LG Digital Signage
SERVICE MANUAL
CHASSIS :
MODEL :
CAUTION
BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL71897270 (2410-REV01)
Any reproduction, duplication, distribution (including by way of email, facsimile or other electronic means),
publication, modification, copying or transmission of this Service Manual is STRICTLY PROHIBITED unless you
have obtained the prior written consent of the LG Electronics entity from which you received this Service Manual.
The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service
Manual.
Copyright © 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
UWC7B
65UH5N
65UV5N
65UH5N-EP
65UV5N-EP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65UH5N and is the answer not in the manual?

Questions and answers

Related Manuals for LG 65UH5N

Summary of Contents for LG 65UH5N

  • Page 1 Service Manual is STRICTLY PROHIBITED unless you have obtained the prior written consent of the LG Electronics entity from which you received this Service Manual. The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service Manual.
  • Page 2 SERVICING PRECAUTIONS ..............5 SPECIFICATION ..................7 SOFTWARE UPDATE ................11 BLOCK DIAGRAM .................. 13 EXPLODED VIEW .................. 14 TROUBLE SHOOTING GUIDE ..........APPENDIX - 2 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 3 (Cleaning with a dirty or rough cloth may damage the panel.) CAUTION Please use only a plastic screwdriver to protect yourself from shock hazard during service operation. - 3 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 4 Mettre au rebut les batteries usagées conformément aux instructions du fabricant. VOrSIChT Explosionsgefahr bei unsachgemäßem Austausch der Batterie Entsorgung gebrauchter Batterien nach Anleitung - 4 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 5: Servicing Precautions

    Alternatively, obtain and wear a commercially available discharging wrist strap device, which should be removed to prevent potential shock reasons prior to applying power to the - 5 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 6 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. 3. Solder the connections. - 6 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 7: Application Range

    Brightness sensor CM3232 (Detect changes in ambient light and adjust its brightness automatically) rJ45, 100Base-T(100Mbps) only SuperSign CMS / Super- Sign Control / SuperSign Control+ - 7 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 8 All Inputs 30 - 136 khz ultra Deep Color On(6G) hDMI1/2/3, DP Vertical frequency 58 - 62 hz hDMI, DP Synchronization Separate Sync, Digital - 8 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 9 62368-1 Signal 3000Vac/1sec or 4242Vdc/1sec Current 100mA(AC) / 10mA(DC) Tilt(facedown) 30° °(de- in conditions within 30ºC gree) temperature, 50% humidity, 75"/86" tilt unsupported - 9 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 10 1080P 60hz 1080/60P 67.5 uD 2160P 30hz 2160/30P hDMI1/2/3, DP 112.5 uD 2160P 50hz 2160/50P hDMI1/2/3, DP uD 2160P 60hz 2160/60P hDMI1/2/3, DP - 10 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 11: Usb Download

    3) Connect the uSB device to the uSB port on the Signage. 4) Push menu button, enter ‘All Settings’ menu. Go to ‘General’ menu. - 11 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 12 5) Press number “7” seven times. 6) Enter Ext.Micom urSA. Press ‘uPDATE’ 7) Finish - 12 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 13: Block Diagram

    BLOCK DIAGRAM - 13 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 14: Exploded View

