  • Page 1 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA English HONBDA-7S-D-RMA Dual Band PS700 & PS800 Digital Signal Boosters User Manual Rv.02...
  • Page 2: Document History

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Document History Description Revision Date Issued Original Version Jun 13th, 2022 Rv.02...
  • Page 3: About This Manual

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA About this manual This manual describes installation, commissioning, operation and maintenance of Fiplex VHF & UHF and 700 & 800 Public Safety Centric DAS and Fiplex Control Software (FCS). The first part of the manual describes the Signal Booster hardware and the second part describes the software.
  • Page 4 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Abbreviations Automatic Gain Control Base Station, BS antenna = towards the base station Direct Current Downlink signal direction (from base station via Signal Booster / Master / Remote to mobile station) DPLX Duplex filter EEPROM...
  • Page 5: Safety Guidelines

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Part 1 HARDWARE Safety Guidelines The general safety information in this guide applies to both operation and service personnel. Specific warnings and cautions are located in the applicable guide sections but may not appear in this summary.
  • Page 6: Safety Notices

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Safety Notices This general safety information applies to both operating and service personnel. Specific warnings and cautions are located in other parts of this guide where they apply and may not appear in this summary.
  • Page 7: Fcc Compliance

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA FCC Compliance ATTENTION: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 8 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Selon RSS 131 Issue 2: ...
  • Page 9: Product Description

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 1. Product Description The DH147S are an FPGA based VHF & UHF and 700 & 800 Dual Band DAS systems that transmits in the frequencies with field programmable for VHF + UHF or 700MHz + FirstNet + 800 MHz. This DAS extends the radio coverage into areas inside the Base Station range where propagation losses This product consists in different parts that can work together:...
  • Page 10: Product Parts

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 1.1 Product Parts MASTER UNIT MASTER UNIT – RACK MOUNT OPTION 1.2 Dimensions MASTER UNIT MASTER UNIT – Rack mount option Rv.02...
  • Page 11: Power Specifications

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 1.3 Power Specifications  Nominal Main Power Input Voltage: 110 VAC. Internal AC to DC Power Supply for AC Versions.  Battery/DC Input Voltage: 24 VDC. External Battery Power Source. A UL 864 or UL 1481 listed power supply/battery charger and approved sealed lead acid batteries (not provided with this product) will be the DC input the DC version.
  • Page 12: Mechanical Specifications

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Mechanical Specifications Master Rack mount. Parameter Specifications Notes Size 19 x 14.3 x 1.7 in 484.22 x 363.15 x 43 mm Donor/Coverage Antenna Matting Male Connector Torque 3.7 Connectors Ports: N (f) ft.lbs.
  • Page 13: Alarm Indicators

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 1.5 Alarm Indicators There is an indicator panel located at bottom of the Signal Boosters. This LED panel, shown in Figure 3-1 below, works as a status monitor, indicating warnings or alarms. The LED panel has four LEDs: ...
  • Page 14: Installation

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 2. Installation Mounting the Device This device is NOT designed for outdoor usage. To improve reliability, it is mandatory to mount this device on a server room or an ambient controlled from direct exposure to sun, rain, snow and hailing.
  • Page 15: Important Installation Guidelines

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Step 2 Fix the rack mount device with screws that allows it. Important Installation Guidelines The following guidelines should be carefully observed for all installations of DH147S. • The unit shall be installed by QUALIFIED SERVICE PERSONNEL only. •...
  • Page 16 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Required to comply with following Model Building and Installation Codes: a) Standard for the Installation, Maintenance, and Use of Emergency Services Communications Systems, NFPA 1221; b) Fire Code NFPA 1; c) Life Safety Code, NFPA 101;"...
  • Page 17: Connection Step By Step

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 3. Commissioning 3.1 Connection step by step MASTER UNITS 1. Connect the service antennas to the To Base RF Ports. N type female connectors are used in the unit. If the Master unit is Rack Mount, then the RF ports are DMA female type.
  • Page 18 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES This product incorporates field-programmable software. In order for the product to comply with the requirements in the Standard for In-building 2-Way Emergency Radio Communication Enhancement Systems, certain programming features or options must be limited to specific values or not used at all as indicated below.
  • Page 19 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Enable/Disable - DL PA Fail Alarm Assigned to Relay Enabled - Assigned to Relay 4 1, 2, 3 or 4 Enable/Disable - TX Power Low Alarm Assigned to Relay Enabled - Assigned to Relay 4 1, 2, 3 or 4 Enable/Disable -...
  • Page 20 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA RELAY 3 IS INDICATING THE ALARM. The RX Power low alarm is used to provide the Donor Antenna Malfunction. The user must configure the DL Squelch threshold To trigger this on each channel below the power alarm properly the per channel measurement that the...
  • Page 21: Wiring Diagram

