Owner's Manual
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
24U631A
27U631A
32U631A
www.lg.com
Copyright
2024 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 27U631A and is the answer not in the manual?

Questions and answers

Related Manuals for LG 27U631A

Summary of Contents for LG 27U631A

  • Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 24U631A 27U631A 32U631A www.lg.com Copyright 2024 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS ASSEMBLING AND PREPARING ............4 USING THE MONITOR ............... 11 - Installing ..........................5 - Connecting to a PC ......................12 Moving and Lifting the Monitor ..................5 HDMI Connection ......................12 Installing on a Table ......................6 USB-C Device connection ....................12 - Connecting AV Devices .....................13 Using the Kensington Lock ....................6 HDMI Connection ......................13...
  • Page 3 USER SETTINGS ................14 PRODUCT SPECIFICATION ..............19 - Activating the Main Menu ....................14 - Support Mode ........................21 Main Menu Features ......................14 (Preset Mode, HDMI) ......................21 Menu Settings ........................15 (Preset Mode, USB-C) .......................22 [Quick Settings] ........................15 HDMI Timing (Video) ......................23 [Input]..........................16 TROUBLESHOOTING ................

  • Page 4: Assembling And Preparing

    • To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer • Always use genuine LG components to ensure safety and product performance. from which you purchased the product. • The product warranty will not cover damage or injury caused by the use of unauthorized components.

  • Page 5: Installing

    Installing CAUTION • Avoid touching the monitor screen as much as possible. Moving and Lifting the Monitor - This may result in damage to the screen or some of the pixels used to create images. When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size.

  • Page 6: Installing On A Table

    Installing on a Table Using the Kensington Lock • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website (3.9 inches) away from the wall to ensure sufficient ventilation.

  • Page 7: Installing On The Wall

    Installing on the Wall Installing the Wall Mount Plate To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.
  • Page 8 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could • lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. The wall mounting bracket is optional. You can obtain optional accessories from your local dealer.

  • Page 9: Product Description

    Product Description : Wall Mount Plate A: Joystick Button : Back of the Monitor : Standard screw : Max. 8 mm (0.3 inches)

  • Page 10: How To Use The Joystick Button

    How to Use the Joystick Button Adjusting the Angle You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ Place the monitor mounted on the stand base in an upright position. down with your finger. Adjust the angle of the screen.

  • Page 11: Supported Software

    Press the joystick button, go to [Settings] > [Input], and then select the input option. CAUTION • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Do not press the screen for a prolonged time. This may cause image distortion.

  • Page 12: Connecting To A Pc

    Connecting to a PC USB-C Device connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the Plug and Play* feature. NOTE * Plug and Play: A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers.

  • Page 13: Connecting Av Devices

    Connecting AV Devices Connecting Peripherals HDMI Connection Headphones Connection HDMI transmits digital video and audio signals from your AV device to the monitor. Connect peripherals to the monitor via the headphones port. NOTE NOTE • • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. Peripheral devices are sold separately.

  • Page 14: User Settings

    USER SETTINGS Main Menu Features NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • When [Beep Guide] is activated, pressing the joystick button will take you to [Settings] right away. Activating the Main Menu Press the joystick button on the back of the monitor.

  • Page 15: Menu Settings

    Menu Settings [Quick Settings] [Settings] > [Quick Settings] To view the OSD menu, press the joystick button at the back of the monitor and then enter the [Settings]. • [Brightness]: Adjusts the brightness of the screen. Move the joystick up/down and left/right to set the options. •...

  • Page 16: [Input]

    [Input] [Picture] [Settings] > [Input] [Settings] > [Picture] > [Picture Mode] • [Input List]: Selects the input mode. • [Custom]: Allows the user to adjust each element. • • [Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide], and [Vivid]: Heightens contrast, brightness and sharpness to display vivid images.
  • Page 17 [Settings] > [Picture] > [Picture Adjust] [Settings] > [Picture] > [Game Adjust] • • [Brightness]: Adjusts the brightness of the screen. [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is •...

