OWNER'S MANUAL
LG LED Screen
Please read this manual carefully before install & operating your set and
retain it for future reference.
LAPA136-GF
www.lg.com
Copyright © 2025 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAPA136-GF and is the answer not in the manual?

Questions and answers

Summary of Contents for LG LAPA136-GF

  • Page 1 OWNER’S MANUAL LG LED Screen Please read this manual carefully before install & operating your set and retain it for future reference. LAPA136-GF www.lg.com Copyright © 2025 LG Electronics Inc. All Rights Reserved.
  • Page 2: Table Of Contents

    Table of ConTenTs safeTY PReCaUTIons ......3 MaKInG ConneCTIons ..... 37 - Precautions for the AC Adapter and Power ..4 TRoUblesHooTInG ......40 - Precautions for Moving the Product ...... 6 - Precautions for Installing the Product ....7 PRoDUCT sPeCIfICaTIons ....45 - Precautions for Cleaning the Product ....
  • Page 3: Safety Precautions

    WaRnInG - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. safeTY PReCaUTIons The Safety Precautions are intended to prevent unexpected danger or harm by helping the user to use the product safely and for its intended purpose.
  • Page 4: Precautions For The Ac Adapter And Power

    • Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord, make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized service center for a replacement.
  • Page 5 • If water or any foreign substance goes inside the product, disconnect the power cord immediately and contact the service center. - Otherwise, this may cause a fire or electric shock due to damage to the product. • Keep the power cord or AC adapter away from any heating devices. - The cord coating may melt and cause fire or electric shock.
  • Page 6: Precautions For Moving The Product

    Precautions for Moving the Product WaRnInG • Contact the service center before moving the product. - It may cause electric shock and damage the product. • Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved.
  • Page 7: Precautions For Installing The Product

    Precautions for Installing the Product WaRnInG • Contact the service center before installing the product. - It can cause electric shock and damage the product. • Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects near the product to prevent throwing things on the product screen.
  • Page 8 CaUTIon • Install the product where no Electromagnetic Interference occurs. • If you install the product in a place that does not meet the recommended conditions, this may cause serious damage to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing.
  • Page 9: Precautions For Cleaning The Product

    Precautions for Cleaning the Product WaRnInG • Keep the product clean at all times. - If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage. • When you need to clean the inside of the product, you must contact the service center. - Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product.
  • Page 10: Precautions For Using The Product

    Precautions for Using the Product WaRnInG • Do not use the product in any environment with excessively high temperatures or humidity. • If you use the product for a long period of time, take a rest from time to time to protect your vision. - Extended viewing could result in impaired vision.
  • Page 11 • Do not use high voltage electrical goods near the product (e.g., a bug zapper). - This may result in product malfunction if it receives an electrical shock. • If there is a gas leak, do not touch the outlet, and open the windows for ventilation. - Otherwise, the product may cause fire or electric shock.
  • Page 12: Precautions For Using The Remote Control

    Precautions for Using the Remote control WaRnInG • Avoid places with high humidity. - It may cause electrical shock or damage the product. • Do not expose batteries to excessive heat, such as direct sunlight, open fireplace, and electric heaters. - It may cause fire and you may be injured.
  • Page 13: Precautions For Experiencing Image Retention

    Precautions for experiencing Image Retention • Displaying a still image for a prolonged period of time may cause damage to the screen, resulting in image retention. Most third-party products have the same issue. The resulting damage is not covered by the product warranty.
  • Page 14: Preparation

    PRePaRaTIon Unpacking noTe • The pictures are schematic diagrams. Everything is subject to the in fact products. <flight case> <Carton packing>...
  • Page 15 1. Unpack the lDMs. Take the cartons out of the flight case or carton packing, then unpack the cartons. And cut the vacuum bag with scissors. Take ten LDMs from the carton. 10 pcs LDMs...
  • Page 16 2. Take Mounting plate and Cabinets out from the flight case. <Left & Right Cabinets> <Center Cabinet> 3. Unpack the mounting plate.
  • Page 17: Setting

