Summary of Contents for Deepcool CG580 4F Series
- Page 1 CG580 4F Series Panoramic Glass Panels Single Chamber ATX Case...
-
Page 3: Case Features
Case Features Case Specifications Length:437mm Maximum GPU length:410mm Radiator compatibility: Fan locations: Width:235mm Maximum PSU length:210mm Front: NA Front: NA Height:501mm Maximum CPU Cooler length:176mm Top: 120/140/240/280/360mm Top: 3×120 / 2×140mm Side: 120/240/360mm Side: 3×120mm Rear: 120/140mm Rear: 1×120mm / 1×140mm Bottom: 1×120mm(3.5 HDD/ 120FAN: Choose one of two) PSU Shrouded: 2×120mm... - Page 4 ×1 ×1 Tempered Glass Side Panel Right Side Panel ×1 ×2 Tempered Glass Front Panel Top&Bottom Dust Filter...
- Page 5 ×1 ×1 Hard Disk Bracket Side Panel Dust Filter ×1 ×3 120mm PWM ARGB Fan 120mm PWM ARGB Reverse Blade Fans...
- Page 6 PSU Screws Motherboard Screws HDD Screws Stand Off Sleeve Screws Sunk Screws PCIE Rear Panel Cable Ties...
-
Page 7: Specifications
Specifications 235mm 437mm 501mm... - Page 8 120mm×1 140mm×1 120/140mm...
- Page 9 120mm×3 120/240/360mm...
- Page 10 120mm×3 140mm×2 120/140/240/280/360mm...
-
Page 11: Removing The Side Panel
Removing the Side Panel... -
Page 14: Installing The Front Panel
Installing the Front Panel... -
Page 15: Installing The Motherboard
Installing the Motherboard Rear Connector Motherboards:M-ATX/ATX... - Page 16 Installing the GPU...
- Page 17 Veritical GPU Bracket Mode...
-
Page 20: Installing Hdds
Installing HDDs... -
Page 23: Installing Ssds
Installing SSDs... -
Page 24: Installing The Power Supply
Installing the Power Supply... - Page 25 I/O Panel Introduction TYPE-C USB 3.0 USB 3.0 MIC/AUDIO POWER...
-
Page 26: Installing The Front I/O Connectors
Installing the Front I/O Connectors USB3.0 TYPE-C HD AUDIO F_PANEL LED/SW... - Page 27 Manual ARGB&Fan Wiring...
- Page 28 Motherboard RGB Synchronization...
-
Page 29: Fan Connection
Fan Connection...