  • Page 18: [General]

    [General] [Settings] > [Picture] > [Color Adjust] • [Gamma] [Settings] > [General] - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the • [Language]: Sets the menu screen to the desired language. lower the gamma value, the lighter the image becomes.

  • Page 19: Product Specification

    PRODUCT SPECIFICATION AC/DC Adaptor 24U631A / 27U631A • Specifications are subject to change without notice. Model : MS-V2530R190-048L0-DE MS-V2530R190-048L0-US The symbol means alternating current, and the symbol means direct current. Manufacturer: JAMA Technology (HongKong) Co., Ltd - Input: 100-240 V~ 50/60 Hz, 1.5 A Color Depth: - Output: 19 V ...
  • Page 20 24U631A • • With Stand: 539.4 x 215 x 413.6 (21.2 x 8.4 x 16.2) With Stand: 3.6 (7.9) • • Without Stand: 539.4 x 45.7 x 321.3 (21.2 x 1.7 x 12.6) Without Stand: 2.8 (6.1) 27U631A 27U631A • • With Stand: 613.2 x 215 x 454.8 (24.1 x 8.4 x 17.9) With Stand: 4.4 (9.7) • • Without Stand: 613.2 x 43.7 x 362.5 (24.1 x 1.7 x 14.2) Without Stand: 3.6 (7.9)

  • Page 21: Support Mode

    Support Mode (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 45.000 60.000 1920 x 1080 67.500 60.000 Recommended Timing 2560 x 1440 88.787...

  • Page 22: (Preset Mode, Usb-C)

    (Preset Mode, USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 45.000 60.000 1920 x 1080 67.500 60.000 Recommended Timing 2560 x 1440 88.787 59.951...

  • Page 23: Hdmi Timing (Video)

    HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 720P 45.0 1080P 67.5...

  • Page 24: Troubleshooting

    • Have you installed the display driver? - Be sure to install the display driver from our web site: https://www.lg.com. Please refer to the list below if you experience any of the following issues during product use. - Make sure to check if the graphics card supports Plug and Play function.
  • Page 25 The display color is abnormal. Some features are disabled. • • Does the display appear discolored (16 colors)? Are some functions not available when you press the Menu button? - Set the color to 24 bit (true color) or higher. (The settings may differ depending on the operating system - The OSD is locked.

  • Page 26: License

    LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. USB Type-C ®...

  • Page 27: Beep Guide

    BEEP GUIDE Menu Location Menu Location Picture - Picture Mode - Vivid 3 1 2 Picture - Game Adjust - Response Time - Normal 3 3 1 3 Picture - Picture Mode - HDR Effect 3 1 3 Picture - Game Adjust - Response Time - Off 3 3 1 4 Menu Location...
  • Page 28 Menu Location Menu Location Menu Location Picture - Color Adjust - Six Color - Green_Saturation 3 4 6 4 General - Language - Swedish 4 1 6 General - Information Picture - Color Adjust - Six Color - Green_Saturation 3 4 6 4 1 Slider General - Language - Finnish 4 1 7 General - Information...

  • Page 29: Limited Warranty (Usa)

    LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632. If there is a conflict between the AAA Rules and the rules set forth in this section, the rules set...
  • Page 30 Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand for arbitration, LG will promptly pay all arbitration filing fees to the AAA unless you seek more than $25,000 in damages,...

  • Page 31: Limited Warranty (Canada)

    Notice of Dispute.
  • Page 32 Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during the 30 day period after LG’ s receipt of the Notice of Dispute, you and LG agree to resolve any claims between you and LG...
  • Page 33 Opt Out. The arbitration provision requires you and LG to resolve disputes by binding arbitration instead of court, unless the laws of your province or territory do not permit that, or, in other jurisdictions, if you choose to opt out.
  • Page 34 The model and serial number of the product are located on the back and on one side Trade Name of the product. Responsible LG Electronics USA, Inc. Record them below in case you ever need service. Party Address 111 Sylvan Avenue, North...

