Manual P/N 854-30000
This material contains information of proprietary interest to BVM Ltd. It has been supplied in
confidence and the recipient, by accepting this material, agrees that the subject matter will not be
copied or reproduced, in whole or in part, nor its contents revealed in any manner or to any person
except to meet the purposes for which it was delivered.
User's Manual
cPC2PMC
CompactPCI
Hot Swap
Dual PMC Carrier
Board Revision A
Manual Revision B 14 June 2000
BVM Limited,
Hobb Lane,
Hedge End,
Southampton,
SO30 0GH, UK.
TEL: +44 (0)1489 780144
FAX: +44 (0)1489 783589
E-MAIL: sales@bvmltd.co.uk
WEB:
http://www.bvmltd.co.uk
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CompactPCI cPC2PMC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BVM CompactPCI cPC2PMC

Summary of Contents for BVM CompactPCI cPC2PMC

  • Page 1 Board Revision A Manual Revision B 14 June 2000 This material contains information of proprietary interest to BVM Ltd. It has been supplied in confidence and the recipient, by accepting this material, agrees that the subject matter will not be copied or reproduced, in whole or in part, nor its contents revealed in any manner or to any person except to meet the purposes for which it was delivered.
  • Page 3 BVM Ltd. This applies to any merged, modified or derivative version USE OF PRODUCT...

  • Page 5: Table Of Contents

    Table Of Contents Contents Page 1. Introduction ............................1 1.1 Scope ............................1 1.2 cPC2PMC Part Numbers ......................1 2. Overview ............................2 2.1 Board Layout ..........................2 2.2 Features .............................3 2.3 Applications ..........................3 3. Operation ............................4 3.1 Block Diagram ..........................4 3.2 General Description........................4 ® 3.3 CompactPCI Interface ......................5 3.3.1 PCI2250 Features........................
  • Page 6 Appendix A Data Sheets & Manual References .................16 A.1 PCI2250 PCI-to-PCI Bridge......................16 ® A.2 LTC 1643L Hot Swap Controller....................16 A.3 PMC Specification ........................16 ® A.4 CompactPCI Core Specification.....................16 ® A.5 CompactPCI Hot Swap Specification ..................16 ® A.6 PMC on CompactPCI Specification..................16 List of Figures Figure...

  • Page 7: Introduction

    The User manual is intended for use by system integrators, service personnel, software engineers and end users. Unless otherwise stated, address information is in hexadecimal notation. cPC2PMC Part Numbers Part Number Description ® 852-30010 CompactPCI Dual PMC Carrier Copyright  2000 BVM Ltd.

  • Page 8: Overview

    cPC2PMC Overview Board Layout PMC Site 2 PMC Site 1 CPC2PMC Figure 1 Board Layout...

  • Page 9: Features

    General purpose carrier for PMC modules. • Supports a wide range of industrial I/O PMC modules. • High performance PMC I/O (serial, SCSI, Ethernet etc.). • Hot-swappable carrier for PMC modules. • Extraction & insertion in live systems. Copyright  2000 BVM Ltd.

  • Page 10: Operation

    cPC2PMC Operation Block Diagram Pn1 Pn2 PMC 2 Pn1 Pn2 PMC 1 PCI Bridge swap control Figure 2 Block Diagram General Description ® The cPC2PMC is a hot swappable CompactPCI PMC carrier. Two PMC module sites are provided. It is possible to remove the cPC2PMC and associated PMC modules (with suitable hot swap driver ®...

  • Page 11: Compactpci Interface

    VI/O without any setting changes. The CompactPCI VI/O setting has no effect on the PMC sites. The ® ® cPC2PMC is a 32-bit 33MHz CompactPCI module. The CompactPCI enclosure can be standard, Hot Swap or High Availability. Copyright  2000 BVM Ltd.

  • Page 12: Pci Hot Swap Signals

    cPC2PMC 3.3.3 PCI Hot Swap Signals The following Compact PCI Hot Swap signals are used on the cPC2PMC: Compact PCI Signal Name Purpose ENUM# Used to indicate to the system controller that the cPC2PMC has been inserted or is about to be removed. This is an open collector output from the cPC2PMC.

