- Page 1 CG530 4F Series Panoramic Glass Panels Dual Chamber ATX Case...
- Page 3 Case Features Case Specifications Radiator compatibility: Length：440mm Maximum GPU length：410mm Front：NA Width：285mm Maximum PSU length：210mm Top: 120/140/240/280/360mm Height：399mm Maximum CPU cooler height：160mm Side: 120/140/240/280mm Fan locations: Bottom: 120/240/360mm Front：NA Top: 3x120mm/2x140mm Side: 3x120mm/2x140mm Rear: 1x120mm Bottom: 3×120mm/3.5 HDD+2x120mm/2.5 SSD+2x120mm...
- Page 4 ×1 ×1 Tempered Glass Side Panel Right Side Panel ×1 ×1 Tempered Glass Front Panel Top Dust Filter...
- Page 5 ×1 ×1 Bottom Dust Filter Hard Disk Bracket ×1 ×3 120mm PWM ARGB Fan 120mm PWM ARGB Reverse Blade Fans...
- Page 6 ×18 ×3 ×1 Stand Off Sleeve Screws ×5...
- Page 7 Specifications 285mm 440mm 399mm...
- Page 8 120mm×1...
- Page 9 120mm×3 140mm×2 120/140/240/280mm...
- Page 10 120mm×3 140mm×2 120/140/240/280/360mm...
- Page 11 120mm×3 3.5 HDD+2×120mm 2.5 SSD+2×120mm 120/240/360mm...
- Page 12 Removing the Side Panel...
- Page 15 Installing the Motherboard M-ATX Rear Connector Motherboards:M-ATX/ATX...
- Page 16 Installing the GPU...
- Page 17 Installing HDD...
- Page 19 Installing SSD...
- Page 20 Installing the Power Supply...
- Page 21 I/O Panel Introduction TYPE-C USB3.0 USB3.0 MIC/AUDIO POWER...
- Page 22 Installing the Front I/O Connectors USB3.0 TYPE-C HD AUDIO F_PANEL LED/SW...
- Page 23 Manual ARGB&Fan Wiring...
- Page 24 Motherboard RGB Synchronization...
- Page 25 Fan Power Line Wiring...
- Page 27 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr+6） （PBB） （PBDE） 机壳 ○ ○ ○ ○ ○ ○ 塑胶 ○ ○ ○ ○ ○ ○ 螺丝 ○ ○ ○ ○ ○ ○ 集成电路 ○ ○ ○ ○ ○...