    The introduction of laPa136-Gf screen interface and function Remote Controller Interface and Button Specifications • : Changes the input source. • : Accesses the main menus, or saves your input and exits the menus. • : Moves left and right.
  • Page 18: Remote Control

    Remote Control The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching terminals to the labels inside the compartment, and close the battery cover.
  • Page 19: Optional Accessories

    Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. lG one : Quick share <sC-00Da>...
  • Page 20: Assembly

    The panel is designed to be mounted to a fixed framework. The listing in Table 2.1 is the main components of a LAPA136-GF LED panel. The profile of the panel is shown in Figure 2.1.
  • Page 21 MainBoard,Key Board,Wi-Fi Board and Network Port Adapter Board. Please refer to the description for each board in the follow sections. LAPA136-GF LED display is combined with LDM and case. The LDMs and case are fixed by magnetic structure. 1. LDM 2.
  • Page 22 2.2 Major components of laPa136-Gf leD panel assembly...
  • Page 23: Mechanical Assembly

    Mechanical assembly <side view> <Rear view> <front View>...
  • Page 24 Display Module (lDM) The front face of the LAPA136-GF LED display is fitted with 100 light emitting diode (LED) dot LED modules known as LDMs. Each LDM is fitted with 20736 LEDs* plus associated drive electronics. Electrical connections (low voltage power, and digital data) are made to the rear of each LDM, from inside of the enclosure.
  • Page 25: Installation Guidelines

    The LAPA136-GF LED display is designed to be mounted on the stand (sold separately) or on the wall. When installing, it is important to ensure that the entire screen is correctly aligned, both vertically and horizontally.
  • Page 26: Mounting Plate Installation

    1) Mounting Plate Installation Wall mount piece list Item Photo Description Item Photo Description Left plate Right plate Vertical M6 x 60 connecting Expansion plate Screw KM4 x 8 screw step1. Install the left plate and right plate with connection plate. Use 12 pcs KM4X8 screw (item 5) to install the left plate (item 2) with right plate (item3).
  • Page 27 step2. Install the left and right plate Components with vertical connection plate. Use 8pcs KM4X8 screw (item 5) to install the left plate(item1)and right plate(item2) Compontents. step3. Double check the dimension after assembling. Install the mounting plate to the desired location and secure them with 24 pcs M8 x 80 explosion screws.
  • Page 28: Screen Installation

    2) screen Installation The two members jointly lifted the right screen component and placed it on the wall mount structure...
  • Page 29 Place the half screen component on the Wall Mount structure in order. noTe • The wall-mounted notch at the mark can be used for alignment.Be careful not to damage the connecting cable below when sliding the screen Place the left screen component on the bracket in order.
  • Page 30 You need to connect all the cables and install back all the LDMs. NETWORK CABLE (5 PCS(Right 3pcs, Left 2pcs)) Speaker CABLE AC CABLE (2PC) (2 PC) Please pay attention to the labels, eg. RJ45 cable labelled OUT1 is matched to the connector labelled OUT1.
  • Page 31 The cabinet is combined by sliding on the wall mount, we must make sure that the aluminum block is properly connected to the positioning. After the cabinet is joined, follow the instructions of Label to quickly fix the cabinet with the hexagonal plate.
  • Page 32 Install and tighten 4 pcs black M4 flat head screws to both top and bottom side of the case. 1 PCS M4 screw 1 PCS M4 screw Before install screws Install back screws 1 PCS M4 screw 1 PCS M4 screw Install M4 screws.
  • Page 33 All the LDMs (LED Panel) have labels stuck on the back side. Please follow below number to install back the LDMs. front view...
  • Page 34 Mount lDM Step1. Wear anti-static gloves, then take out a LDM, please pay attention to the arrow direction on the back side of it. Step2. Flatten the LDM. noTe • When mounting an LDM back, pay more attention to the guide pin which is located in corners to mount it smoothly.
  • Page 35: Electrical

    The power distribution system used must provide adequate protection against excess line current and leakage currents to earth. electrical Characteristics for one laPa136-Gf at 100V aC Input at 240 V aC Input Rating Rating Parameter Unit Parameter Unit normal...
  • Page 36: Power Cable Wiring