  • Page 35: Important Precautions

    » If loosely connected, the poor connection may cause a fire or electric shock. Be sure to use power cords and AC adapters provided or approved by LG Electronics, Inc. » The use of non-approved products may cause a fire or electric shock.

  • Page 36: Precautions In Installing The Product

    » If you continue to use without taking proper measures, electrical shock or fire can occur. If you dropped the product or the case is broken, turn off the product and unplug the power cord. » If you continue to use without taking proper measures, electrical shock or fire can occur. Contact LG Customer Service.

  • Page 37: Precautions In Moving The Product

    Do not attempt to disassemble, repair or modify the product yourself. » Fire or electric shock can occur. » Contact LG Customer Service for repair. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.

  • Page 38: Précautions Importantes

    Assurez-vous d’enfoncer complètement la fiche du cordon dans l’adaptateur c.a. » Un branchement desserré pourrait causer un incendie ou une décharge électrique. Assurez-vous d’utiliser les cordons d’alimentation et adaptateurs c.a. fournis ou approuvés par LG Electronics, Inc. » L’utilisation de produits non approuvés pourrait entraîner un incendie ou une décharge électrique.
  • Page 39 Si une odeur de fumée ou toute autre odeur se dégage du moniteur ou si vous entendez un son étrange en provenance du moniteur, débranchez le cordon d’alimentation et contactez le service à la clientèle de LG. » Si vous continuez à utiliser l’appareil sans prendre de mesures appropriées, il y a un risque de décharge électrique ou d’incendie.
  • Page 40 Ne tentez pas de désassembler, de réparer ou de modifier l’appareil vous-même. » Il existe un risque d’incendie ou de décharge électrique. » Contactez le service à la clientèle de LG pour le faire réparer. Pour nettoyer l’appareil, débranchez le cordon d’alimentation et frottez doucement avec un chiffon doux pour prévenir toute éraflure.
  • Page 41 DDC(Display Data Channel) ENGLISH DEUTSCH DDC (Display Data Channel) DDC (Display Data Channel) DDC ist ein Kommunikationskanal, über DDC is a communication channel over which weiche Sie von lhrem Monitor automatisch the monitor automatically informs the host über das verbundene System (PC) und seine system (PC) about its capabilities.
  • Page 42 DDC(Display Data Channel) FRANÇAIS ITALIANO DDC (Display Data Channel) DDC (Display Data Channel) DDC est une chaine de communication par Il DDC è un canale di comunicazione attraverso le biais de laquelle le moniteur prévient il quale il monitor informa automaticamente il automatiquement le systéme central (PC) de sistema ospite (PC) circa le proprie capacità.
  • Page 43 DDC(Display Data Channel) ESPAÑOL PORTUGUÊS DDC (Canal de despliegue de DDC (Display Data Channel) información) DDC es un canal de comunicacion sobre el DDC é um canal de comunicação através cual el monitor automáticamente informa al do qual o monitor informa ao computador sistema anfitrión (PC) sobre sus capacidades.
  • Page 44 DDC(Display Data Channel) NEDERLANDS РУССКИЙ DDC (Display Data Channel) Канал обмена данных между монитором и компьютером DDC. DDC is een communicatiekanaal waarmee de DDC-канал связи, по которому монитор monitor het hostsysteem (PC) automatisch автоматически информирует компьютер о informeert over zijn mogelijkheden. своих...
  • Page 45 DDC(Display Data Channel) 日本語 한국어 DDC( 디스플레이 데이터 채널 ) DDC（ディスプレイ • データ • チャンネル） DDC 는 모니터의 기능에 관한 정보를 자동으로 호스 DDC は、 モニターがその状態をホスト • システム （Ｐ Ｃ）へ自動的に通知する通信チャンネルです。 트 시스템 (PC) 에 제공하는 통신 채널입니다 DDC protocol DDC プロトコル ①...
  • Page 46 DDC(Display Data Channel) CATALÀ ‫العربية‬ DDC (Canal de Dades de (‫ )قناة بيانات الشاشة‬DDC Pantalla) ‫ هي قناة تواصل ت ُ علم الشاشة من خاللها النظام المضيف‬DDC .‫)الكمبيوتر( تلقائي ا ً حول قدراتها‬ DDC és un canal de comunicació a través del DDC ‫بروتوكول‬...

