  • Page 1 OWNER’S MANUAL LG LED Screen Please read this manual carefully before install & operating your set and retain it for future reference. LAEC015-GN2 www.lg.com Copyright © 2022 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS……………………3 - Precautions for the AC Adapter and Power………… 4 - Precautions for Moving the Product…………………..6 - Precautions for Installing the Product………………...7 - Precautions for Cleaning the Product………………...9 - Precautions for Using the Product…………………...10 - Precautions for Using the Remote control…………..12 - Precautions for Experiencing Image Retention……13 - Product Disposal……………………………………….13 PREPARATION………………………..……..14...

  • Page 3: Safety Precautions

    WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. SAFETY PRECAUTIONS The Safety Precautions are intended to prevent unexpected danger or harm by helping the user to use the product safely and for its intended purpose. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.

  • Page 4: Precautions For The Ac Adapter And Power

    WARNING • Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord, make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized service center for a replacement.
  • Page 5 • If water or any foreign substance goes inside the product, disconnect the power cord immediately and contact the service center. - Otherwise, this may cause a fire or electric shock due to damage to the product. • Keep the power cord or AC adapter away from any heating devices. - The cord coating may melt and cause fire or electric shock.

  • Page 6: Precautions For Moving The Product

    Precautions for Moving the Product WARNING • Contact the service center before moving the product. - It may cause electric shock and damage the product. • Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved.

  • Page 7: Precautions For Installing The Product

    Precautions for Installing the Product WARNING • Contact the service center before installing the product. - It can cause electric shock and damage the product. • Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects near the product to prevent throwing things on the product screen.
  • Page 8 CAUTION • Install the product where no Electromagnetic Interference occurs. • If you install the product in a place that does not meet the recommended conditions, this may cause serious damage to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing.

  • Page 9: Precautions For Cleaning The Product

    Precautions for Cleaning the Product WARNING • Keep the product clean at all times. - If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage. • When you need to clean the inside of the product, you must contact the service center. - Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product.

  • Page 10: Precautions For Using The Product

    Precautions for Using the Product WARNING • Do not use the product in any environment with excessively high temperatures or humidity. • If you use the product for a long period of time, take a rest from time to time to protect your vision. - Extended viewing could result in impaired vision.
  • Page 11 • Do not use high voltage electrical goods near the product (e.g., a bug zapper). - This may result in product malfunction if it receives an electrical shock. • If there is a gas leak, do not touch the outlet, and open the windows for ventilation. - Otherwise, the product may cause fire or electric shock.

  • Page 12: Precautions For Using The Remote Control

    Precautions for Using the Remote control WARNING • Avoid places with high humidity. - It may cause electrical shock or damage the product. • Do not expose batteries to excessive heat, such as direct sunlight, open fireplace, and electric heaters. - It may cause fire and you may be injured.

  • Page 13: Precautions For Experiencing Image Retention

    Precautions for Experiencing Image Retention • Displaying a still image for a prolonged period of time may cause damage to the screen, resulting in image retention. Most third-party products have the same issue. The resulting damage is not covered by the product warranty. - Use a screen saver when using the monitor for a prolonged period of time.

  • Page 14: Preparation

    PREPARATION Packaging NOTE: The pictures are schematic diagrams. Everything is subject to the in fact products. Carton Packaging...
  • Page 15 1. Pack up the LDMs. Pack up six LDMs into an antistatic bag separately and set them into the carton. (Pack up all the LDMs in this way. Seal the cartons. Then put the cartons into the Carton Packaging . 6pcs LDMs...
  • Page 16 2. Pack up the mounting plate. 3. Pack up the cabinet and put them into the Carton Packaging .

  • Page 17: Setting

    Setting The introduction of LAEC015-GN2 screen interface and function 1. Remote Controller 2. Interface and Button Specifications NOTE: The volume buttons are not placed on the cabinet. It can only be controlled by the remote controller.

  • Page 18: Remote Control

    REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching terminals to the labels inside the compartment, and close the battery cover.
  • Page 19 Selects the Picture Mode. (HOME) Activates the Launcher. Enters the White Balance menu. (SETTINGS) Accesses the main menus or saves your input and exit menus. SuperSign menu key. (Navigation Buttons) Scrolls through menus or options. Selects menus or options and confirms your input. (BACK) Allows you to move back one step in the user interaction function.