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 4. Wiring Diagram 4.1 AC Version MAIN AC SUPPLY CIRCUIT: 110VAC or 220VAC / 60Hz or 50Hz, 100W max. Note 1: When installed, this device must be in permanent connection. Note 2: All the cables used in this installation must be made of copper material, the aluminum conductors are forbidden for this purpose to ensure the safety.
  • Page 22: Dry Contacts

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 4.2 DC Version MAIN DC SUPPLY CIRCUIT: 24 VDC Nominal, 40W max. Note 1: When installed, this device must be in permanent connection. Note 2: All the cables used in this installation must be made of copper material, the aluminum conductors are forbidden for this purpose to ensure the safety.
  • Page 23: Maximum System Configuration

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 4.3.1 RF Connections  Max RF Input No-Damage: 0dBm  Max RF Output Power: -6 dBm  Frequency Range: 1. 700-800 MHz Bands + First Net 2. VHF/UHF Bands 4.3.2 Maximum system configuration ...
  • Page 24: Starting Operation

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 6. Starting Operation BE SURE THAT “TO MOBILE” AND “TO BASE” PORTS ARE PROPERLY LOADED EITHER WITH 50 OHMS DUMMY LOADS, OR RADIATING SYSTEM. IN ALL MASTER UNITS AND REMOTE UNITS. 1.
  • Page 25 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 3. Select the Firmware Band that will be used: a. 700/800 MHz b. VHF & UHF When the Firmware was chosen, the software will change between the two options: A) Firmware 700/800 MHz option: 1.
  • Page 26 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA section click on “Assign 1 st ADJBW 2. If FirstNet amplification is required, in the 700/800 MHz to FirstNet”. Note that the 1 st ADJBW Filter is now assigned to FirstNet. WARNING: Make sure to disable the FirstNet option on the Canadian territory.
  • Page 27 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 3. If OFF, Turn ON the UL and DL power amplifiers, and check that any alarm indicator is active. 4. Setup desired operating gain using FCS. UL and DL chain are independent, so both values must be set.
  • Page 28 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 7. Use the integrated spectrum analyzer to verify the spectrum. Rv.02...
  • Page 29 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA B) Firmware VHF & UHF option: 1. Setup the needed channel frequencies in the following part of the GUI for all the available bands. 2. If FirstNet amplification is required, in the 136-174 &...
  • Page 30 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA WARNING: Make sure to disable the FirstNet option on the Canadian territory. Rv.02...
  • Page 31 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 3. If OFF, Turn ON the UL and DL power amplifiers, and check that any alarm indicator is active. 4. Setup desired operating gain using FCS. UL and DL chain are independent, so both values must be set.
  • Page 32 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 6. Setup desired filter bandwidth, depending on presence of adjacent channels. The wider the filter the lower the added delay, but if adjacent signal is detected, narrow filters can be used. Spectrum analyzer of FCS can be used to know rejection to undesired signals.
  • Page 33: Laboratory Measurements

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Laboratory Measurements For specific parameters verification and laboratory tests, please contact factory. Detailed procedures, recommended tests set up, and a knowledge engineering team will bring adequate support to perform the measurements in a comfortable and safely way. Rv.02...
  • Page 34: Local Software. Desktop Application Through Usb Port

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Part 2 Software 1. Introduction Fiplex Signal Booster can be fully configured and monitored in local and remote mode. Local mode: USB port with Windows desktop application Remote mode: Remote Web server In following section, each control mode (configuration / monitoring) are described.
  • Page 35 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 3. The installer will start to copy the necessary files. Rv.02...
  • Page 36 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 4. After installation has completed, a shortcut in user desktop will appear. 5. Connect USB cable between computer and Signal Booster, keeping the Signal Booster powered off. Usually, drivers will be automatically installed, but depending on Windows version, screen asking for drivers of new device can appear.
  • Page 37 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 7. Execute the Fiplex Control Software. Next window will appear: User interface controls:  Scan Devices Button: refresh the available COM ports and identify Fiplex devices  Connection Button: connect / disconnect software from Signal Booster ...
  • Page 38 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA 8. Click “Scan Devices” Now, the Fiplex Digital Signal Booster is shown in the list of available devices, and connection button is enabled. NOTE: Fiplex Signal Booster could not appear in list, if COM port number is higher than COM16, depending on Windows version.
  • Page 39 Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Click “Advanced Options” Change COM port number 9. Click “Connect”. Fiplex Control Software window will be automatically maximized, and web browser will show the configuration screen. Application screens are described in the next section due to these application screens and web pages (in webserver remote mode) are the same.
  • Page 40: Maintenance

    Fiplex Communications Inc Public Safety Centric DAS Master Rack mount | HONBDA Maintenance: The devices must be installed in for easy access for possible servicing and maintenance like the manual advice. According to NFPA 72, The Fire Alarm Code, the property owner is ultimately responsible for ensuring that ITM is completed on the fire alarm system, including the smoke detectors.