    It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, fire, or other hazards. Do not modify the original design without permission of manufacturer. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 15 * SVC Part List 서비스 자재 리스트 Part No Part Name EAV65062301 LED Array LEFT EAV65062311 LED Array RIGHT RAB37010701 THERMAL PAD EAJ65865601 PANEL Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 16 Screw(총 9ea) 분해 *After Disassemble Cover Shield Right, Disassemble Cover Shield Left . Cover Shield Right 분해 후, Cover Shield Left 분해 ① ② Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 17 * Pay attention to the color of the screw. 스크류 색상에 유의 할 것. 4. Disassemble of Case Top (Up/Down/Left/Right). 케이스탑을 분해한다(상/하/좌/우). *Disassemble Hooks with flat stick. 후크를 납작한 스틱으로 분해한다. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 18 6. Reverse the Module 모듈을 반전한다. * Two people should hold the left/right each side and reverse it. 2 명이 좌우를 각각 붙잡고 뒤집는다. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 19 4개 테이프를 제거하고, Panel를 분해한다.(12구 압착기 사용 권장, Panel 데미지 최소화) * 12구 압착기 8. Disassemble Guide Panel Screw (Down side, 7ea) 가이드패널 스크류를 분해한다.(하측, 7개소) Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 20 시트 2매와 LGP와 반사지를 제거한다. *Check up and down in the shape of the Horizontal side Sheet Guide. 장변 시트걸이부 형상으로 상하 확인 할 것. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 21 The Guide of Module disassemble 모듈 분해 가이드 10. After FFC Disassemle, Disattach Led Array for use Knife. FFC 분해 후 칼을 이용하여 LED Array를 띄어냄. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 22 Normal Signage Assembly Guide Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 23 시트 2매와 LGP와 반사지를 조립한다. *Check up and down in the shape of the Horizontal side Sheet Guide. 장변 시트걸이부 형상으로 상하 확인 할 것. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 24 The Guide of Module assemble 모듈 조립 가이드 3. Assemble Guide Panel.(Up/Down/Left/Right) 가이드 패널을 조립한다.(상/하/좌/우) 4. Assemble Guide Panel Screw (Down side, 7ea) 가이드패널 스크류를 조립한다.(하측, 7개소) Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 25 5. Panel Assembly (Use 12 Point adsorber) Panel를 조립한다.(12구 압착기 사용 권장, Panel 데미지 최소화) * 12구 압착기 6. Disassemble of Case Top (Up/Down/Left/Right). 케이스탑을 분해한다(상/하/좌/우). Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 26 8. Assemble of Case Top screws(20ea) Case Top Screw 조립(20개) * Pay attention to the color of the screw. 스크류 색상에 유의 할 것. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 27 Screw(총 9ea) 조립 *After Assemble Cover Shield Left, Assemble Cover Shield Right . Cover Shield Right 분해 후, Cover Shield Left 분해 ② ① Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 28: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 29 1. Back Cover 분리 ※ Back Cover와 Bottom Cover는 Latch 체결되어 있음. 2. WIFI ~ Main PCB 간 연결 Cable 해체 3. Bottom Cover 분리 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 30 Circuit noise, mechanical noise F. Exterior error Exterior defect First of all, Check whether there is SVC Bulletin in GSCS System for these model. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 31 ☞A5 & A3 Always check & record S/W Version and White Replace Main Board Re-enter White Balance value Balance value before replacing the Main Board Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 32 Check and Normal Check various voltages No Video/ replace voltage? of Power Board ( 13.2V) No audio MAIN B/D Replace Power Board and repair parts Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 33 Request repair for external device/cable Check external External device device and /Cable Replace Main/T-con B/D HDMI cable error normal Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 34 Replace Screen (Check normal operation normal? Main /T-con of External Input, and HDMI by connecting Jig, pattern Generator ,Set-top Box etc. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 35: Power Error

