1 system fan board connector
3 SATA2 hard drive connectors 1 to 6
for system board 4 (from right to left)
5 backplane jumper
7 SATA2 hard drive connectors 1 to 6
for system board 1 (from right to left)
9 CPLD JTAG connector 1
11 SGPIO connector B for
system board 2
13 SATA2 hard drive connectors 1 to 6
for system board 3 (from right to left)
15 CPLD JTAG connector 2
17 SGPIO connector B for
system board 4
Figure 5-6. Back View of the Backplane—Type 2
1 2
5
1 power supply connector 2
3 HDD connector number 0-Port 1
5 power supply connector 1
2 backplane power connector for power
supply 1
4 SATA2 hard drive connectors 1 to 6 for
system board 2 (from right to left)
6 SGPIO connector A for system board 1
8 SGPIO connector B for system board 1
10 SGPIO connector A for system board 2
12 SGPIO connector A for system board 3
14 SGPIO connector B for system board 3
16 SGPIO connector A for system board 4
18 backplane power connector for
power supply 2
4
2 HDD connector number 23-Port 24
4 PCIEx8 connector
Jumpers and Connectors
3
