- Page 1 USER MANUAL Sol-H450H / Sol-H500H H2H Version Ver:1.1,2022-11...
- Page 2 About the Manual This manual contains important instructions for the Sol-H450H/Sol-H500H Microinverter and must be read in its entirety before installing or commissioning the equipment. For safety, only qualified technician, who has received training or has demonstrated skills can install and maintain this Microinverter under the guide of this document.
- Page 3 Table of Contents 1 Important Safety Instructions ....................3 1.1 Safety Instructions ....................... 3 1.2 Radio Interference Statement ..................... 4 1.3 The Meaning of Symbols ..................... 5 2 Microinverter System Introduction .................... 6 2.1 About 1 in 1 Unit ......................... 6 2.2 Microinverter Highlights......................
- Page 4 1 Important Safety Instructions This manual contains important instructions to follow during installation and of the Photovoltaic Grid-connected Inverter (Microinverter). To reduce the risk of electrical shock and ensure the safe installation and operation of the Microinverter, the following symbols appear throughout this document to indicate dangerous conditions and important safety instructions.
- Page 5 In any circumstance, do not connect DC input when AC connector is unplugged. Please install isolation switching devices on the AC side of the inverter. 1.2 Radio Interference Statement CE EMC Compliance：The equipment can comply with CE EMC, which are designed to protect against harmful interference in a residential installation.
- Page 6 1.3 The Meaning of Symbols Symbol Usage Treatment To comply with European Directive 2002/96/EC on waste Electrical and Electronic Equipment and its implementation as national law, electrical equipment that has reached the end of its life must be collected separately and returned to an approved recycling facility.
- Page 7 2 Microinverter System Introduction 2.1 About 1 in 1 Unit “1-in-1 Unit Microinverter” with ultra-wide DC input operating voltage range (16 V–60 V) and low start-up voltage (22 V only). 2.2 Microinverter Highlights Maximum output power up to 500W; Adapted to 60 & 72 cells PV panels. ...
- Page 8 2.3 Terminals Introduction Object Description AC Connector (Male) DC Connectors AC Connector (Female) 202207V1.1...
- Page 9 2.4 Operation Mode Normal: Under this mode, Microinverter is operating normally and convert DC power into AC power to support the house loads and feed in to Public Grid. Zero Export Control: Under this mode Microinverter’s generation is limit base on the current house loads, there will be no extra power feed in to the Public Grid.
- Page 10 3 About Installation 3.1 Accessories Object Description AC End Cable (Male) DC Extension Cable M8*25 screws AC Female End Cap, IP68 *Note: 1.All accessories above are not included in the package, and need to be purchased separately. Please contact our sales representative for the price. 2.M8 screws need to be prepared by installer.
- Page 11 not expose it to direct sunlight. To avoid overheating, always make sure the air flow around the inverter is not blocked. Do not install in places where gasses or flammable substances may be present. Avoid electromagnetic interference that can compromise the correct operation of electronic ...
- Page 12 Step 3. Connect AC End Cable A) Installation of cable end connector. Solid wrench No.30 or monkey wrench wide than 3cm、 Cross screwdriver No.1、Wire striper. a). Disassemble the connector and thread the cable through the waterproof cap and connector housing b).Connect the cable to the terminal, and the screw torque is 0.8 + / - 0.1N ·...
- Page 13 Step 7. Set Up the Monitoring System Refer to the SLT User Manual or SLT Quick Installation Guide, and Quick Installation Guide for Solenso Monitoring Platform Online Registration to install the SLT and set up your monitoring system. 202207V1.1...
- Page 14 Flashing Red and Green alternately: Firmware is corrupted. *Note: All the faults are reported to the SLT, refer to the local APP of the SLT or Solenso Monitoring Platform for more information. 4.2 On-site Inspection (For qualified installer only) To troubleshoot an inoperable microinverter, follow the steps in the order shown.
- Page 15 5kg weight and can be fully closed if the original packaging is no longer available. 5.2 Storage and Transportation Solenso packages and protects individual components using suitable means to make the transport and subsequent handling easier. Transportation of the equipment, especially by road, must be carried out by suitable ways for protecting the components (in particular, the electronic components) from violent, shocks, humidity, vibration, etc.
- Page 16 5.3 Disposal If the equipment is not used immediately or is stored for long periods, check that it is correctly packed. The equipment must be stored in well-ventilated indoor areas that do not have characteristics that might damage the components of the equipment. Take a complete inspection when restarting after a long time or prolonged stop.
- Page 17 -40 ~ +65 Dimensions(W×H×D mm) 193×165×32 Weight (kg) Enclosure rating IP67 Cooling Natural convection Features Communication Wireless_2.4G High Frequency Transformers Isolation Type (Galvanically Isolated) Solenso Monitoring System Monitoring (Solenso DTU is required) EN 50549-1: 2019, VDE-R-N 4105: Compliance 2018 202207V1.1...
- Page 18 Appendix 1: Installation Map 202207V1.1...
- Page 19 Appendix 2: WIRING DIAGRAM – 230VAC SINGLE PHASE: 202207V1.1...
- Page 20 WIRING DIAGRAM – 230VAC / 400VAC THREE PHASE: 202207V1.1...
