Extron electronics CC 101P Installation Manual page 2

4. Connect the line output cable to the rear panel 3-pole captive screw Line Output connector (see
Line Input on the front panel of the CC 100C. Connect the positive (+) pole to positive (+) and the ground (arrow) to ground
(arrow).
5.
Connect the contact in cables to the rear panel 2-pole captive screw connector (see
on the rear panel of the CC 100C. Connect the "IN" to the "NO" (normally open) and the ground "G" to common "C."
6. Connect the contact out cable to the rear panel 2-pole captive screw connector (see
connector on the rear panel of the CC 100C. Connect the "OUT" to "O" and the ground "G" to ground "G."
7. Observing correct polarity (see Note), connect the power cable to the rear panel 2-pole captive screw connector (see
figure 3), and to the 2-pole power connector on the rear panel of the CC 100C or the PlenumVault System power supply.
NOTE:
To maintain correct polarity, ensure the power cable is connected as positive (+) to positive (+), and negative (-) to
negative (-).
If sufficient power is not available, connect the CC 101P directly to an optional Extron power supply.
NOTE:
The CC 101P is to be used with Extron power supplies only and as listed above.
8. Turn the system on and test the microphone transmission for level. Adjust the Mic Gain as needed (see
9. Set the tone switch as desired (see
when the room is being monitored. Setting the switch to Off (down) disables the recurring tone (default setting).
10. Mount the cabled device into the mud ring or wall box, and attach the supplied faceplate.
NOTE:
To help complete installation and connection details, see the CC 100C Installation Guide, available online at
www.extron.com.
E
F
G
H
I
J
CC 101P Side View
Figure 3. Wiring the Rear Panel of the CC 101P to the CC100C
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Safety and Regulatory Compliance Guide
2
in figure 3). When setting the switch to On (up), the unit emits a tone every 10 seconds
F
CC 100C Front Panel
REMOTE
RESET
RS-232/RS-485
Adjust
Gain
MIC SPKR
On
V
Off
INPUT RELAY N/A
0 1 G NO C NC
Connect power cable to power supply.
on the Extron website.
© 2014-2025 Extron — All rights reserved.
All trademarks mentioned are the property of their respective owners.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
CC 100C
USB
STORAGE
LINE
IN OUT SUB
STATUS MIC A B
CC 100C Rear Panel
POWER IN
LAN/PoE 12-15V
12W MAX
www.extron.com
in figure 3), and to the
G
in figure 3), and to the relay connector
I
in figure 3), and to the contact input
H
in figure 3).
E
in
J
Extron
68-2517-01 Rev. B
02 25