    Measure Main Power voltage of each output of Power B/D Normal? Normal Replace Main B/D voltage? Close Normal Check ST-BY 3.5V at Main B/D voltage? ☞A10 Replace Power B/D Replace Power Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 36 Power off by unknown status except listed case "POWEROFF_ABNORMAL1" Power off by abnormal status except CPU trouble Abnormal "POWEROFF_CPUABNORMAL" Power off by CPU Abnormal Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 37 Power Board Screen normal voltage Speaker Out Cancel OFF Replace Power Board and repair parts Check Speaker Disconnection Replace MAIN Board disconnection Replace Speaker Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 38 (In case of External Input signal error) Connect and check Normal Check and fix other external device audio? external device Check and fix external device Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 39 (Power B/D don’t have problem) If R/C operate, Normal Close operating? Explain the customer cause is interference from light in room. Replace R/C Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 40 INSTART menu Voltage? 1pin Main B/D ☞A13 Close Check & Repair Wifi cable connection ☞A5 Wi-Fi Mac value is “NG”? Close Change the Wifi assy Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 41 - Fix information signal - S/W Version HDMI/DP Check and fix Replace Main B/D Fix in Recognition error external device/cable accordance with technical information Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 42 ※ Describe the basis of the description in (For models without any fix information, provide “Part related to nose” in the Owner’s Manual. the description) Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 43 13/13 Module Zoom part Replace module damage with exterior damage Cabinet Replace cabinet damage Remote control Replace remote control damage Stand Replace stand dent Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 44 A-2/5 Defected Type caused by Main/ Inverter/ Exchange LED driver Board (PSU) A-3/5 Module Exchange Module itself (1) A-4/5 Exchange Module itself (2) A-5/5 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 45 Voltage and speaker checking method when C. Audio error_No audio/Normal video there is no audio WiFi operation checking method D. Function error_ WiFi/BT not working Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 46 Check LCD back light with naked eye date After turning on the power and disassembling the case, check with the naked eye, whether you can see light from module holes. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 47 1. Check the Voltage between LED+ / LED- 2. The Voltage spec is in Power B/D spec sheet 3. Refer to the Power B/D Spec sheet Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 48 2. Enter into White Balance of item 14. 3. After recording the R, G, B (GAIN, Cut) value of Color Temp (Cool/Medium/Warm), re- enter the value after replacing the MAIN BOARD. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 49 Error Established A. Video error_No video/ Audio symptom date Monitor Signage Revised Content Power Board voltage measuring method date Check the 13.2V and PWR_ON Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 50 Monitor Signage Version checking method Content date 1. Checking method for remote control for adjustment Version 업데이트 요 Press the IN-START with the remote control for adjustment Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 51 Monitor Signage Revised Content Monitor signage connection diagram date As the part connecting to the external input, check the screen condition by signal Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 52 Monitor Signage Revised Content Check Link Cable reconnection condition date Check the contact condition of the Link Cable, especially dust or mis insertion. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 53 You can view 8 types of patterns using the ADJ Key Checking item : 1. Defective pixel 2. Residual image 3. MODULE error (ADD-BAR,SCAN BAR..) 4.Video error (Classification of MODULE or Main-B/D) Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 54 Solder defect, CNT Broken Solder defect, CNT Broken T-Con Defect, CNT Broken Abnormal Power Section Solder defect, Short/Crack Solder defect, Short/Crack A - 1/5 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 55 Abnormal Power Section Abnormal Power Section Solder defect, Short/Crack Abnormal Display Fuse Open, Abnormal power section Solder defect, Short/Crack GRADATION Noise GRADATION A - 2/5 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 56 Appendix : Exchange Power Board No Light Dim Light Dim Light Dim Light No picture/Sound Ok A - 3/5 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 57 Panel Mura, Light leakage Press damage Crosstalk Press damage Crosstalk Un-repairable Cases In this case please exchange the module. Press damage A - 4/5 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 58 Gate TAB IC Defect Un-repairable Cases In this case please exchange the module. Horizontal Block Gate TAB IC Defect Gate TAB IC Defect A - 5/5 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 59 103.3V 114.8V 126.3V P202 VC_1~6 0.1V 1.4V 2.6V [Picture Condition : Back light 100] all condition meets, Power Board OK. SK100 (AC input) D201 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 60 126.3V 132.9V 139.6V P202 55" VC_1~6 0.1V 1.4V 2.6V [Picture Condition : Back light 100] all condition meets, Power Board OK. D201 SK100 (AC input) Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 61 160.3V 178.1V 195.9V P202 D201 VC_1~6 0.1V 1.4V 2.6V [Picture Condition : Back light 100] SK100 (AC input) all condition meets, Power Board OK. D201 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 62 POWER OFF MODE checking method date Entry method 1. Press the IN-START button of the remote control for adjustment 2. Check the entry into adjustment item 3 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 63 ③ Connect the tester RX1 to the speaker terminal and if you hear the Chik Chik sound when you touch the GND and output terminal, the speaker is normal. Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 64 2. If not OK, check WiFi/BT cable connection between WiFi/BT assy & Main B/D. 3. Check the 3.5V on the pin #1, 6, 12 Copyright ⓒ 2023 - 2024 LG Electronics Inc. All rights reserved. Only training and service purposes.
