- Page 1 OWNER’S MANUAL (LED SCREEN) Please read the safety information carefully before using this product. After reading this manual, keep it in an easily accessible location for future reference. LSAL006-G2L LSAL006-G2R www.lg.com Copyright © 2023 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS .....3 - Precautions for the AC Adapter and Power................. 4 - Precautions for Moving the Product ....6 - Precautions for Installing the Product ..... 7 - Precautions for Cleaning the Product ..... 9 - Precautions for Using the Product ....10 - Product Disposal ............ -
Page 3: Safety Precautions
SAFETY PRECAUTIONS The safety precautions are intended to prevent unexpected danger or harm by helping the user to use the product safely and for its intended purpose. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death. CAUTION If you ignore the caution message, you may be slightly injured or the product may be damaged. -
Page 4: Precautions For The Ac Adapter And Power
• Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord, make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized service center for a replacement. - Page 5 • If water or any foreign substance goes inside the product, disconnect the power cord immediately and contact the service center. - Otherwise, this may cause a fire or electric shock due to damage to the product. • Keep the power cord or AC adapter away from any heating devices. - The cord coating may melt and cause fire or electric shock.
-
Page 6: Precautions For Moving The Product
Precautions for Moving the Product WARNING • Contact the service center before moving the product. - It may cause electric shock and damage the product. • Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved. - You may be electrocuted or the product can be damaged. -
Page 7: Precautions For Installing The Product
Precautions for Installing the Product WARNING • Contact the service center before installing the product. - It can cause electric shock and damage the product. • Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects near the product to prevent throwing things on the product screen. - Page 8 CAUTION • Install the product where no Electromagnetic Interference occurs. • If you install the product in a place that does not meet the recommended conditions, this may cause serious damage to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing. Please do not install the product in places such as where there is an abundance of fine dust or oil mist, chemical substances are used, exposed to direct sunlight, the temperature is very high or low, the humidity is very high.
-
Page 9: Precautions For Cleaning The Product
Precautions for Cleaning the Product WARNING • Keep the product clean at all times. - If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage. • When you need to clean the inside of the product, you must contact the service center. - Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product. -
Page 10: Precautions For Using The Product
Precautions for Using the Product WARNING • Do not use the product in any environment with excessively high temperatures or humidity. - It may cause electrical shock or damage the product. • If you use the product for a long period of time, take a rest from time to time to protect your vision. - Extended viewing could result in impaired vision. -
Page 11: Product Disposal
• Do not use high voltage electrical goods near the product (e.g., a bug zapper). - This may result in product malfunction if it receives an electrical shock. • If there is a gas leak, do not touch the outlet, and open the windows for ventilation. - Otherwise, the product may cause fire or electric shock. -
Page 12: Assembling And Preparing
ASSEMBLING AND PREPARING CAUTION • Always use genuine components to ensure safety and durability of the product. • The product warranty will not cover damage or injury caused by the use of unauthorized components. NOTE • The accessories provided with your product may vary depending on the model or region. •... - Page 13 MSAL-0062 MSAL-0062 NOTE • Essential accessories are only available for some models. If necessary, please purchase them separately.
-
Page 14: Optional Accessories
Optional Accessories Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. Wall Mount WM-L118R Stand ST-1180R... -
Page 15: Handling For Protecting Led Package Screen
Handling for Protecting LED Package Screen When removing the package, be careful not to damage the front. When taking out the product with a exclusive jig, be careful not to damage the front. - Page 16 CAUTION If the product is tilted towards the LED package screen, the bottom of the product may be damaged. LED Package Screen If the product is tilted towards the edge of the LED package screen, the bottom (corner) of the product may be damaged.
-
Page 17: Installation Precautions Guide
Installation Precautions Guide Temperature • Make a cooling system for the enclosure so that the operating temperature of the product can be maintained. - Product operating temperature: 0 °C to 40 °C (32 °F to 104 °F) (the recommended room temperature is below 25 °C (77 °F).) • Install in a location where the warm air from an air conditioner does not directly affect the product. - This will prevent malfunctions such as the screen turning off. - Page 18 Installation Position • Ensure the distance from the ceiling of the installation room to the product is at least 400 mm (15.7 inches). - The high temperature air collected at the ceiling will naturally circulate to prevent malfunction. • Ensure the distance from the floor of the installation room to the product is at least 100 mm (3.9 inches). - The air from the floor will easily circulate to the ceiling to prevent malfunctions. 400 mm (15.7 inches) or more 100 mm (3.9 inches) or more...
-
Page 19: Installation Location
Installation Location Installing on a Recessed Wall • After installation on a recessed wall, a bezel can be installed for interior purposes. A : 20 mm (0.7 inches) or more B : 50 mm (1.9 inches) or more C : 300 mm (11.8 inches) or more D : 50 mm (1.9 inches)or more When Installing the Bezel • Ensure it can be detached for product repair. • For the top / bottom bezels, secure at least 60 % of the air vent to facilitate air circulation. - Page 20 Installing on a Wall A : 20 mm (0.7 inches) or more B : 50 mm (1.9 inches) or more C : 300 mm (11.8 inches) or more D : 50 mm (1.9 inches)or more...
-
Page 21: Buttons And Terminal
Buttons and Terminal LSAL006-G2L+G2R You can simply operate the functions, using the button. Basic functions Power On (Press) Power Off (Press and Hold) Menu Control (Press Menu Selection (Press and Hold 1) All running apps will close. 2) You can access and adjust the menu by pressing the button when LED screen is on. 3) You can use the function when you access menu control. - Page 22 IR & LIGHT SENSOR IR signal input and illumination can be detected. NOTE • For LSAL006-G2L the IR sensor is provided. • For MSAL-0062 the remote control is provided.
-
Page 23: Troubleshooting
TROUBLESHOOTING No image is displayed. • Is the power cord connected to the product? - Check if the power cord is correctly plugged into the power outlet. • Is the ‘No Signal’ message displayed? - There is no connection between MSAL-0062 and the input source. Check the connection status of the LAN cable. - Access the Input menu to check the input source. - Page 24 The display color is abnormal. • Screen has poor color resolution (16 colors). - Refer to the manual of MSAL-0062. • The screen color is unstable or looks black and white. - Refer to the manual of MSAL-0062. • Does a black dot appear on the screen? - The few pixels (red, green, blue, white and black) that appear on the screen are due to the inherent characteristics of the LED surface.
-
Page 25: Product Specifications
PRODUCT SPECIFICATIONS Without prior notice, the product specifications are subject to change to enhance the functionality of the product. symbol means alternating current, and the symbol means direct current. LSAL006-G2L / LSAL006-G2R Pixel pitch (distance between pixels) 0.68 mm Resolution 1,920 x 2,160 Pixel density 2,162,630 pixels/m Number of pixels per screen... - Page 26 [Unit: mm (inches)] LSAL006-G2L LSAL006-G2R 1307.6 (51.4) 1307.6 (51.4) 41 (1.6) 1472.8 (57.9) 2615.2 (102.9) 99 (3.8)
- Page 27 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL Temporary noise is normal when powering ON or OFF this device.
