Download Print this page

RAMSET JOBMASTER Operator's Instruction & Training Manual

Semi automatic, single shot, powder actuated tool

Advertisement

Quick Links

WARRANTY
Your Ramset™ tool has a warranty against materials or workmanship for a period of 12 months from the date
of purchase, providing the tool has been operated by a trained operator strictly in accordance with these
instructions and Local or Government regulations, using only genuine Ramset™ fasteners, and accessories
or compatible consumables. Within this 12 month period Ramset™ will repair or replace this product free of
charge if it shall be found to be defective under normal use due to faulty workmanship or materials.
Claims under the guarantee may be made by delivering the product undismantled to the seller from whom
it was purchased or by making a claim to such a seller in writing, in either case within 7 days of the defect
becoming apparent.
In addition to other rights and remedies that may be available under law, our goods come with guarantees that
cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonable foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
Find your local Ramset Service Agent:
https://ramset.com.au/store-locator/
or call 1300 780 063
Ramset™ 1 Ramset Drive, Chirnside Park, Victoria. 3116. Australia
In the interests of product improvement, Ramset™ reserves the right to alter product specifications as required. Information included in this product catalogue is correct at time of printing. It
is the responsibility of the user to ensure product selected is appropriate for its intended use. For further technical information go to www.ramset.com.au or contact Ramset™ on the numbers
indicated. ITW Australia Pty. Ltd. ABN 63 004 235 063 trading as Ramset™ © Copyright 2025 Disclaimer: The information contained in this publication is intended to give a fair description
of the products and their capabilities. No responsibility or liability by the manufacturers will be accepted for misuse, misreading or deviation from the recommended guidelines of these
products. As new technology is introduced, or industry standards are altered, Ramset™ reserves the right to alter the information without notice.
CB1564
Ramset
Australia
Sales, Orders and Enquiries
Tel:
1300 780 063
Email:
enquiry@ramset.com.au
Web:
www.ramset.com.au
Ramset
New Zealand
Sales, Orders and Enquiries
Tel:
0800 RAMSET (726738)
Email:
info@ramset.co.nz
Web:
www.ramset.co.nz
J O B M A S T E R
Operator's Instruction
& Training Manual
Semi Automatic, Single Shot, Powder Actuated Tool

Advertisement

loading
Need help?

Need help?

Do you have a question about the JOBMASTER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RAMSET JOBMASTER

  • Page 1 For further technical information go to www.ramset.com.au or contact Ramset™ on the numbers indicated. ITW Australia Pty. Ltd. ABN 63 004 235 063 trading as Ramset™ © Copyright 2025 Disclaimer: The information contained in this publication is intended to give a fair description of the products and their capabilities.
  • Page 2: Safety Introduction

    THIS TOOL IS TO BE USED ONLY BY PROPERLY TRAINED Powder-actuated fastening is suitable for AND LICENSED OPERATORS. use in the following base materials only: YOU MUST SUCCESSFULLY COMPLETE THE RAMSET TRAINING • Poured Concrete PROGRAM FOR THE TOOL AND OBTAIN A CERTIFIED •...
  • Page 3 DANGER DANGER SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Tool Handling Safety Loads and Load Selection Safety Always be sure tool is operating 1. Always make a test fastening after properly before attempting to use being sure that the base material is it. Follow the “Daily Function Check” suitable for powder actuated fastening.
  • Page 4 DANGER SPALL GUARD TOOL OPERATOR OR Never use any other types of fasteners or strip loads in the Ramset Jobmaster tool. Use of other BYSTANDERS. types of fasteners or loads may cause unintentional load discharge, damage the tool, cause poor fastening performance, or create a risk of serious injury to the operator or bystanders.
  • Page 5 FASTENING APPLICATIONS TOOL OPERATING INSTRUCTIONS FASTENING APPLICATIONS TOOL OPERATION Your Ramset tool can be used for a wide 100mm 100mm Daily Function Test range of fastening needs in a variety of base Always check the tool first to make sure materials.
  • Page 6: Troubleshooting

    Power Adjust wire brush Failure of tool Retaining ball missing Call (02) 9829 4000 The power level of the JOBMASTER can be REMOVE THE LOAD STRIP ONLY FROM THE to stay closed decreased for optimum penetration of the Pawl cap loose...
  • Page 7: Parts Schematic

    Complete disassembly and cleaning of all parts may be necessary to restore the tool to normal operation. General maintenance should be performed every six months or more often if the tool is subjected to heavy use. Call 1300 780 063 or find your local Ramset Service Agent https://ramset.com.au/store-locator/ ALWAYS FUNCTION TEST THE TOOL AFTER PERFORMING ANY SERVICE.
  • Page 8: Disassembly & Cleaning

    DISASSEMBLY & CLEANING DISASSEMBLY & CLEANING TOOL DISASSEMBLY 6. Pull the piston assembly out of the barrel 1. Unscrew the silencer nut. assembly. REMOVE THE PISTON UNSCREW THE SILENCER NUT The tool is now disassembled for normal cleaning. 2. Remove the silencer slide. Inspect all parts for wear or damage and clean or replace as required.
  • Page 9 Complete the information on the other side of this page. The JOBMASTER™ Tool is warranted for 12 months after sale by ITW Brands. Enclose a copy of your sales receipt and send to the address on the back of this manual to activate your tool warranty and receive your tool license.
