the compressor unit is inactive. Drops will flow through an opening in the refrigerator rear wall into a tray fitted above the compressor, from where they will evaporate.

  • Page 27: Cleaning The Appliance

    CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface.

  • Page 28: Troubleshooting

    TROUBLESHOOTING Problem: Cause or remedy: Appliance is connected • Make sure there is voltage in the power outlet and that to the power mains but it the appliance is switched on. does not work. • Too high environment temperature. Cooling system operates •...
  • Page 29 Problem: Cause or remedy: Door is difficult to open: • If you are trying to open the freezer door after just having closed it, this could be difficult to do. As you open the door, some cool air escapes from the appliance and it is replaced by warm air from the environment.

  • Page 30: Information About Appliance Noise

    WE RESERVE THE RIGHT TO MAKE CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.asko.com...
  • Page 31 設備名稱：　電冰箱 ，型號（型式）： Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 鉛Lead 汞Mercury 鎘 六價鉻 多溴聯苯 多溴二苯醚 Ｕnit (Pb) (Hg) Cadmium Hexavalent Polybrominated Polybrominated (Cd) chromium biphenyls diphenyl ethers (PBB) (PBDE) 電路板Control unit ○ ○ ○ ○...
  • Page 32 en (06-18)

This manual is also suitable for:

Rfn2386sr