    Power Cable Wiring aC Power An approved three-pole appliance coupler inside the panel connects to the AC supply. The AC power cable is then connected to the EMI filter and distributes to the power supply units. Each panel has an earth point for grounding.
  • Page 37: Making Connections

    MaKInG ConneCTIons You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device. Connecting to a PC Some of the cables are not provided.
  • Page 38 noTe • For the best image quality, using the monitor with HDMI connection is recommended. • To comply with the specifications of the product, use a shielded interface cable with ferrite core, such as a HDMI cable. • If you turn the monitor on when the set is cold, the screen may flicker. This is normal. •...
  • Page 39: Using The Input List

    Using the Input list (HoMe) HDMI1 HDMI2 HDMI3 DISPLAYPORT Connecting cables Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product. You can turn the product on/off, select an input source and adjust the OSD menu from your PC.
  • Page 40: Troubleshooting

    TRoUblesHooTInG no image is displayed. • Is the power cord connected to the product? - Check if the power cord is correctly plugged into the power outlet. • Did you install the driver? - Check if the function is supported by referring to the graphics card user manual. Issues Related to screen •...
  • Page 41 network connection problems • If the main network line to the last abnormal module is not bright, the main network line is connected abnormally, and the abnormal module outputs an abnormal network line. Inspection: Recheck the state of the network cable in the corresponding position to confirm that the connection is OK.
  • Page 42 lDM problems • The abnormal module position of LDM is abnormal. Inspection: Replace the LDM in the corresponding position. • You can replace it with the following procedure. Power off the panel and unplug the power cable; Locate the problem LDM; Dismount the problem LDM from the panel.
  • Page 43 The adapter board problems • The abnormal module position of LDM is not bright, the state of the adapter board in the corresponding position is work abnormally. Inspection: Replace the adapter board in the corresponding position. The receiver board problems •...
  • Page 44 The calibration data is abnormal • Some LDMs are particularly bright when the screen is white, unlike others. Inspection: Switch calibration off again, then switch to calibration on to confirm the existence of calibration data. You can also switch LDMs data and receiver card data to confirm that the calibration data exists and is correct.
  • Page 45: Product Specifications

    PRoDUCT sPeCIfICaTIons The product specifications below may be changed without prior notice due to upgrade of product functions. “ ” refers to alternating current (AC), and “ ” refers to direct current (DC). Pixel pitch (distance between pixels) 1.5625 mm (0.0615 inches) Typ.
  • Page 46 Crestron Connected Power Mgmt. On/Off Schedule Holiday Schedule LG ConnectedCare SuperSign CMS Software Compatibility LG Assistant SuperSign Software & Manual Downloading from the LG Electronics website. Visit the LG Electronics website http://partner.lge.com and download the latest software for your model.
  • Page 47 Wireless module (lGsbWaC72) specifications Wireless lan (Ieee 802.11a/b/g/n/ac) frequency range (MHz) output power (Max.) (dbm) 2400 to 2483.5 5150 to 5725 16.5 5725 to 5850 (Not for EU) 11.5 • As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional frequency table.
  • Page 48: Supplier's Declaration Of Conformity

    20 cm (7.8 inches) between the device and the body. • FCC ID: BEJLGSBWAC72 / IC: 2703H-LGSBWAC72 (USA Only) supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs NJ 07632 E-mail lg.environmental@lge.com...
  • Page 49 HDMI/ DisplayPort (PC) support mode Resolution Horizontal frequency (kHz) Vertical frequency (Hz) 800 x 600 37.879 60.317 1024 x 768 48.363 1280 x 720 44.772 59.855 1366 x 768 47.7 1280 x 1024 63.981 60.02 1680 x 1050 65.29 59.954 1920 x 1080 67.5 3840 x 2160...
  • Page 50: Licenses

    Supported licenses may differ by model. For more information of the licenses, visit www.lg.com . The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
  • Page 51 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL Temporary noise is normal when powering ON or OFF this device. SERIAL NO.
