- Page 1 REMOTE CONTROLLER MANUAL MODEL RAR-M0A9 Instruction manual Page 1~26 To obtain the best performance, please read this instruction manual completely. คู ่ ม ื อ การใช ้ ง าน หน ้า 27~54 เพื อได ้รั บ การทํ า งานที ดี ท ี สุ ด โปรดอ่ า นคู ่ ม ื อ อย่ า งละเอี ย ด <...
- Page 2 NAMES AND FUNCTIONS OF REMOTE CONTROL UNIT REMOTE CONTROLLER This controls the operation of the indoor unit. Signal range to reach indoor unit is about 7 meters. If inverter lamp is used, the range of control may be shorter. This unit can be fi xed on a wall using the fi xture provided. Before fi xing it, make sure the indoor unit can be controlled from the remote controller.
-
Page 3: Cooling Operation
COOLING OPERATION Use the device for cooling when the outdoor temperature is 21 ~ 46°C. If indoors humidity is very high (over 80%), some dew may form on the air outlet grille of the indoor unit. Press the selector button so that the display indicates (COOL). -
Page 4: Silent Operation
SILENT OPERATION During Cooling mode, press the selector button so that the display indicates (SILENT) along with the (COOL) symbol. Silent operation starts with a beep. The FAN SPEED will be automatically changed to SILENT. CANCELLATION of SILENT Operation Operation mode after cancel Cancel Condition Key press Stop operation... -
Page 5: Dehumidifying Operation
DEHUMIDIFYING OPERATION Use the device for dehumidifying when the room temperature is over 16°C. When it is under 15°C, the dehumidifying function will not work. Press the selector button so that the display indicates (DEHUMIDIFY). The FAN SPEED is set at SILENT or LOW automatically. The FAN SPEED button can be used to change between SILENT and LOW only. -
Page 6: Fan Operation
FAN OPERATION In Fan operation mode the device is function as an air circulator. Press the selector button so that the display indicates (FAN). Set the desired FAN SPEED with the button. (the display indicates the selectable setting). (HI) : High fan speed. (MED) : Medium fan speed. - Page 7 ONE-TOUCH POWERFUL MODE Press the button. Operation start with a signal received sound “beep”. ● Unit will be forced operate in (COOL) mode for ● 20 minutes. Indicator appear during this period. After 20 minutes, indicator will disappear while unit ●...
- Page 8 HOW TO SET THE AIR SLEEP TIMER Press the button, and the display changes as shown below. Mode Indication Air Sleep Timer Air Sleep Timer Air Sleep Timer: The device will continue working for the designated number of hours and then turn off. Point the signal window of the remote controller toward the indoor unit, and press the AIR SLEEP TIMER button.
- Page 9 REFRESH MODE OPERATION To slightly reduce air blow temperature of air conditioner and room humidity if unit has been operating for a long period of time for the day. (a) During COOLING or SILENT operation, press the to allow unit to start REFRESH operation.
-
Page 10: How To Set The Timer
HOW TO SET THE TIMER ■ ON Timer and OFF Timer are available. OFF Timer Reservation ■ Operation stop at setting time OFF TIMER setting Select the OFF TIMER by pressing the (OFF ● TIMER) Button. Setting time will change according to the below sequence ●... - Page 11 AIR FLOW LOUVERS ADJUSTMENTS Adjustment of the conditioned air in the upward and downward directions. The horizontal air defl ector is automatically set to the proper angle suitable for each operation. The defl ector can be swung up and down continuously and also set to the desired angle using the “...
- Page 12 FROST WASH OPERATION (GENERAL INFORMATION) Cleaning function by frosting the indoor exchanger and allowing melted water to wash away dust particles collected on surface of exchanger. This function only applicable during OFF mode. Note ● Operate FROST WASH when under the following conditions Outdoor temperature 21°C ~ 43°C Indoor temperature...
- Page 13 HOW TO EXCHANGE THE BATTERIES IN THE REMOTE CONTROLLER When using the remote control, if there is no response from the air conditioner unit and or the remote control has fading and dim displays, the batteries in the remote control device need to be removed and replaced with new ones Remove the cover as shown in the fi...