  • Page 20: Assembly

    The panel is designed to be mounted to a fixed framework. The listing in Table 2.1 is the main components of a LAEC015-GN2 LED panel. The profile of the panel is shown in Figure 2.1.
  • Page 21 Card Convertor Board, I/O Board, LAEC controller Board and Power Board. Please refer to the description for each board in the follow sections. LAEC015-GN2 LED display is combined with LDM and case. The LDMs and case are fixed by magnetic structure.
  • Page 22 Figure 2.2 Major components of LAEC015-GN2 LED panel assembly...

  • Page 23: Mechanical Assembly

    MECHANICAL ASSEMBLY Unit: (mm) <side view> <rear view> Unit: (mm) <Front View>...
  • Page 24 LED Display Module (LDM) The front face of the LAEC015-GN2 LED display is fitted with 72 light emitting diode (LED) dot LED modules known as LDMs. Each LDM is fitted with 28800 LEDs* plus associated drive electronics. Electrical connections (low voltage power, and digital data) are made to the rear of each LDM, from inside of the enclosure.

  • Page 25: Installation Guidelines

    The LAEC015-GN2 LED display is designed to be mounted on the stand (sold separately) or on the wall. When installing, it is important to ensure that the entire screen is correctly aligned, both vertically and horizontally.

  • Page 26: Mounting Plate Installation

    1) Mounting Plate Installation Wall mount piece list Item Description Photo Qty. Top slip plate Left and right connection plate Low slip plate Low fixed plate Top and low Connection plate M4x10 Flat Head Screw M4 NUT M8x60 Expansion Screw M6 screws screw gasket...
  • Page 27 Wall Mount Drawing Step1. Install 2pcs Top slip plate (item 1) with Left and right connection plate(item 2) Lock 16pcs M4X10 screw (item 6)
  • Page 28 Step2. Install the top plate and low plate (item3&4) with connection plate (item 5). Lock 12pcs M4 nut (item 7)
  • Page 29 Step3. Double check the dimension after assembling. Install the mounting plate to the desired location and secure them with 21 pcs M8x60 explosion screws(item8). (The following locations which should be installed the screws are marked in circle. The depth is about 60-65mm)

  • Page 30: Screen Assembly

    2) Screen assembly The 7 PCS fixed screw(mounting lock+ M10x20 screw) behind the cabinet are assembled to the cabinet and locked with tools. Mounting lock+ M10x20 screw Rear view Loosen 2pcs M4 nuts， remove the cover Left cabinet Right cabinet Note: Please install the right cabinet first and then install the left cabinet.

  • Page 31: Screen Installation

    Screen Installation 1.The two members jointly lifted the right half cabinet and placed it on the Mounting Plate. Adjust to fit，on the waist hole add a screw gasket (item 10) ,then lock M6 screws(item 9), and fix the left box to prevent left and right movement 2.Place the left half cabinet on the bracket in order.
  • Page 32 3.You need to connect all the cables and install back all the LDMs. 1pc AC Cable 4pcs Network Cables. 1pc speaker cable Please pay attention the cables. connector RJ45 cable labeled OUT1 is matched to the connector labeled OUT1.
  • Page 33 4.The cabinet is combined by sliding on the wall mount, we must make sure that the aluminum block is properly connected to the positioning. 5.After the cabinet is joined, follow the instructions of Label to quickly fix the cabinet with the hexagonal plate.
  • Page 34 6.Install and tighten 8 pcs black M4 flat head screws to both top and bottom side of the case. No screws 2 PCS M4 screws Before install screws After install screws 2 PCS M4 screws 7.Install M4 screws. Install 11 pcs fasten screws. Install 18 pcs M4 flat head screws.
  • Page 35 8.The Sensor Box Module has a cable connector to connect the mainboard and the "IR sensor board" of the Sensor Box Module. After the cables are properly connected, the Sensor Box Module is locked with 2 pcs M3 screws below the middle of cabinet. These two screws marked in red must be installed with a screwdriver and cannot be omitted.
  • Page 36 Dismount LDM Step1. Power off the LED display. Step2. Hold the 2pcs handles, push the lock inward and pull the handles toward outside, and then take it up. Handles lock Step3. Take the tool up and horizontally fit it closely to the display surface. Please pay more attention to the direction.
  • Page 37 Step4. Pull the handles towards the center. Step5. Ensure the magnet is locked. Take down the LDM carefully. Step6. Put down the LDM and tool together carefully onto an anti-static soft pad(such as white foam which used to protect the parts in the Carton Packaging ,please refer to page15,item 3 ). Step7.
  • Page 38 Mount LDM Step1. Wear anti-static gloves, then take out a LDM. The arrow on the back of the LDM indicates the top direction. Check this before attaching the LDM Step2. Locate the LDM to case Caution: There are guide pins on the back of the LDM to ensure that the LDM is attached to the correct position on the cabinet.