  • Page 13: Hot Swap Controller

    The cPC2PMC uses a microswitch built in to the lower front-panel ejector/injector handle. A change of ® state in the microswitch will occur during an insertion and extraction from a CompactPCI backplane. ® This will cause the ENUM# signal to be asserted on the CompactPCI backplane. Copyright  2000 BVM Ltd.

  • Page 14: Installation

    cPC2PMC Installation 1. PMC modules should only be installed when the cPC2PMC is in a powered-off condition to avoid damage to the PMC module and host carrier board. Normal ESD protection procedures should be followed to avoid damage to the board. 2.

  • Page 15: Configuration

    PMC modules that generate power management events. Function ® 1 & 2 Fitted ! CompactPCI ENUM# generated from PMC PME# ® 1 & 2 Omitted NO CompactPCI ENUM# generated from PMC PME# Copyright  2000 BVM Ltd.

  • Page 16: Lk2 Jtag Bypass 1

    cPC2PMC 5.2.2 LK2 JTAG Bypass 1 ® When fitted the CompactPCI JTAG daisy chain bypasses PMC site 1. When omitted PMC site 1 is ® included in the CompactPCI JTAG daisy chain. Function 1 & 2 Fitted ! PMC site 1 JTAG daisy chain bypassed 1 &...

  • Page 17: Connections

    AD[23] AD[22] AD[26] CVIO AD[25] AD[24] AD[30] AD[29] AD[28] AD[27] REQ# 3.3V AD[31] BRSVP1A5 BRSVP1B5 RST# GNT# BRSVP1A4 HEALTHY# CVIO INTP INTS INTA# INTB# INTC# INTD# -12V TRST# +12V Signals required for Hot Swap support. Copyright  2000 BVM Ltd.

  • Page 18: Compactpci Connector J3 And J4

    cPC2PMC ® CompactPCI Connector J3 and J4 This table shows the connections between the Pn4 connector on the two PMC sites (1 & 2) and the ® CompactPCI connectors J3 & J4. This is as per the PMC on Compact PCI Specification PICMG 2.3 R1.0.

  • Page 19: Pn1 & Pn2 Pmc Pci

    The INTx designation denotes the PMC board signal name - see section "7.2.2 Interrupt Routing (page 14)" for cPC2PMC interrupt routing. The BUSMODE4#, 3# & 2# signals are configured to the pattern LLH (indicating PMC). Copyright  2000 BVM Ltd.

  • Page 20: Programming

    cPC2PMC Programming PCI2250 PCI-to-PCI Bridge ® ® Support for the PCI2250 PCI-to-PCI Bridge is built into Windows 98 and Windows 2000. For further information see the data referenced in "A.1 PCI2250 PCI-to-PCI Bridge (page 16)". PMC Sites 7.2.1 PCI Device Numbering Local PCI device numbers for the two PMC sites are allocated as follows: Device Number For PMC in site 1 only...

  • Page 21: Specification

    I/O connection: PICMG 2.3 R1.0 PMC on CompactPCI Compliant. Operating Environment Dimensions: 160mm x 233.35mm (6U) single slot. Power: +3.3V 250mA, +5V 20mA typical (excluding PMC requirements). Environmental: 0 to 70 °C, 95% humidity non-condensing (extended range to order). Copyright  2000 BVM Ltd.

  • Page 22: Appendix A Data Sheets & Manual References

    cPC2PMC Appendix A Data Sheets & Manual References PCI2250 PCI-to-PCI Bridge Texas Instruments PCI2250 PCI-to-PCI Bridge Data Manual - Literature Number: SCPS051 - December 1999. (http://www.ti.com) ® 1643L Hot Swap Controller Linear Technology Corporation LTC1643L/LTC1643L-1/LTC1643H PCI-Bus Hot Swap Controller - 1643f LT/TP 0899.
