Dell PowerEdge C6100 Hardware Owner's Manual page 17

Item Indicator, Button,
or Connector
9 Video connector
10 Power-on indicator/
power button (system
board 1)
Figure 1-9. Enumeration—Four System Boards
Figure 1-10. Enumeration—Three System Boards
Icon Description
Connects a VGA display to the system.
The power-on indicator lights
when the system power is on.
The power button controls the
DC power supply output to the system.
NOTE:
the video monitor can take from several
seconds to over 2 minutes to display an
image, depending on the amount of
memory installed in the system.
NOTE:
systems, turning off the system using the
power button causes the system to
perform a graceful shutdown before
power to the system is turned off.
NOTE:
press and hold the power button for
five seconds.
3
4
4
When powering on the system,
On ACPI-compliant operating
To force an ungraceful shutdown,
1
2
1
2
About Your System
17