  • Page 39: Electrical

    Electrical The power distribution system used must provide adequate protection against excess line current and leakage currents to earth. Electrical Characteristics for ONE LAEC015-GN2 At 100V AC Input At 240V AC Input Parameter Unit Rating Parameter Unit Rating Normal Normal...
  • Page 40 Earthing Each panel is separately connected to the AC power distribution system’s earth through the appliance coupler. All exposed panel metalwork (main frame) is also connected to this earth. If the framework is earthed only through each panel (i.e. through the panel’s mounting bolts), there is a possibility of electrical damage if a wiring fault occurs, or if an electrical discharge, such as lightning strike, hits the panels.
  • Page 41 CE-EMC Statement This product has been certificated by CE. Installations should be located at least 30 meters from other sensitive systems or installations and if situated in close proximity to a roadway it may create interference to vehicle radio communications. FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 42: Power Cable Wiring

    Power Cable Wiring AC Power An approved three-pole appliance coupler inside the panel connects to the AC supply. The AC power cable is then connected to the EMI filter and distributes to the power supply units. Each panel has an earth point for grounding.

  • Page 43: Making Connections

    MAKING CONNECTIONS You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device. Connecting to a PC Some of the cables are not provided.
  • Page 44 NOTE • For the best image quality, using the monitor with HDMI connection is recommended. • To comply with the specifications of the product, use a shielded interface cable with ferrite core, such as a HDMI cable. • If you turn the monitor on when the set is cold, the screen may flicker. This is normal. •...

  • Page 45: Using The Input List

    Using the Input List (HOME) → → → → Connecting cables Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product. You can turn the product on/off, select an input source and adjust the OSD menu from your PC.

  • Page 46: Troubleshooting

    TROUBLESHOOTING • Is the power cord connected to the product? - Check if the power cord is correctly plugged into the power outlet. • Did you install the driver? - Check if the function is supported by referring to the graphics card user manual. •...
  • Page 47 Network connection problems • If the main network line to the last abnormal module is not bright, the main network line is connected abnormally, and the abnormal module outputs an abnormal network line. Inspection: Recheck the state of the network cable in the corresponding position to confirm that the connection is OK.
  • Page 48 LDM problems • The abnormal module position of LDM is abnormal. Inspection: Replace the LDM in the corresponding position. • You can replace it with the following procedure. 1. Power off the panel and unplug the power cable; 2. Locate the problem LDM; 3.
  • Page 49 The adapter board problems • The abnormal module position of LDM is not bright, the state of the adapter board in the corresponding position is work abnormally. Inspection: Replace the adapter board in the corresponding position. The receiver board problems •...
  • Page 50 The calibration data is abnormal • Some LDMs are particularly bright when the screen is white, unlike others. Inspection: Switch calibration off again, then switch to calibration on to confirm the existence of calibration data. You can also switch LDMs data and receiver card data to confirm that the calibration data exists and is correct.

  • Page 51: Product Specifications

    PRODUCT SPECIFICATIONS The product specifications below may be changed without prior notice due to upgrade of product functions. “ ” refers to alternating current (AC), and “ ” refers to direct current (DC). Pixel pitch (distance between pixels) 1.5625 mm Min.
  • Page 52 Crestron Connected Power Mgmt. On/Off Schedule Holiday Schedule LG ConnectedCare Software Compatibility SuperSign CMS LG Assistant SuperSign Software & Manual Downloading from the LG Electronics website. Visit the LG Electronics website http://partner.lge.com and download the latest software for your model.
  • Page 53 Wireless module(LGSBWAC72) Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency range (MHz) Output power (Max.) (dBm) 2400 to 2483.5 5150 to 5725 16.5 5725 to 5850 (Not for EU) 11.5 Bluetooth Frequency range (MHz) Output power (Max.) (dBm) 2400 to 2483.5 • As band channels can vary per country, the user cannot change or adjust the operating frequency.
  • Page 54 Resolution Horizontal frequency (kHz) Vertical frequency (Hz) 800 x 600 37.879 60.317 1024 x 768 48.363 1280 x 720 44.772 59.855 1366 x 768 47.7 1280 x 1024 63.981 60.02 1680 x 1050 65.29 59.954 1920 x 1080 67.5 3840 x 2160 67.5 Resolution Horizontal frequency (kHz)

  • Page 55: Licenses

    © DTS, Inc. All Rights Reserved. The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by LG Electronics Inc. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 56 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL Temporary noise is normal when SERIAL powering ON or OFF this device.
