- Page 1 Air conditioner User manual AC***DN1DCG, AC***DN4DCG • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Operation Features Operating temperature and humidity Cleaning and Maintenance Cleaning and Maintaining Cleaning the indoor unit exterior • Cleaning the outdoor unit heat exchanger Cleaning the air filter Resetting the filter-cleaning reminder Periodic maintenance Troubleshooting 2 English... -
Page 3: Safety Information
Safety Information California Proposition 65 Warning (US) WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to operate the extensive features and functions of your new appliance safely and efficiently. Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. - Page 4 Safety Information Follow directions. Do NOT attempt. Make sure the machine is grounded to prevent electric shock. Cut off the power supply. Do NOT disassemble. Symbol Meaning Flammable gas Flammable materials Refrigerant Refrigerant safety group Safety Group Read operating manual Refer to operating manual Read service manual 4 English...
-
Page 5: For Installation
FOR INSTALLATION WARNING Use the power line with the power specifications of the product or higher and use the power line for this appliance only. In addition, do not use an extension line. • Extending the power line may result in electric shock or fire. •... - Page 6 Safety Information This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line. • Failure to do so may result in electric shock, fire, an explosion, or other problems with the product. CAUTION Install your appliance on a level and hard floor that can support its weight.
- Page 7 Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 8 Safety Information To reinstall the air conditioner, please contact your nearest service center. • Failing to do so may result in problems with the product, water leakage, electric shock, or fire. • A delivery service for the product is not provided. If you reinstall the product in another location, additional construction expenses and an installation fee will be charged.
- Page 9 • Since this may be dangerous due to a lack of oxygen, open a window at least once an hour. Do not use means to accelerate the defrost operation or to clean, other than those recommended by Samsung. Do not pierce or burn. Be aware that refrigerants may not contain an odor.
- Page 10 Safety Information CAUTION Do not place objects or devices under the indoor unit. • Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year. •...
- Page 11 Do not spray volatile material such as insecticide onto the surface of the appliance. • As well as being harmful to humans, it may also result in electric shock, fire or problems with the product. Do not drink the water from the air conditioner. •...
-
Page 12: For Cleaning
Safety Information FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. • This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut off the power supply and wait until the fan stops. -
Page 13: At A Glance
Indoor Unit Overview The indoor unit and its display may look slightly different from the illustration shown below, depending on the model and the panel type. 1-way Cassette 01 Display Indication Function Operation indicator • Heating and cooling model: Operation(Blue) / Defrost(Yellow) •... - Page 14 Indoor Unit Overview 4-way Cassette 01 Display Indication Function On/Off operation indicator Removing frost indicator Timer indicator Filter cleaning indicator 02 Air flow blade/Air outlet (inside) / Remote control sensor WindFree panel (You can use the WindFree Cooling function when the Cool, Dry, or Fan mode is running.) (Refer to the remote control manual for product operation) 03 Air intake...
-
Page 15: Operation Features
Operation Features Operating temperature and humidity Indoor unit / Outdoor unit: AC***DN*DCG / AC***DXSCCG OPERATIONAL TEMPERATURE MODEL MODE INDOOR HUMIDITY INDOOR OUTDOOR 64℉ to 90℉ 0℉ to 122℉ Cool 80% or less (18℃ to 32℃) (-18℃ to 50℃) AC009DN1DCG/AA 86℉ or less -13℉... - Page 16 Operation Features Indoor unit / Outdoor unit : AC***DN*DCG / AC***DXSCCF OPERATIONAL TEMPERATURE INDOOR MODE HUMIDITY INDOOR OUTDOOR 64℉ to 90℉ -40℉ to 122℉ Cool 80% or less (18℃ to 32℃) (-40℃ to 50℃) 64℉ to 90℉ -40℉ to 122℉ 80% or less (18℃...
-
Page 17: Cleaning And Maintenance
Cleaning and Maintaining Before cleaning the indoor unit, be sure to turn off the auxiliary power switch. Cleaning the indoor unit exterior 1-way Cassette Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt of odd- shaped areas by using a soft brush. -
Page 18: Cleaning The Air Filter
Cleaning and Maintaining Cleaning the air filter CAUTION • Before cleaning the indoor unit, be sure to turn off the auxiliary power switch. • Be sure to hold the grille with a hand to prevent dropping from the opening of the front grille. 1-way Cassette 1 Detaching the air filter Press the Push signs on the front panel, then open... - Page 19 2 Cleaning the air filter Clean the air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running water and dry it in a ventilated area. CAUTION • Do not scrub the air filter with a brush or other cleaning utensil.
- Page 20 NOTE • The hooks are located on both sides of the front grill with the Samsung logo. Pull out the air filter from the indoor unit. 2 Cleaning the air filter Clean the air filter with a vacuum cleaner or soft brush.
- Page 21 3 Reassembling the air filter CAUTION • If the indoor unit is used without an air filter, the indoor unit may be damaged due to dust. English...
-
Page 22: Resetting The Filter-Cleaning Reminder
Cleaning and Maintaining Resetting the filter-cleaning reminder Programmable Wired Controller After cleaning and reassembling the air filter, be sure to reset the filter-cleaning reminder as follows : • Indoor unit with the wired remote control: Option a. Press the button to display the Option Filter Reset menu. - Page 23 Wireless Remote Control • Indoor unit with the wireless remote control: In operation ▶ ▶ Select ▶ ▶ Settings. Select ▶ ▶ Filter reset. ▶ CAUTION • The filter reset indicator blinks when the air filter should be cleaned. • Although the filter cleaning indicator ( ) does not light, be sure to set the "Filter Reset"...
-
Page 24: Periodic Maintenance
Cleaning and Maintaining Periodic maintenance Requires qualified Unit Maintenance item Interval technicians Clean the air filter. At least once a month Clean the condensate drain pan. Once a year Required Indoor unit Clean the heat exchanger. Once a year Required Clean the condensate drainpipe. -
Page 25: Troubleshooting
The product does not work. • Ventilate the room for which the alarm was activated. Error E697 • Contact the Samsung Electronics service center for assistance. • This error occurs when the R-32 refrigerant sensor has a malfunction or the sensor’s life has expired. - Page 26 Cleaning and Maintaining Problem Solution • Check whether the power is turned on, and then operate the air conditioner again. • Check whether the auxiliary power switch (MCCB, ELB) is turned on. • If the auxiliary power switch (MCCB, ELB) is turned off, the air conditioner does not work although you press the (Power) button.
- Page 27 Problem Solution The air conditioner is • Check whether the wired remote control is set for group control. In this not turned on or off case, the air conditioners connected to the wired remote control are immediately with the wired turned on or off sequentially.
- Page 28 Cleaning and Maintaining Problem Solution • Close the windows and doors to maximize the cooling and heating efficiencies. • If the Cool mode is stopped and then started immediately, cool air comes out after about 3 minutes to protect the compressor of the outdoor unit. The air is not cool or warm enough.
- Page 29 Memo English...
- Page 30 COUNTRY CALL OR VISIT US ONLINE AT AMERICA 888-699-6067 (Samsung HVAC) www.samsunghvac.com...
