Optional connector kit
MODEL: TCB-KBOS4E
Thank you for purchasing the "Optional connector kit" of TOSHIBA Air Conditioner. Before starting the installation work,
please read this manual carefully and install the product properly. Ask the customer to keep this Installation Manual.
PRECAUTIONS FOR SAFETY
• Before installing the product, please read the "PRECAUTIONS FOR SAFETY" carefully to perform the proper installation.
• Be sure to keep the instructions described in the precautions for safety, since the descriptions include the important
information for safety.
• Ask the dealer from whom the product was purchased or qualified installation professional to install the product.
Improper installation by unqualified persons may result in electric shock or fire.
• Perform installation work properly according to the Installation Manual.
Improper installation may result in electric shock or fire.
• Ask an authorized dealer or qualified installation professional to reinstall the product.
Improper installation may result in electric shock or fire.
• Perform electrical work in accordance with applicable standards and this Installation Manual, and use an exclusive
circuit. Use a voltage that meets the rated voltage of the product.
Improper electrical work or insufficient capacity in power circuit may result in electric shock or fire.
• Use appropriate cables with adequate current capacity for wiring.
Use of inappropriate cables may result in a short circuit, overheating, or fire.
• Perform wiring securely using specified cables, and take measures to prevent cable tension from being applied to
connecting points.
Improper wiring may result in disconnection, overheating, or fire.
• Prevent excessive force from being applied to the P.C. board.
Excessive force may damage the P.C. board or disconnect its printed wiring, which may result in overheating or fire.
• After the installation work is completed, perform a test run according to the installation manual of the outdoor unit to
confirm that no abnormality is found.
Air Conditioner
INSTALLATION MANUAL
WARNING
CAUTION
1
Advertisement
Related Manuals for Toshiba TCB-KBOS4E
Summary of Contents for Toshiba TCB-KBOS4E
- Page 1 Optional connector kit MODEL: TCB-KBOS4E Thank you for purchasing the “Optional connector kit” of TOSHIBA Air Conditioner. Before starting the installation work, please read this manual carefully and install the product properly. Ask the customer to keep this Installation Manual.
- Page 2 1. Components Q’ty Single-phase Three-phase RAV -SP80✽AT-✽ RAV -SM224✽AT8/7-✽ -SP110✽AT-✽ -SM280✽AT8/7-✽ -SP140✽AT-✽ RAV -SP110✽AT8/7-✽ Component Remarks -SP140✽AT8/7-✽ -SP160✽AT8/7-✽ RAV -GM224✽AT8✽-✽ -GM280✽AT8✽-✽ RAV -GP110✽AT8✽-✽ -GP140✽AT8✽-✽ -GP160✽AT8✽-✽ Cable for peak-cut control or night operation (5-core cable of 300 mm in length with yellow connector) Use these Cable for peak-cut control or night operation cables as...
-
Page 3: Connecting The Cables
2. Connecting the Cables <Three-phase power supply models system diagram> (RAV-SM2244AT8/7-✽, SM2804AT8/7-✽, SP110✽AT8/7-✽, -SP140✽AT8/7-✽, -SP160✽AT8/7-✽) (RAV-GP110✽AT8✽-✽, -GP140✽AT8✽-✽, -GP160✽AT8✽-✽) *Pass the “5-core cable of 500 mm” twice through the “clamp filter (Procured locally) (ZCAT2032-0920)” Timer or switch (commercially available) Orange CN610 Peak-cut Yellow (Yellow) - Page 4 <Single-phase power supply models system diagram> (RAV-SP110✽AT-✽, SP140✽AT-✽) *Pass the "5-core cable of 300 mm” through the “clamp filter (Procured locally) (ZCAT2032-0920)” Timer or switch (commercially available) White Black Night operation CN610 Yellow (Yellow) Operation stop Orange Peak-cut Outdoor unit cycle control P.C.
- Page 5 <Single-phase power supply models system diagram> (RAV-SP80✽AT-✽) *Pass the “5-core cable of 300 mm” twice through the “clamp filter (Procured locally) (ZCAT2032-0920)” Timer or switch (commercially available) White Black Night operation CN610 Yellow (Yellow) Operation stop Orange Peak-cut Outdoor unit cycle control P.C.
- Page 6 MEMO ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 7 MEMO ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 8 EE99754201-1...