  • Page 47: Energy Saving Design

    Energy Saving Design ENGLISH PORTUGUÊS Energy Saving Design Programa de economia de energia This program is designed to have computer equipment manufacturers build circuitry into their Este programa foi elaborado com a finalidade de products to reduce power consumption when it is estimular os fabricantes de equipamentos para not in operation.
  • Page 48 Energy Saving Design DEUTSCH 한국어 Energiespar-Design 절전디자인 Dieses Programm wurde konzipiert, um die 이 프로그램은 컴퓨터 장비 제조업체가 해당 제품에 회로를 Hersteller von Computergeräten zu veranlassen, 내장하여 , 사용하지 않는 기간에 전력 소비를 줄일 수 있도 록 만들어졌습니다. Schaltungen in ihre Produkte einzubauen, die zu einem geringeren Stromverbrauch führen, wenn 이...

  • Page 49: Bahasa Indonesia

    Energy Saving Design MAGYAR BAHASA INDONESIA Energiatakarékos kialakítás Desain Hemat Energi E program célja, hogy a számítógéptartozékgyártók Program ini dirancang agar produsen peralatan azon termékei, amelyek rendelkeznek az ehhez komputer membangun sistem sirkuit ke dalam szükséges áramkörrel, alacsony fogyasztással produk mereka untuk mengurangi konsumsi daya üzemeljenek akkor, amikor nincsenek saat peralatan sedang tidak beroperasi.
  • Page 50 Energy Saving Design ESPAÑOL 日本語 Diseño de ahorro de energía 省エネ設計 （省エネルギー設計、節電設計） Este programa está diseñado para que los fabricantes de equipos informáticos incorporen 本プログラムはコンピュータ機器メーカーが製造する sistemas de circuitos a sus productos con el fin 製品がその非使用時 ( 非動作時 ) は消費電力を抑 de reducir el consumo de energía cuando no esté える回路構成を持つことを目的に策定されま...
  • Page 51 Energy Saving Design ҚАЗАҚША NEDERLANDS Энергия үнемдейтін дизайн Energiebesparend ontwerp Бұл бағдарлама компьютер жабдықтарын Dit programma stimuleert fabrikanten van өндірушілерге жұмыс істемей тұрғанда, қуаттың computerapparatuur om schakelingen in producten тұтынылуын азайту мақсатымен өнімдеріне te bouwen die het stroomverbruik verminderen als электр...
  • Page 52 Energy Saving Design FRANÇAIS ΕΛΛΗΝΙΚΆ Design d’économie d’énergie Σχεδίαση εξοικονόμησης ενέργειας Ce programme est conçu pour obtenir l’installation Το πρόγραμμα αυτό έχει σχεδιαστεί ώστε οι de circuits par les fabricants d’équipements κατασκευαστές εξοπλισμού ηλεκτρονικών informatiques dans leurs produits afin de réduire υπολογιστών...
  • Page 53 Energy Saving Design ITALIANO РУССКИЙ Programma di risparmio Функция сохранения энергии energetico Эта программа разработана для создания и внедрения производителями компьютерного Questo programma è stato messo a punto affinché оборудования схем, позволяющих снизить i produttori di computer producano circuiti per i loro потребление...

