Assembly Instructions
Knutsford Pavilion 2.4m
Code: 15221
V7 12 23
(W x D x H) 2.80m x 2.80m x 2.30m
ONLINE ASSEMBLY VIDEO AVAILABLE
Please scan the QR code or visit zestoutdoorlivingsupport.co.uk
PLEASE KEEP THESE INSTRUCTIONS
www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk
1
of 10
Advertisement
Related Manuals for Zest Knutsford 15221
Summary of Contents for Zest Knutsford 15221
- Page 1 Assembly Instructions Knutsford Pavilion 2.4m Code: 15221 V7 12 23 (W x D x H) 2.80m x 2.80m x 2.30m ONLINE ASSEMBLY VIDEO AVAILABLE Please scan the QR code or visit zestoutdoorlivingsupport.co.uk PLEASE KEEP THESE INSTRUCTIONS www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk of 10...
- Page 2 European redwood. Unlike man-made materials, timber is an entirely natural material, and each piece has its own distinctive qualities. So, owning a Zest timber product is like enjoying a unique slice of nature. The benefits of slow grown timber: Trees grow slowly in the cold climate of Eastern...
- Page 3 Knutsford Pavilion 2.4m Assembly Instructions Requires 2-3 Person assembly *All Screw holes to be pre-drilled* Tools required: Corded / Cordless Drill, *Pozi-drive bit (*Crosshead) / 3mm & 5mm drill bits / Screwdriver, (Torx-Bits Included), Tape Measure, Mallet. Please take a few moments to check all pack contents listed Knutsford Pavilion 2.4m Pack List Code Item...
- Page 4 Set out Ring Beams A1 & A2 as shown above and fix in position using 8 x 60mm screws, (2 x 60mm Screws per corner.). Position 2 x Posts (B) beneath Ring Beam (A1) and attach using 2 x 120mm Screws, (1 x 120mm screw per post.).
- Page 5 Place remaining Posts (B) beneath Ring Beam and fix using 2 x 120mm Screws, (1 x 120mm screw per post.). Position 1 x Hand Rail (C) between Posts (B) at desired height and fix using 4 x 120mm Screws, (2 x 120mm per post.), Repeat for remaining 2 x Hand Rails (C) www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk of 10...
- Page 6 Place 1 x Handrail Cover (D) onto Handrail (C) and fix using 4 x 45mm Screws. Repeat for remaining 2 x Handrail Covers (D) and Handrails (C) Fix 1 x Bracing (E) to Post (B) & Ring beam using 2 x 140mm Screws as shown above. Attach remaining Bracings (E) to Posts (B) &...
- Page 7 Attach angled end of 1 x Rafter (F) to Finial Block (G) allowing a 20-25mm gap between Rafter (F) and Finial Block Capping using 1 x 100mm Screw. Similarly attach 1 x Rafter (F) to opposite side of Finial Block (G) Place rafter assembly diagonally onto ring beam and fix using 2 x 100mm Screws, (1 x 100mm Screw per rafter.).
- Page 8 Attach remaining 2 x Rafters (F) to Finial Block (G) using 2 x 100mm Screws, (1 x 100mm Screw per Rafter (F)), and to Ring beam using 2 x 100mm Screws (1 x 100mm screw per Rafter (G)). Attach 1 x Centre Rafter (H) to Final Block (G) using 1 x 100mm Screw and to Ring beam using 1 x 100mm Screw.
- Page 9 Open 1 x Roof Board pack and set out as shown above (Top). Attach longest pair of square ended roof boards to Centre Rafter (H) and to Rafters (F) (allowing a 10-15mm overlap beyond rafter ends) using 8 x 45mm Screws. (4 x 45mm Screws per board, 2 x 45mm Screws per end). Interlock shorter pair of square ended Roof Boards to fixed Roof Boards and continue to interlock subsequent Roof Boards.
- Page 10 Place 1 x Long Cover Strip (J) over joint in roof boards and under finial block capping (angled cut beneath capping and facing upwards). Fix in position using 8 x 45mm screws (2 x 45mm screws per end, 2 x 45mm either side of centre). Repeat on remaining roof board joints using 3 x Long Cover Strips (J) (1 x Long Cover Strip per joint).
