Deepcool FISHTANK CG530 Series User Manual

Panoramic glass panels dual chamber atx case

Advertisement

Quick Links

CG530 Series
Panoramic Glass Panels Dual Chamber ATX Case

Advertisement

loading
Need help?

Need help?

Do you have a question about the FISHTANK CG530 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Deepcool FISHTANK CG530 Series

  • Page 1 CG530 Series Panoramic Glass Panels Dual Chamber ATX Case...
  • Page 3 Case Features Case Specifications Radiator compatibility: Length:440mm Maximum GPU length:410mm Front:NA Width:285mm Maximum PSU length:210mm Top: 120/140/240/280/360mm Height:399mm Maximum CPU cooler height:160mm Side: 120/140/240/280mm Fan locations: Bottom: 120/240/360mm Front:NA Top: 3x120mm/2x140mm Side: 3x120mm/2x140mm Rear: 1x120mm Bottom: 3×120mm/3.5 HDD+2x120mm/2.5 SSD+2x120mm...
  • Page 4 ×1 ×1 Tempered Glass Side Panel Right Side Panel ×1 ×1 Tempered Glass Front Panel Top Dust Filter...
  • Page 5 ×1 ×1 Bottom Dust Filter Hard Disk Bracket...
  • Page 6 ×18 ×3 ×1 Stand Off Sleeve Screws...
  • Page 7 Specifications 285mm 440mm 399mm...
  • Page 8 120mm×1...
  • Page 9 120mm×3 120/140/240/280mm...
  • Page 10 120mm×3 140mm×2 120/140/240/280/360mm...
  • Page 11 120mm×3 3.5 HDD+2×120mm 2.5 SSD+2×120mm 120/240/360mm...
  • Page 12 Removing the Side Panel...
  • Page 15 Installing the Motherboard M-ATX Rear Connector Motherboards:M-ATX/ATX...
  • Page 16 Installing the GPU...
  • Page 17 Installing HDD...
  • Page 19 Installing SSD...
  • Page 20 Installing the Power Supply...
  • Page 21 I/O Panel Introduction USB2.0 USB3.0 USB3.0 MIC/AUDIO RESET POWER...
  • Page 22 Installing the Front I/O Connectors USB3.0 USB2.0 HD AUDIO F_PANEL...
  • Page 23 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr+6) (PBB) (PBDE) 机壳 ○ ○ ○ ○ ○ ○ 塑胶 ○ ○ ○ ○ ○ ○ 螺丝 ○ ○ ○ ○ ○ ○ 集成电路 ○ ○ ○ ○ ○...

This manual is also suitable for:

Fishtank cg530Fishtank cg530 whR-cg530-bknda0-g-1R-cg530-whnda0-g-1