  • Page 54: Oszczędzanie Energii

    Energy Saving Design POLSKI 繁體中文 Oszczędzanie energii 節能設計 Ten program został stworzony, aby producenci 此程式用於幫助電腦設備製造廠商在他們的產品中 sprzętu komputerowego mieli możliwość 建立電路，藉此降低產品處於非作業狀態時的功率 wbudowania do swoich produktów zespołów 消耗量。 obwodów elektrycznych redukujących pobór mocy w stanie bezczynności. 本顯示器與已安裝符合VESA 顯示能源管理訊號 (DPMS) 協定之螢幕抑制顯示軟體的電腦配合使用 W przypadku użycia tego monitora na komputerze 時，可降低處於非作業狀態時的功率消耗量，進而...
  • Page 55 Energy Saving Design ‫العربية‬ CATALÀ ‫تصميم موفر للطاقة‬ Disseny d’estalvi d’energia Aquest programa està dissenyat perquè els ‫تم إعداد هذا البرنامج بحيث تتمكن شركات تصنيع أجهزة الكمبيوتر من‬ ‫إدماج مجموعة دارات إلكترونية في منتجاتها للحد من استهالك الطاقة‬ fabricants d’equips informàtics integrin circuits als .‫عند...
  • Page 56 Service DEUTSCH ENGLISH Service Wartun Bei folgenden Fehlerbedingungen ist der Unplug the monitor from the wall outlet and Netzstecker des Monitors zu ziehen und der refer servicing to qualified service personnel Kundendienst zu benachrichtigen: when : Wenn der Netzstecker beschadigt oder das The power cord or plug is damaged or Netzkabel ausgefranst ist.

  • Page 57: Manutenzione

    Service ITALIANO FRANÇAIS Manutenzione Maintenance du Moniteur Débranchez le moniteur (prise murale) Staccare il monitor dalla presa elettrica et contactez un technicien qualifié de e consultare il personale addetto alla maintenance de ce type d’équipement dans manutenzione quando: les cas suivants: Il cavo elettrico o la spina sono danneggiati Le cordon d’alimentation ou la prise est o consumati.
  • Page 58 Service ESPAÑOL PORTUGUÊS Servicio Manutenção Desconecte el monitor del tomacorriente de Desligue o monitor da tomada e procure por la pared y refiera el servicio a personal de serviço autorizado, quando: servicio calificado cuando: O cabo de força ou plugue estiver danificado El cable o enchufe de energía está...
  • Page 59 Service NEDERLANDS РУССКИЙ Onderhoud Ремонт и Обслуживание In de volgende gevallen haalt u de stekker van В нижеперечисленных случаях отключите de monitor uit het stopcontact en roept u de монитор от сети и обратитесь в пункты hulp in van een gekwalificeerde technicus: сервисного...
  • Page 60 Service ‫العربية‬ ‫الخدمة‬ Maintenance Tel :‫افصل الشاشة عن مأخذ الحائط واتصل بفريق خدمة محترف‬ Dammam 8339561 . ٍ ‫إن سلك الطاقة أو المقبس تالف أو با ل‬ • .‫انسكب سائل على الشاشة‬ • Khobar 8942694 .‫تعرضت الشاشة للمطر أو الماء‬ •...
  • Page 61 Service 日本語 한국어 保守および修理 수리 次のような保守になったら、モニタ－の電源プラグ 다음과 같은 경우에는 벽면 콘센트에서 모니터의 플러그 をコンセントから抜き、修理センターにご相談くださ 를 뺀 다음 자격이 있는 수리 담당자에게 의뢰하십시오 . い。 전원코드 또는 플러그가 손상되거나 낡았습니다 . 電源コードまたはプラグが破損した、または擦り 액체가 엎질러져서 모니터에 흘러들어갔습니다 . 모니터가 비 또는 물에 노출되었습니다 . 切れた。...
  • Page 62 Service CATALÀ Servei Desconnecteu el monitor de l’endoll de paret i consulteu al personal de servei qualificat si: El cable o l’endoll estan danyats o esfilagarsats. Ha caigut líquid al monitor. El monitor s’ha vist exposat a la pluja o l’aigua. El monitor no funciona amb normalitat seguint les instruccions d’ús.
