- Page 1 Installation Instructions and Owner’s Manual SCS1 Series Backwashing Multi-Layer Carbon Filter System Franklin Water Treatment, LLC 12630 US Highway 33 N Churubusco, IN 46723 Phone (260) 693-1972 Fax (260) 693-0602 SCS1 Instruction Manual 240314.docx...
-
Page 2: Table Of Contents
Component Parts Breakdown Page 17 Component Parts List Page 18 Control Valve Breakdown Page 19 Control Valve Parts List Page 20 Installation Fittings Page 21 Ten Year Limited Warranty Page 24 Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 3: Pre-Installation Instructions
“rotten eggs.” Due to its gaseous nature, hydrogen sulfide must be tested at the well site within 1 minute of drawing the sample. If sulfur is present additional equipment will be required. The SCS1 can reduce low levels of sulfur in drinking water. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 4 8. Appliances requiring extended periods of continuous or high flow water use (i.e. geothermal heat pumps, swimming pools, lawn irrigation, outside hose bibs, etc.) should bypass the filter. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 5: General Installation
Filtered Hard Water geothermal heat pumps, swimming pools, lawn Treated Water irrigation, hose bibs etc. Untreated Water Brine Water Heater Softener Pressure Tank SCS1 BW Filter Tank Tank FIGURE 1: Typical Installation Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 6: Bypass Valve
If water is available on the outlet side of the unit it is an indication of water bypassing the system (Fig. 5) Figure 3 - Bypass Figure 2 - Service Figure 5 – Shut Off Figure 4 - Diagnostic Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 7: Installation Instructions
Check for leaks and correct as needed. Return the inlet bypass valve handle to the bypass position and allow the filter media to soak for at least 2 hours prior to backwashing the unit. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 8: Set The Time Of Day
If a power loss last less than 8 hours and time of day is flashing, replace coin type 2032 battery. Do not forget to reset for daylight savings time. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 9 “RINSE” will be shown in the lower right of the display. STEP 15: Exit Manual Regeneration: Allow the rinse cycle to complete and the filter will return to service mode automatically. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 10 Installation Instructions (cont.) STEP 16: TURN ON FUEL / ELECTRICAL SUPPLY TO WATER HEATER. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 11: User Displays
"REGEN" button. "REGEN TODAY" will appear on screen. Push and hold REGEN button to initiate immediate regeneration. The softener will regenerate again at specified time. Back-to-back regenerations are recommended when salt is allowed to run out in brine tank. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 12: Maintenance
“Service” position (Figure 2, Page 5) allowing air to purge gently. Any air trapped in the media bed should begin purging to the drain and water should begin flowing to the drain slowly. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 13 “REGEN” appears in the middle left of the display. Allow the rinse cycle to complete and the filter will return to service mode automatically. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 14: Troubleshooting Guide
A) pH too low Birm Filter fails to remove B) Dissolved oxygen such as soda ash injection system iron level too low 2) Aerator may be installed prior to the filter Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 15 2 outer pins (furthest left and furthest right) of connector J4 on the control valve circuit board. Should be approximately 15 volts DC. Replace transformer if defective. 5) Replace circuit board if needed Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 16: Error Code
ALT oFF inspection and repair or replacement and looking for park B) Obstruction in reset control valve (hold “NEXT” and position control valve “REGEN” buttons for 3 seconds) Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 17: Specifications
Factory default settings: Filter mode, P-Code 80, Single 8 minute backwash, single 8 minute rinse, 3 days between regeneration. All models include: V3007 – 1” MNPT elbow adapters and QFNCR4-2 – ¾” compression fittings for PEX, CPVC and copper. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 18: Component Parts Breakdown
Component Parts Breakdown Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 19: Component Parts List
1.25 - QC20 1/4" x 1/8" Gravel, 20 lb Pail for models SCS1-20, SCS1-25 qty 1.5 - QC20 1/4" x 1/8" Gravel, 20 lb Pail for models SCS1-30 V3006 Bypass valve Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 20: Control Valve Breakdown
Control Valve Breakdown Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 21: Control Valve Parts List
Flow Control Washer, 7.5 GPM (SCS1-20) V3162-090 Flow Control Washer, 9.0 GPM (SCS1-25) *V3190-110 *Flow Control Washer, 11.0 GPM (SCS1-30) * requires 1” drain housing V3008-05 Not Shown 18280-02 Top Screen, Bayonet Style Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 22: Installation Fitting Assemblies
1" brass sweat assembly V3007-03 assembly V3151 Nut, 1" quick connect V3151 Nut, 1" quick connect V3150 Split ring V3150 Split ring V3105 O-ring 215 V3105 O-ring 215 V3188 Fitting V3188-01 Fitting Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 23 O-ring 215 V3629 Fitting V3628 Fitting 1-1/4" PLASTIC MALE NPT Description Part # 1-1/4" plastic male NPT V3007-05 assembly V3151 Nut, 1" quick connect V3150 Split ring V3105 O-ring 215 V3317 Fitting Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 24 SERVICE WRENCH - V3193 Although no tools are necessary to assemble or disassemble the valve, the Service Wrench, (shown in various positions on the valve) is available to aid in assembly or disassembly. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 25: Ten Year Limited Warranty
If you are unable to contact the dealer, contact Franklin Water Treatment, LLC @ (260)693-1972. We will require a full description of the problem, model number, date of purchase, and selling dealer’s business name and address.
