Dell PowerEdge C6100 Hardware Owner's Manual page 73

3 Remove the expansion card. See "Removing the Expansion Card" on
page 69.
4 Remove the two screws securing the expansion-card connector to the
expansion-card bracket. See Figure 3-12.
5 Pull the expansion-card connector away from the expansion-card bracket.
See Figure 3-12.
Figure 3-12. Removing and Installing the Expansion-Card Connector
1 screw (2)
3 expansion-card bracket
3 2
2 expansion-card connector
Installing System Components
1
73
