Power Distribution Board Connectors

Figure 5-13. Power Distribution Board Connectors
1 backplane power connector
3 main power connector for system
boards 3 and 4
5 system fan board power connector

Jumper Settings

CAUTION:
Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
1
6
2
5
2 system fan board connector
4 main power connector for system
boards 1 and 2
6 bridge card connector
Jumpers and Connectors
3
4
